HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE
ALLWAYS
Installation Guide
1
ECO No:254-403-C
Page: 1 OF 128
Rev: B
Part No:7029-9682

Advertisement

loading
Need help?

Need help?

Do you have a question about the ALLWAYS and is the answer not in the manual?

Questions and answers

Related Manuals for Haworth ALLWAYS

Summary of Contents for Haworth ALLWAYS

  • Page 1 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE ALLWAYS Installation Guide ECO No:254-403-C Page: 1 OF 128 Rev: B Part No:7029-9682...
  • Page 2 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Index 1 free standing worktop and its accessory 1.1 leg 1.2 work surface 1.3 screen 1.4 power tray outlet plate 1.5 horizontal power channel 1.6 vertical cable channel 1.7 horizontal cable channel 1.8 umbilical cord 1.9 center leg...
  • Page 3 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Index 4.3 Power spine installation 4.3.1 One-segment power spine installation 4.3.2 Two-segments power spine installation 4.3.3 Three-segments power spine installation 4.4 Accessory 4.4.1 Ceiling channel a Install ceiling channel on power hoop b Install ceiling channel on Power Spine 4.4.2 Umbilical cord...
  • Page 4 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 1. Free standing worktop 1.1 legs (A) Fix leg (default height 730mm) (2) leveling Adjustment . Pull down the glide cover as the picture shown Circumrotate it to the left or right as the picture shown...
  • Page 5 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 1.2 worksurface 1.2.1 worksurface types worktop board Straw board: 18mm Powder coated MDF : 18mm HPL board: 18mm Compact laminate board: 10mm Glass 10mm 1.2.2 Below picture indicate the position to install legs on worktop：...
  • Page 6 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE finish step NOTES “○”Install the worktop leg at position with round remark, the means to install the leg at rectangle corner is the same as above The means to install leg at obtuse angle of L shape is as image shown, the holes...
  • Page 7 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 1.3 screen 1.3.1 desk screen It is made from Fabric and metal frame Unpack it and fix it on desk. 1.3.2 Hung screen There are 3 kind of Hung screen made from different material which is fabric ,acrylic screen and compact laminate See below for Hung screen Assembly。...
  • Page 8 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 1.3.3 Recessed desk screen Recessed desk screen is made of fabric ,needn’t assembly. 1.3.4 lateral screen lateral screen is made of :fabric and metal frame. The fabric screen like the picture shows is need not to be assembled.
  • Page 9 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 1.3.5 power hoop/spine screen 1.3.5.1 glass screen installation Step 1: Place the rubber spacer on the bracket as picture shown. Step 2: Place the glass sheet in approach position. Step 3: Place the washer for screwing in.
  • Page 10 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE cover finished step 1.3.5.2 power spine/hoop Fabric screen It has been assembled in plant, can be installed on the power hoop/spine directly. 1.3.5.3 power spine/hoop compact laminate screen It has been assembled in plant, can be installed on the power hoop/spine directly.
  • Page 11 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 1.3.5.4 power spine/hoop recessed glass screen It is used for power hoop/spine ceiling feed solution, same as 4.3.1. 1.3.5.5 Recessed power spine/hoop Fabric screen It has been assembled in plant, can be installed on the power hoop/spine directly.
  • Page 12 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 1.3.5.7 power hoop screen accessory rail Accessory rail is optional installed on screen. Ride the Accessory rail on screen. Press the top to fit height. There are 2 kinds of Accessory rail ： One for glass screen . See side view (1) Another for fabric screen.
  • Page 13 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 1.4 power tray outlet plate As image shown below, install socket body to outlet plate, and make sure the holes of two parts are in alignment. Then put the socket cover on the outlet plate, also holes of which are in alignment.
  • Page 14 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE After cable arrangement, assemble pre-assembled outlet plate to the power tray, insert the plate into power tray. match the hole of plate to the one of power tray and fix it by screw M6*20.
  • Page 15 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Locate the power tray rim in the cutout of worktop as illustrated, Insert the flange of the power tray to rim, then assemble the power tray and power tray rim by Velcro strip as illustrated If the worktop is not in glass, and needed screw the power tray in worktop.
