Summary of Contents for Black Diamond Equipment Recon LT
- Page 1 RECON LT INSTRUCTIONS Recon LT 09/2021 BlackDiamondEquipment.com M14184_A...
-
Page 2: Table Of Contents
Table of Contents Introduction ..............................3 Markings ..................................4 Liability ..................................4 Warranty conditions ..............................5 Manufacturer address & support ..........................5 Intended use ................................. 5 Target group and previous knowledge ......................... 5 Essentials ..................................6 Technical specifications ..............................6 Safety................................ -
Page 3: Introduction
– as explained in specialist publications and material from avalanche courses – must be followed. With the BLACK DIAMOND RECON LT you have a product that is state of the art in terms of safety and user- friendliness. Despite this, the BLACK DIAMOND RECON LT can pose risks if used inappropriately or incorrectly. We refer to possible hazards in chapter 2 and with safety notes placed throughout the operating manual. -
Page 4: Markings
1.1 MARKINGS In accordance with applicable regulations, the following marks may be found on the BLACK DIAMOND RECON LT or/and on the packaging: CE mark of conformity indicates fulfillment of relevant EU directives. See Chapter 7. Conformity. UKCA mark of conformity indicates fulfillment of relevant UK directives. See Chapter 7. Conformity. -
Page 5: Warranty Conditions
The manufacturer provides a 2-year warranty covering manufacturing and material defects of the BLACK DIAMOND RECON LT from the date of purchase. Exceptions are the battery, carrying system and bag as well as any damage caused by improper use or dismantling of the device by unauthorized persons. Any other warranties and liability for consequential damage are expressly excluded. -
Page 6: Essentials
1.7 ESSENTIALS The BLACK DIAMOND RECON LT meets the current state of technology and the applicable health and safety regulations. However, incorrect operation or misuse can give rise to hazards for: • the life and health of the users or third parties, •... -
Page 7: General Safety Rules And Obligations
• The BLACK DIAMOND RECON LT must only be used in perfect condition. • It is forbidden to alter or change the BLACK DIAMOND RECON LT without the written permission of Black Diamond Equipment. • Do not attempt to repair damage or malfunctions without authorization. Instead, contact our support, who will tell how to proceed. -
Page 8: Packaging
1x BLACK DIAMOND RECON LT • 1x Alkaline battery (in battery compartment) • 1x BLACK DIAMOND RECON LT carrying system • 1x Quick Start Guide Check that the contents are complete and undamaged after unpacking. If necessary, contact your point of sale or our support team. -
Page 9: Carrying System
If the self-check is successful, “OK” is indicated on the display (4B). In the event of a device warning, an alert signal sounds and the display indicates “E” in combination with a number (4E). For error codes, see chapter 6.1. Manual BLACK DIAMOND RECON LT 3 / 21... -
Page 10: Group Check
Despite a comprehensive self-check, a beacon check (transmit check and receive check) is obligatory prior to every tour! The BLACK DIAMOND RECON LT provides a group check function. In group check mode the receiving range is limited to 1 m. -
Page 11: Helpful Background Features
4.7.1 Secondary avalanche | Auto-Search-to-Send The BLACK DIAMOND RECON LT provides the feature Auto-Search-to-Send. By default, it is disabled and can be enabled in the PIEPS APP device manager. Once enabled, the device switches from search mode to send mode automatically after a certain time without change in motion (burial). -
Page 12: Search Mode | Search Strategy
Signal search (eyes + ears, beacon) • Coarse search (starting with initial signal) • Fine search (closer than 5 m on the surface) • Pinpointing (systematic probing) (4) Systematic digging (5) First Aid (6) Rescue Manual BLACK DIAMOND RECON LT 6 / 21... -
Page 13: Signal Search
Start searching in the primary search area for the initial signal detection as well as for visual/acoustic signals. The BLACK DIAMOND RECON LT has a circular receiving range that allows a correct indication of direction and distance from the point of initial signal detection – a specific method such as turning/rotating is not necessary. All signals of the burials that are within the maximum receiving range are received simultaneously. -
Page 14: Coarse Search
Follow the directional arrow quickly and check for a decreasing distance reading. Change the search direction by 180° in case of an increasing distance reading. Turn left Move straight ahead Turn right NOTICE Work calmly and with concentration in search mode. Avoid hasty movements! Manual BLACK DIAMOND RECON LT 8 / 21... -
Page 15: Fine Search
“probe guide” to ensure the probe follows a steady path. Follow a proven system until you have a hit. Communicate a hit clearly to companions. Leave the probe stuck for shoveling guidance. Manual BLACK DIAMOND RECON LT 9 / 21... -
Page 16: Multiple Burials | Mark Function
Signal without continuous wave Signal with continuous wave The BLACK DIAMOND RECON LT identifies a continuous wave and supports visually by flashing human figures. Manual BLACK DIAMOND RECON LT... -
Page 17: Device Management With The Pieps App
Bluetooth and the PIEPS APP allow a straightforward device management (e.g. software update) and additionally provide a handy training mode. Get the PIEPS APP (Android Play Store, iOS App Store), connect your BLACK DIAMOND RECON LT and take advantage of all features! To enable Bluetooth, press the button MARK (1D) while switching on the beacon. -
Page 18: Troubleshooting, Maintenance, Storage, Disposal
Bluetooth activation and/or connection not In case of a permanent error take the device to your possible. The avalanche beacon function is retailer. working. Is not checked during the self-check, occurs only during Bluetooth activation. Manual BLACK DIAMOND RECON LT 12 / 21... -
Page 19: Battery Replacement
Use a damp cloth without cleaning agents to clean the device. NOTICE Flowing water, steam or cleaning agents must not be used to clean the device. To do so could impede operation of the device. Manual BLACK DIAMOND RECON LT 13 / 21... -
Page 20: Storage
7. CONFORMITY EUROPE Black Diamond Equipment declares that the radio equipment type BLACK DIAMOND RECON LT is in compliance with Directives: EMC 2014/30/EU, RED 2014/53/EU, RoHS 2011/65/EU, LVD 2014/35/EU. Black Diamond Equipment declares that the radio equipment type BLACK DIAMOND RECON LT is in compliance... - Page 21 This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment and meets RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment has very low levels of RF energy that are deemed to comply without testing of specific absorption ratio (SAR). Manual BLACK DIAMOND RECON LT 15 / 21...
