RC Factory FLASH 09M Assembly Instructions Manual

910 mm 900 mm 260g
Kit Contents:
*Fuselage
*Wings
*Canopy
*Backbone
Acessory Pack Contents:
1x Landing gear plate
2x Pant brace
1x Plastic frame
1x Motor mount
2x Screw M2x16 ... landing gear
4x Washer 2 ... landing gear
4x Nut M2 ... landing gear
2x Screw 2,9x6mm ... landing gear
8x Plastic clevises
Plastic frame:
1. Aileron horn (2pcs)
2. Aileron servo arm extensions
3. Horizontal stabilizator horn
4. Vertical stabilizator horn
You Will Also Need:
* S harp hobby knife
* S crewdriver
* P liers
* File
All manuals and user guides at all-guides.com
Li-pol
3s 450-720
*Horizontal stabilizator
*Vertical stabilizator
*SFG's
*Landing gear
*Wheel pant
*T-Canalyser
*Acessory pack
*Carbon parts:
- 2x 1x500 ... stabilizator pushrods
- 2x 1,5x800 ... wing spar
4x Screw 2,9x9mm ... motor instalation
2x 2/1x0,5cm ... Plastic clevises reduction
2x Threaded end Ø 1,5
2x Threaded end Ø 1,0
2x Wheel
1x Wood spar
1x Push rod guides
2x 3(4)x0,5x150 ... horizontal stab reinforcement
2x 1,8x125mm ... aileron pushrods
4.
2.
1.
* CA medium+thin, CA kicker
* Ruler
* S andpaper 100-500
* Drill 2 a 3mm
3.
1.