  • Page 16 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 1.5 horizontal power channel Install the horizontal power channel beside power tray as illustrated. Install the Insert into the slot of rim as illustrated, then rotate 90 degrees. Assemble the horizontal power channel and then adjust the insert to the position of installation holes, screw them together.
  • Page 17 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 1.6 Vertical cable channel Install vertical power channel in slot on the leg. Refer to A-A detail to clip to channel into slot. Vertical cable channel step A-A detail step ECO No:254-403-C Page: 17 OF 128...
  • Page 18 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 1.7 horizontal cable channel If no power tray, only install the horizontal cable channel. Installation same as step 1.6 horizontal cable channel step Installation step Installation2 Q-Q detailed ECO No:254-403-C Page: 18 OF 128...
  • Page 19 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 1.8 umbilical cord 1.8.1 umbilical cord and desk Cable through form Floor to worktop use umbilical cord as picture shown. install the Y shape umbilical cord connector on the rim using 2 pcs screw M6*25.
  • Page 20 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 1.8.2 umbilical cord and ceiling Uninstall the top section of umbilical cord, put the bracket on the umbilical cord, then install the top section as below drawing show. Use screw ST6.3-38 to fix the bracket with ceiling fix the end of the umbilical cord with rim under worktop through screw.
  • Page 21 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 1.9 center leg 1.9.1 Left center leg installation method of worktop and power tray refer to 1.4.1 As the image shown, fix the insert into the inner slot of worktop frame Rotate 90 degrees, make it be perpendicular to the worktop frame...
  • Page 22 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Put the fixed height leg at the middle of bridge ( the second row hole at the bottom, the border line of leg should be in 45 degrees as the image shown. Assemble the fixed height worktop leg to the bridge.
  • Page 23 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 1.10 CPU holder Bridge installation refer to 1.9.1 Matching the CPU holder installation slot with the hole on Bridge. Use M8*25 Screw fix them together as picture shown. CPU holder step step step ECO No:254-403-C...
  • Page 24 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 1.11 monitor arm Connect the adaptor on monitor arm before Connect them to the worktop. As image shown, lean the bottom holder against the rim of worktop, the hole match the screw slot of rim, tight it by screw M6*25...
  • Page 25 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 1.12 screen installation on desk 1.12.1 desk screen /recessed desk screen installation As below image, move the screen bracket close to the bottom frame under worktop, towards to the side of worktop with power tray.
  • Page 26 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 1.12.2 lateral screen installation put lateral screen between worktop connection as picture shown. fix lateral screen on rim with M6*20 Screw. See A detail. Note: lateral screen could be installed at any position along worktop rim.
  • Page 27 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 1.12.3 Hung screen installation Install the screen to the side of worktop with power box, and located it at the middle position Fix the upper surface of screen bracket to the bottom frame below worktop, the installation...
  • Page 28 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 1.12.4 modesty screen installation As the image shown, fix the two modesty bracket L to the both ends of acrylic sheet, insert the sticking out hole to the long round slot with the sharp edge facing outside.
  • Page 29 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 1.12.5 install rim modesty screen on Desk Put rim modesty screen under the worktop at opposite side to user. Match the 3 installation hole with the groove on rim. Use M6*20 screw fix the screen on rim as detail A shown.
  • Page 30 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 1.13 storage and Desk 1.13.1 below desk bracket As image shown, connect the bracket to the bridge of worktop, the means to install the worktop bridge refer to 1.10.1 Assemble the bracket as image shown and fix it by screws.
  • Page 31 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 1.13.2 side aligned bracket 1.13.2.1 Bracket has two different types: one for worktop in 17.5 mm thickness and the other for worktop in 10mm As image shown to connect the bracket to the rim of worktop...
  • Page 32 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 1.13.2.2 Bracket has two different types: one for worktop in 17.5 mm thickness and the other for worktop in 10mm. Embed two inserts into the side slot of bridge, as image shown put the insert into the slot and rotate 90 degrees, then move that to the end of each side.
