U-Line S-12572 Quick Start Manual

S-12570, S-12571
S-12572, S-23878
3M HEADGEAR
3M protective headgear can only be used with 3M
faceshields. This headgear/faceshield combination is
designed to be used when the user is likely to come
in contact with flying particles and liquid splash as
long as use is consistent with all instructions, product
warnings and eye and face protection regulations
and standards.
Figure 1a
PAGE 1 OF 3
1-800-295-5510
uline.com
ASSEMBLY
1. Align the star shaped notches located on both ends
2. Rotate the faceshield towards the headgear making
3. Force the faceshield into the headgear until you
Figure 1b
Pour le français, consulter la page 3.
of the face shield onto the headgear. (See Figure 1a)
sure that the faceshield is in front of the flange.
(See Figure 1b)
hear it snap into place. (See Figure 2)
NOTE: To remove, pull back on the locking
mechanism tab until the star shaped holes are
aligned and remove the face shield.
Figure 2
Locking Mecha-
nism Tab
Para Español, vea página 2.
Flange
1121 IS-12572
