Before the first use of the level meter , read the instructions in this manual and keep it
carefully. The manufacturer reserves the right to make alterations without a prior notice.
INSTRUCTION MANUAL
Hlm-35
Hlm-35

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MLM-35 and is the answer not in the manual?

Questions and answers

Related Manuals for Dinel MLM-35

Summary of Contents for Dinel MLM-35

  • Page 1 INSTRUCTION MANUAL Hlm-35 Hlm-35 ydrostatic level meters ydrostatic level meters Before the first use of the level meter , read the instructions in this manual and keep it carefully. The manufacturer reserves the right to make alterations without a prior notice.

  • Page 3: Table Of Contents

    ontents 1 . Basic description ........................ 4 2  .  Range of application ......................4 3  .  Variants of sensors ......................5 4 . Dimensional drawing ......................5 5  .  Installation and putting into operation ................6 6  .  Mechanical mounting ....................... 7 7  .  Electrical connection ......................7 8 ...

  • Page 4: Basic Description

    (resp. voltage) accord- ing to the density of measured liquid. We recommend consulting the suitability of the level meter for measuring other liquids, than H2O with the manufacturer. HLM–35 © Dinel, s.r.o.

  • Page 5: Variants Of Sensors

    Sensor with stainless steel converter membrane. Pressure equali- sation via a capillary. 4 . d imensional drawing HLM–35N-C_ HLM–35N-S_ Types of threads: Types of threads: G 3/4''; M27x2 G 3/4''; M27x2 * According to el. connection type © Dinel, s.r.o. HLM–35...

  • Page 6: Installation And Putting Into Operation

    (ø 13 mm) Spiral relief Note. Values in brackets apply for version with the capillary (CK and SK) 5 .  Installation and putting into operation This procedure has the following three steps: •  Mechanical mounting - see Chapter 6 •  Electrical connection - see Chapter 7 •  Settings - see Chapter 8 HLM–35 © Dinel, s.r.o.

  • Page 7: Mechanical Mounting

    (see accessories), the connector is not part of the sensor. In this case the cable is connected to the inside pins of the socket according to the figure below. (BK) +U (BR) 0 V (BU) Inside view of the connector socket (variant "C") © Dinel, s.r.o. HLM–35...
  • Page 8 BR – brown BU (3) BK – black BU – blue (X) – Connector terminal numbers 0 V (3) Cable wire colours with capillary: RD – red BU – blue BK – black ---- – shielding +U (1) HLM–35 © Dinel, s.r.o.

  • Page 9: Setting The Measuring Range With A Magnetic Pen

    Permanent shine – the level meter is ready to confirm the limit setting Orange "STATE" using the magnetic pen 3 short flashes – confirmation of the settings The simultaneous shine of green and orange LEDs – when touching the magnetic pen to confirm the limit setting © Dinel, s.r.o. HLM–35...

  • Page 10: Connection Examples

    In the case using a connection box with integrated overvoltage protection, the sensor needs to be connected to the bottom series of terminals. This series of contacts is marked by label SENSOR. HLM–35 © Dinel, s.r.o.
  • Page 11 SENSOR. (BK (0V)(3)) Connection of level meter HLM-35 with current output to the PCU-100 Legend: – red – black ---- – cable shield (1...) – connector terminal numbers Here is the connection of the PCU-100 -_- I unit with the HLM-35N -_- I level meter. © Dinel, s.r.o. HLM–35...

  • Page 12: User-Adjustable Measuring Ranges

    CV, CK, SV and SK; (M) Settings using the magnetic pen, (0070) measuring range 7 m, the maximum output current can be set in the range of 3,5 to 7 m, see table User- adjustable measuring ranges. HLM–35 © Dinel, s.r.o.

  • Page 13: Order Code

    0010 ... 1000 (see the table above) CABLE cable length in m EXAMPLE OF  HLM-35 N - CV - M27 - 0035 K 2 CODING factory setting to the required range, according to the order code (measuring range). © Dinel, s.r.o. HLM–35...

  • Page 14: Correct Specification Examples

    Protection against dangerous contact is provided by low safety voltage according to 33 2000- 4-41. Electromagnetic compatibility is provided by conformity with standards EN 55011/B, EN 61326- 1, EN 61000-4-2, -4-3, -4-4, -4-5 and -4-6. HLM–35 © Dinel, s.r.o.

  • Page 15: Use, Manipulation And Maintenance

    18 .  General conditions and warranty Dinel, s.r.o. guarantees for the period of three (3) years that the product has the characteristics as mentioned in the technical specification. Dinel, s.r.o. is liable for defects ascertained within the warranty period and were claimed in writing.

  • Page 16: Technical Specifications

    HLM–35_–_ _- _- _- V- _- _ _ _ _ plastic PA / NBR HLM–35_–_ _- _- _- H- _- _ _ _ _ plastic PA / NBR Connector M12 HLM–35_–_ _- _- _- C- _- _ _ _ _ nickel-plated brass HLM–35 © Dinel, s.r.o.

  • Page 17: Packaging, Shipping And Storage

    Store the device in its original packaging in dry areas covered from weather conditions, with humidity of up to 85 % without effects of chemically active substances. The storage temperature range is -20 °C až +70 °C. © Dinel, s.r.o. HLM–35...
  • Page 18 Notes HLM–35 © Dinel, s.r.o.
  • Page 20 Dinel, s.r.o. U Tescomy 249 760 01 Zlín Česká republika Tel.: +420 577 002 002 E-mail: obchod@dinel.cz www.dinel.cz Aktuální verzi návodu naleznete na www.dinel.cz verze: 05/2020 2017...