  • Page 33 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 1.13.3 rear aligned bracket Bracket has two different types: one for worktop in 17.5 mm thickness and the other for worktop in 10mm Embed two inserts into the side slot of bridge, as image shown put the insert into the slot and...
  • Page 34 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 1.13.4 team to open storage Put the open storage on the side storage and align as shown image. Put two inserts into the side slot of the open storage, and then rotate 90 degrees.
  • Page 35 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Make the team storage close the open storage and keep their sides aligned. Let the threaded shaft go through the side hole of open storage as the detail. Place the washer through the bolt and rotate the nut in the storage till tighten the two storages as the detail.
  • Page 36 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 1.13.5 side storage to side storage & team storage to team storage Remove top panels prior to install. To take down the metal top panel, screws should be removed first. Align the 2 storages from side to side.
  • Page 37 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE fix the 2 storages. Install the metal top panel and tightening the four screw. step step step finish step step ECO No:254-403-C Page: 37 OF 128 Rev: B Part No:7029-9682...
  • Page 38 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 120 degree workstation installation 2.1.1 Put the worktop horizontally as below image shows 2.1.2 Use 8 bolt M6*25 to fix 2 legs on the rim as below images show 2.1.3 Use 4 bolt M6*25 to fix two Wing brackets as below images show...
  • Page 39 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 2.1.4 Use 4 M6*14 bolts to fix leg on the wing bracket as images show 2.1.5 Use 4 bolts M6*20 to fix shared adaptor on the worktop ,then use the bolt M6*16 to fix leg on the shared adaptor as images show 2.1.6 Assemble the second worktop according to step 1.1, 1.2, 1.3, 1.4.
  • Page 40 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 2.1.7 Use 4 bolts M6*25 to fix the second worktop to the first one 2.1.8 Assemble the third worktop according to previous step 2.1.9 Fix the third worktop to the first and second ones...
  • Page 41 HAWORTH ASIA PACIFIC ALLWAYS INSTALLATION GUIDE HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 2.2 Freestanding 120 degree worktop installation worktop 2.2.1 Put the horizontally as below image shows 2.2.2 Use 6 bolts M6*25 to fix leg on the rim 2.2.3 Use 2 bolts M6*10 and 2 hammer-headed screw to fix leg backstop on the...
  • Page 42 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 2.2.4 Fix leg on the leg bridge 2.2.5 The finished installation ECO No:254-403-C Page: 42 OF 128 Rev: B Part No:7029-9682...
  • Page 43 HAWORTH ASIA PACIFIC ALLWAYS INSTALLATION GUIDE HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 2.3 Accessories 2.3.1 Workstation gap cover 1 select worktop cover in proper size 2 Directly fix cover to the gap between two worktop Note: Make sure the cover and the rim are in alignment...
  • Page 44 HAWORTH ASIA PACIFIC ALLWAYS INSTALLATION GUIDE HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 2.3.2 Screen on desk 1 Choose screen in proper size 2 Use screw to fix screen on the rim screw A view A view ECO No:254-403-C Page: 44 OF 128...
  • Page 45 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 3 use screw to fix screen on workstation a) Put the screen in the gap of workstation and rotate per as step 1 b) Rotate to vertical position. c) Use the screw to fix it under the rim of worktop.
  • Page 46 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 2.3.3 screen under desk 1 Choose screen in proper size 2 Use screw to fix screen on the rim ECO No:254-403-C Page: 46 OF 128 Rev: B Part No:7029-9682...
  • Page 47 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 2.3.4 Umbilical cord on the desk 1 Install umbilical cord bracket as the photo shows 2 Fix the bracket on shared adaptor, below picture show bottom of worktop 3 Fix the umbilical cord on the umbilical cord bracket , then fix the top cap on the...
  • Page 48 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 2.3.5 U mbilical cord under the desk 1 Install umbilical cord bracket as the photo shows 2 Fix the umbilical cord on shared adaptor View A ECO No:254-403-C Page: 48 OF 128 Rev: B...
  • Page 49 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 2.3.6 horizontal cable channel 1 Fix hammerhead screw on the rim Hammerhead screw 2 Fix horizontal cable channel on the rim ECO No:254-403-C Page: 49 OF 128 Rev: B Part No:7029-9682...
  • Page 50 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Executive desk installation guide 3.1 Horizontal and vertical bridge There are two kinds of executive desk , with or without vertical bridge. Below picture indicate how to install these two kinds of desks. Horizontal bridge...
  • Page 51 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 2 、Horizontal cable channel After the installation of bridge ,fit the horizontal cable on the horizontal bridge as the following: Horizontal cable channel Put horizontal cable channel between horizontal bridge and cutout of worktop, align its hole with the side hole of horizontal bridge.
  • Page 52 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 3、Modesty panel Put modesty panel above the horizontal bridge, keep the hole of modesty panel align with horizontal bridge bottom holes. The detail are in above first picture Put three small bracket on the modesty panel, keep its hole align with hole of modesty panel and horizontal bridge, use 6 M6 screw connect the small bracket with Horizontal, then the modesty was been fixed between bracket and bridge.
  • Page 53 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4 、 Umbilical core under executive desk, be aware that should be executive desk umbilical core Take out one umbilical core and insert M6 bolt, then connect it with the horizontal cable channel through the bolt and nut as the first picture show...
  • Page 54 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 5、 Storage under executive desk installation Horizontal and vertical bridge installation refer to 1.2.3, align the bracket top hole with vertical bridge hole, then connect them with M6 screw as the first picture show...
  • Page 55 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 6、 install legs (be aware that should be executive desk leg) 7、 install power tray 8、 install desk mat Power tray desk mat ECO No:254-403-C Page: 55 OF 128 Rev: B Part No:7029-9682...
  • Page 56 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE New Power hoop/spine installation guide New Power hoop is used to supply power and data solution in the workspace ,it’s also used to support the worktop. 4.1 The one-segment power hoop, actual length is 1400/1500/1600/1800/2100/2400MM 4.2 The two segments power hoop, actual length is...
  • Page 57 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Basic Component End cover Power socket Plate End cover Main channel Screen adapter top corner bracket Flip top top corner Segregation plate bracket Power and data Side cove Bottom cover Beam Side cover Side channel...
  • Page 58 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4.1 One-segment Power hoop installation 4.1.1 Adjust glide of the beam to same height, See below. 4.1.2 if Power hoop is freestanding, it need the stabilizer foot. There are two kinds of the stabilizer foot: double sides stabilizer foot and single side stabilizer foot.
  • Page 59 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4.1.3 install two bottom corner brackets on the beam with 12 M6X6 screws, see below. 4-M6X6 Bottom corner bracket 2-M6X6,both sides 4.1.4 install the two side channels on the bottom corner brackets with M6X6 and M6X14 screws, then tighten the side cover of the two bottom corner brackets, see below.
  • Page 60 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE M6X6 Step 2: Use M6X6 screws to fix two side channels Step 3: Use M6X14 screws to fix the side channels (two red screws in the photo), then tighten the side cover of bottom corner brackets (four...
  • Page 61 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4.1.5 installation the main channel 4.1.5.1 put two Inserts in the slot of the main channel at each side. Install the inside insert (length 50mm),each side need two inserts, see below. Install the outside insert (length 90mm) , each worktop need two inserts , according to the quantity of worktop put inserts in the main channel.
  • Page 62 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4.1.5.2 install two top corner brackets on the main channel, make sure the gap between side cap of the top corner bracket and the main channel is well- proportioned, then fix it as below process.
  • Page 63 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4.1.6 Assemble the main channel on the side channel, fix main channel on side channel with M6X6 and M6X14 screw, then tighten the side cover of top corner brackets (four green screws in the photo)
  • Page 64 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE ， Notes: there are two kinds of segregation plate one is for CHN86 and the other for ， CMS/power logic see below. CHN86 CMS/Power logic 4.1.8 install the screen adapter, it should be assembled in the middle of the main channel.
  • Page 65 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4.1.9 two kinds of segregation plate and power/data layout. See below.. CHN86 CMS/Power logic 4.1.10 install the power/date socket on the plate, there are three kinds of socket plate: China86，CMS and power logic, see below.
  • Page 66 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE ： ， Attention the socket board plate have reserve the blank position break down the blank position according to the demand, See below. 4.1.11 put the power/date socket plate in the main channel, then put the Inserts in the slot, and fix them with M6X6 screws.
  • Page 67 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4.1.12 install the flip top cover, see below. Step 1 put the hinge in the main channel Step 2 revolve the hinge at the below position The right position ECO No:254-403-C Page: 67 OF 128...
  • Page 68 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Step 3 push the hinge in the flip top. 4.1.13 Fix the end cover with M6X6 screws, see below. ECO No:254-403-C Page: 68 OF 128 Rev: B Part No:7029-9682...
  • Page 69 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Notes: if the screen is to be installed, Please install the screen firstly then install the screen adapter covers, see 4.1.14 for cover installation. M6X6 screw ECO No:254-403-C Page: 69 OF 128 Rev: B...
  • Page 70 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4.1.15 install the side cover on the side channel. See below. 4.1.16 install the bottom cover on the beam, see below. ECO No:254-403-C Page: 70 OF 128 Rev: B Part No:7029-9682...
  • Page 71 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4.1.17 Final power hoop as below. 4.1.18 according to the layout assemble the worktop on the power hoop. see below. Step 1: Install the worktop connection bracket on the main channel with M6 screw and insert. see below.
  • Page 72 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Step 2: assemble the worktop on the power hoop with M6 screw. See below. Notes: when 8mm thick worktop is used, please using this kind of bracket, see below. ECO No:254-403-C Page: 72 OF 128...
  • Page 73 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4. 1.2 two-segments Power hoop installation 4.1.2.1 connect two beam with join kit bracket and Adjust glide of the beam to same height, See below. 4.1.2.2 Connect two main channels together. 4.1.2.3 put two inserts in the slot of the main channel and make the channels alignment, see below.
  • Page 74 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4.1.2.4 install the bottom connection part with M6X6 screws. See below. Top view 4.1.2.5 install the top connection part with M6X6 screws and insert ,the centre line of connection part need to alignment with the joint line of two main channel. see below.
  • Page 75 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4.1.2.6 install the two bottom corner brackets on the beam with M6X6 screws. Same as 4.1.1.3 4.1.2.7 Install the two side channels on the two bottom corner brackets. Same as 4.1.1.4 4.1.2.8 put two Inserts in the slot of the main channel at each side. Same as 4.1.1.5 NOTICE: Must be installation the insert before install the top connector 4.1.2.9 install two top corner brackets on the main channel, make sure the gap between...
  • Page 76 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4.1.2.17 Fix the cover of the screen adapter with M4X6 screws, same as 4.1.1.14. 4.1.2.18 install the bottom cover on the beam, same as 4.1.1.16. 4.1.2.19 install the side cover on the side channel, same as 4.1.1.15.
  • Page 77 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4.2 Two new power hoop assembled 4.2.1 take off the end cover of two new power hoops, then connect two power hoop with four bolts, see below. 4.2.2 put the join kit cover between the two power hoops, see below.
  • Page 78 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4.3 New power spine installation New Power spine is used to supply power and data solution in the work space , it’s also used to support the worktop. New Power spine have three kinds of structures one segment, two segments, and three segments.
  • Page 79 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4.3.1: One segment power spine installation 4.3.1.1 fix the segregation plate with M6X6 screws in the main channel same above 4.3.1.2 install the screen adapter, it should be assembled in the middle of the main channel, same above NOTICE: Must be install the insert before install the top connector.
  • Page 80 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4.3.1.7 fix the end cover with M6X6 screw. See below. 4.3.1.8 put the big side cover at the end of main channel, see below. step1： install the big side cover on the main channel step2：fix the it with M6X10 screws.
  • Page 81 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4.3.1.9 Fix the cover of the screen adapter with M4X6 screws, same above 4.3.1.10 Fix the leg on the bottom of the main channel with M6X16 screws. See below. 4.3.1.11 install the fliptop, It’s very important to test the fliptop to verify the function, Same above Attention ：...
  • Page 82 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4.3.2 The two segments power spine installation 4.3.2.1 Connect two main channels together, refer to power hoop installation guide 4.3.2.2 fix the segregation plate with M6X6 screws in the main channel. Refer to power hoop installation guide 4.3.2.3 install the screen adapter, it should be assembled in the middle of the main...
  • Page 83 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4.3.3 Three segments power spine installation 4.3.3.1 Connect three main channels together, same above 4.3.3.2 fix the segregation plate with M6X6 screws in the main channel. Refer to above 4.3.3.3 install the screen adapter, it should be assembled in the middle of the main channel, refer to above 4.3.3.4 put two Inserts in the slot of the main channel at each side.
  • Page 84 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Accessory Ceiling channel 4.4.1 Install ceiling channel on Power hoop 4.4.1.1 step1：fix the connection bracket of ceiling channel with M6X6 screws on power hoop. top view step2：put the two clips in the side cap, and install ceiling channel cover on power hoop.
  • Page 85 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE step3：install ceiling channel on the connection bracket with M6X6 and M6X14 screws then put the power and data in the ceiling channel. step4： install the side cover on the ceiling channel. ECO No:254-403-C Page: 85 OF 128...
  • Page 86 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE step5：according to the ceiling height, add M6 hole on the ceiling channel, then using M6X25 screws fix the bezel on the ceiling channel to cover the ceiling feed hole. Notes: if the ceiling channel is 2800MM, another 500MM channel will be added on the original channel.
  • Page 87 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 2.6 power spine umbilical cord Uninstall the top section of umbilical cord, put the bracket on the umbilical cord, then install the top section as below drawing show. Use screw ST6.3-38 to fix the bracket with ceiling.
  • Page 88 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE fix adapt on power spine, as below draw show. ceiling P detail step step ceiling P detail finish step ECO No:254-403-C Page: 88 OF 128 Rev: B Part No:7029-9682...
  • Page 89 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 3 Power hoop 3.1 screen Screen refer to 2.1 3.2 power hoop Install the hidden plate at the bottom of channel Drive in the screw as illustrated step Bottom channel Main channel stabilize foot...
  • Page 90 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Install hidden plate refer to Align two bottom channel as picture shown. use Bolt M8*95and net to fix the connection. Use M8*20 Screw the fix hidden plate with added channel. Fasten all screw. step...
  • Page 91 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Note: Do not move the twin-bottom channel at the end, need support in middle the height of hidden plate in leveling, the adjustable range is 30mm Install the connector with side channel, the pin of connector to insert in the channel slot...
  • Page 92 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Put the side channel’s rabbet outside, close up the bottom channel vertical, inset the protruding pin of connector into the rabbet of bottom channel Inset the screw from the inside of side channel, connect with bottom channel and lock it with nut.
  • Page 93 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Match the connector with the inclined plane of main channel Inset the protruding pin of connector into the rabbet of main channel Inset screw into the rabbet of connector, connect with main channel and lock with nut Connect the 2 installed main channel, close the 2 main channels and be sure they are on one level.
  • Page 94 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE connect main channel with side channel Inset the protruding pin of main channel into the groove of 2 side channels, lock with screw Main wire go through the bottom of bottom channel, pass side channel and reach main channel, then connect with wire board.
  • Page 95 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Install the side cover with side channel, up side blocked in the 2 insides of main channel, with gap no more than 1mm and no warp Install another side cover, same with step 21 Install bottom cover with bottom channel, gap no more than 1mm and no warp.
  • Page 96 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 3.2.2 Screen and power hoop assembly The inner installation of main channel of power hoop refer to the installation of power Install the screen on the inner bracket of power hoop, lock the bracket and support frame with screw another screen refer to step 1 and 2.
  • Page 97 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 3.3 power hoop and shelf Take apart the Flip top before install shelf as picture shown. Position the shelf bracket as picture shown. Align the Shelf bracket with adaptor bracket and fix them with screw M6*16.
  • Page 98 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 2.4.3 power hoop monitor arm Monitor arm and power hoop installation guide. Put insert into the groove of power hoop as step 1, then rotate the insert 90 degree. Put bracket on power hoop horizontal, keep the position of 4 hole with the hole of insert alignment, then fix the bracket with screw M6X14.
  • Page 99 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 3.6 power hoop joint kit to connect two Power hoop assembly together. Place 2 power hoop side by side as picture shown. Take off both side cover. Place the joint kit as picture shown and use 4 M6* 275 Screw to fix.
  • Page 100 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 5 power hoop core install Power hoop core before main channel installation. Install the gasket into the slot in bottom channel as picture shown. Put the core into the slot on top of gasket.
  • Page 101 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Clip the ceiling feed cover on ceiling channel. See detail for the clipping. Clip channel cover (ceiling feeding) on side channel，method is same as power hoop channel cover。 align two both ceiling feed,Put inserts into the side slot of the open storage, and then rotate 90 degrees.
  • Page 102 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE step step insert step finish Install ceiling feed top section. Assemble it on ceiling channel as picture shown and fix it with screw。 Top section step finish step ECO No:254-403-C Page: 102 OF 128...
  • Page 103 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4 configuration 4.1 new Bench Put the installed desk with caster on the side of main girder. The width side match other’s desk Put storage under each desk’s same side Put the desk and storage with caster on left side.
  • Page 104 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4.2 new cellular Insert the insert in the slot at side of main channel as picture shown. Fix the bracket with screw M6*14 with the insert. Put desk near the side of main girder, outside of desk match the cover of stand girder Connect power hoop and worktop with screw M6*20.
  • Page 105 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Put the screen on the middle of outside of desk (same side of power box) Align the screen bracket with worktop rim groove, lock them with worktop use screw M6*20. Put 4 storages under the outside of desk, be sure the side of worktop is matched the storage A向...
  • Page 106 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4.3 new mobile Put 2 desks on one side of power hoop, be sure to match the 2 side face of power hoop, put the power box outside of desk. Put 2 desks A on the middle of another side of power hoop, put on the side of power hoop tightly, put the power box inside of desk.
  • Page 107 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 7 Allways enhancements 7.1 Power hoop Up-mount Storage & Screen or Rail。 Up-mount Storage & Screen Up-mount Storage & Rail 1,fix the up-mount storage with the bracket with M4X10 screws. Total 4 places. The fixed place can reference the advised dimension as below.
  • Page 108 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE type 2: 2 kits 1000 mm storage. type 3: 1 kits storage. 2,fix the up-mount storage bracket with power hoop with M6X6 screws and inserts. Total 8 places. ECO No:254-403-C Page: 108 OF 128...
  • Page 109 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE adjust the position of the storage according to step 1. Then fix the storage as below.. 3, Assemble the screen or the rail A type:screen A-3.1 Assemble the screen with the bracket firstly. ECO No:254-403-C...
  • Page 110 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE A-3.2 fix the screen on the adapter plate with screws,same as the other power hoop screen, B type :rail B-3.1 fix the rail with the column with 4 pcs screws ,M6X 45,GB/T 70. ECO No:254-403-C...
  • Page 111 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE B-3.2 fix the rail with the bracket fix the bracket with 2 pcs screws,M6X23,GB/T 70 and washer. fix the bracket with 2 pcs screws,M6X23,GB/T 70 and washer. B-3.3 fix the end caps with rubber hammer B-3.4 finished assemble the rail...
  • Page 112 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE B-3.5 fix the rail on the power hoop. fix bracket with power hoop with M6X6 screws and inserts. Total 4 places. fix bracket with end bracket of power hoop with 2pcs M6X16,GB/T 70.3 and 1pcs long insert.
  • Page 113 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE B-3.7 finished.. 4, fix the power plate according to different types.(use the power logic plate type as sample) 2100mm power hoop with 1000 mm up-mount storage ECO No:254-403-C Page: 113 OF 128 Rev: B...
  • Page 114 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 2400mm power hoop with 1000 mm up-mount storage 3200mm power hoop with 800 mm up-mount storage ECO No:254-403-C Page: 114 OF 128 Rev: B Part No:7029-9682...
  • Page 115 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 3600mm power hoop with 1000 mm up-mount storage 4200mm power hoop with 1000 mm up-mount storage ECO No:254-403-C Page: 115 OF 128 Rev: B Part No:7029-9682...
  • Page 116 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 7.2 Power hoop Elevated Shelf & Screen 1.Fix 3 plates with beam with 6 PCS M6X16, GB/T 70.3 screws. M6X16 screws 2.Fix 2 Pcs column legs with the beam with M6 X45,GB/T 70 screws M6x45 screws 3.Fix the end brackets and the beam with M6 X23,GB/T 70 screws...
  • Page 117 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4.Fix the screens receiver with the beam with 4 pcs M4.8X25 ,GB/T 845 screws M4.8X25 screws 5.Fix the shelf and the bracket with 12 Pcs M6X16,GB/T 70.3 screws M6X16 screws 6.Fix the 2 end caps with the beam with rubber hammer...
  • Page 118 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 7.Fix the shelf assembly with the power hoop assembly with M6X16, GB/T 70.3 screws. fix bracket with end bracket of power hoop with 2pcs M6X16,GB/T 70.3 and 1pcs long insert. 8.Fix the end cover and side channel cover of the power hoop...
  • Page 119 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 7.3 Desk Shelf & Fabric Hung Screen 1,fix the AL shelf with 4 spacers. fix the AL shelf with the bar firstly with 8 M6X10 GB/T 70.3 screws ECO No:254-403-C Page: 119 OF 128...
  • Page 120 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 2,fix the AL shelf with the bracket with 2 M6X10 GB/T 70.3 screws. 3,fix the AL shelf with the bracket with 4 M6X25 GB/T 70.3 screws. ECO No:254-403-C Page: 120 OF 128 Rev: B...
  • Page 121 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE B-4,fix the bracket with the allways work top rim with 12 M6X16 GB/T 70.3 screws. B-5,finished. ECO No:254-403-C Page: 121 OF 128 Rev: B Part No:7029-9682...
  • Page 122 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 7.4 Elevated Rail 1.Fix the column leg and the beam with 4pcs M6 X45 ,GB/T 70 screws M6 X45 screws 2.Fix the beam and end bracket with 4 pcs M6 X23,GB/T 70 screws and washer 3.Fix the end cap with rubber hammer...
  • Page 123 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4.Fix the rail assembly with the power hoop assembly fix bracket with end bracket of power hoop with 2pcs M6X16,GB/T 70.3 and 1pcs long insert. 5.Fix the end cover and side channel cover. screws fixed 6.Fix flip top and power sockets.
  • Page 124 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 7.Fix the tools according to the requirement. ECO No:254-403-C Page: 124 OF 128 Rev: B Part No:7029-9682...
  • Page 125 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 8 Allways enhancements Service Parts Price List Part Number Description List Price (USD ) Qty per Pack 1044-4004 ADAPTER,ARM,MONITOR,CUBIT,SVC 1596-2302 BASE,UMBIL,POWER,DESK, 1596-2402 WGT,BASE,UMBILI,POWER,DESK,CUBIT,SVC 2378-2304 END CAP,SPINE,CUBIT,SVC 2421-2002 CASTER,LEG,DESK,CUBIT 2691-4202 CORD,UMIL,POWER,DESK,CUBIT,SVC 2923-0803 COVER,SUPPORT,FLOOR,PH,CUBIT,SVC 2923-1403 COVER,FABRIC,SADDLE,CUBIT,SVC...
  • Page 126 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Part Number Description List Price (USD ) Qty per Pack 1044-4004 ADAPTER,ARM,MONITOR,CUBIT,SVC 1596-2302 BASE,UMBIL,POWER,DESK, 1596-2402 WGT,BASE,UMBILI,POWER,DESK,CUBIT,SVC 2378-2304 END CAP,SPINE,CUBIT,SVC 2421-2002 CASTER,LEG,DESK,CUBIT 2691-4202 CORD,UMIL,POWER,DESK,CUBIT,SVC 2923-0803 COVER,SUPPORT,FLOOR,PH,CUBIT,SVC 2923-1403 COVER,FABRIC,SADDLE,CUBIT,SVC 2923-1503 COVER,GLASS,SADDLE,CUBIT, SVC 5361-0002 HINGE,FLIP TOP,PH,CUBIT,SVC 7090-4902...
