S-24402
3M VENTED HARD
HAT WITH UVICATOR™
WARNING! 3M H-700 Hard Hat provides LIMITED
head protection only. Misuse or failure to follow
warnings and user instructions may result in
serious personal injury or death. For proper
use, see supervisor, instructions or call Uline
Customer Service at 1-800-295-5510.
• This hard hat is designed to provide limited head
protection from small falling objects, such as small
tools, nuts and bolts, etc., striking the top of the
hard hat.
• Do not use for protection against larger objects,
severe impact or penetration, or for objects
traveling at accelerated speeds – avoid areas in
which these may be present.
• Do not rely on the hard hat to provide front, side or
rear impact protection.
• If the hard hat has sustained impact, dispose of it
immediately, even if damage is not visible.
• The hard hat must fit securely on the head and
suspension must be adjusted to a snug fit.
• Never alter, puncture, modify or engrave the shell
or the suspension.
• Do not use paints, solvents, chemicals, adhesives,
gasoline or like substances on this hard hat – doing
so can lessen the protection from impact and
penetration.
ELECTRICAL WARNING: Avoid areas where
the chance of severe electrical shock exists.
Vented helmets do not meet Class G (General)
or Class E (Electrical) requirements and provide
no electrical protection. Non-vented versions
meet Class G and E requirements as providing
limited electrical protection.
PAGE 1 OF 12
1-800-295-5510
uline.com
SAFETY
• Do not use this hard hat as a vehicular or
recreational hard hat.
• Do not store objects between the suspension
and the shell, as the hard hat will not function
as intended, and user will receive less head
protection.
• Exposure to direct sunlight and heat over time
can lessen the ability of the hard hat to withstand
impact and penetration. When possible, store hard
hat out of direct sunlight, including the dashboard
or rear window shelf of a vehicle, and extreme heat
over 120°F.
• Inspect the hard hat, including the suspension
and shell, before and after each use. Replace the
hard hat immediately if it shows any signs of wear,
damage, abuse or degradation. This may be a
sign that protection is reduced.
• Do not use by an open flame.
• Keep plastic bag out of the hands of infants and
children. It is not a toy, and infants and children
should not play with the bag. Wrapping of the bag
around or over the head can cause serious injury
or death.
3M hard hats meet ANSI/ISEA Z89.1-2014 Type I
requirements and CSA Z94.1-15 Type 1 requirements.
• Non-Vented Class G and E hard hats meet the
requirements of ANSI/ISEA Z89.1-2014 and CSA
Z94.1-15 as providing limited electrical protection.
• Vented Class C hard hats provide no electrical
protection.
Para Español, vea páginas 5-8.
Pour le français, consulter les pages 9-12.
CAUTION! Only 3M Hard Hat Accessories used
in conjunction with 3M Hard Hats have been
tested to applicable safety standards.
0921 IS-24402

Advertisement

loading
Need help?

Need help?

Do you have a question about the S-24402 and is the answer not in the manual?

Questions and answers

Summary of Contents for U-Line S-24402

  • Page 1 Para Español, vea páginas 5-8. Pour le français, consulter les pages 9-12. S-24402 1-800-295-5510 uline.com 3M VENTED HARD HAT WITH UVICATOR™ SAFETY • Do not use this hard hat as a vehicular or WARNING! 3M H-700 Hard Hat provides LIMITED recreational hard hat.
  • Page 2 ASSEMBLY Hard hats are shipped with suspension uninstalled to prevent distortion during shipping. The suspension must be installed according to these instructions and must be correctly adjusted to a snug fit in order to provide maximum protection. 1. Turn hard hat shell upside down on its crown. 2.
  • Page 3 ASSEMBLY CONTINUED REMOVING SUSPENSION REVERSE DONNING ORIENTATION (OPTIONAL) Place forefinger under the bend of a suspension key NOTE: Hard hats marked with a reverse donning and the thumb on the top of the key. Work key back arrow can be worn frontward or backward. and forth while pushing upward with some force.
  • Page 4: Maintenance

    ASSEMBLY CONTINUED INSPECTION AND REPLACEMENT • Inspect head suspension plastic parts for breaks, cracks or loss of flexibility. Inspect straps for fraying RECOMMENDATIONS or stitching that is loose or damaged. Replace Inspect the hard hat, including the suspension and suspension immediately if these or other signs of shell, before and after each use.
  • Page 5 S-24402 800-295-5510 uline.mx 3M CASCO DE SEGURIDAD VENTILADO CON UVICATOR™ SEGURIDAD • No utilice este casco como casco vehicular o ¡ADVERTENCIA! El Casco de Seguridad 3M recreativo. H-700 brinda solo protección LIMITADA para la cabeza. El uso indebido o el incumplimiento •...
  • Page 6 ENSAMBLE Los cascos se envían sin la suspensión instalada para evitar la distorsión durante los envíos. Debe instalar la suspensión de acuerdo con estas instrucciones y adaptarla a un ajuste preciso para que brinde la máxima protección. 1. Voltee la cubierta del casco copa abajo. 2.
  • Page 7 CONTINUACIÓN DEL ENSAMBLE RETIRO DE LA SUSPENSIÓN ORIENTACIÓN DE COLOCACIÓN INVERSA (OPCIONAL) 1. Coloque el dedo índice debajo de la inclinación de una llave de suspensión y el pulgar en la parte NOTA: Los cascos marcados con una flecha superior de la llave. Mueva la llave hacia adelante de colocación inversa se pueden poner hacia y atrás presionándola hacia arriba con algo de el frente o hacia atrás.
  • Page 8: Mantenimiento

    CONTINUACIÓN DEL ENSAMBLE RECOMENDACIONES DE INSPECCIÓN Y Diagrama 9 Sensor REEMPLAZO Inspeccione el casco, incluyendo la suspensión y la cubierta, antes y después de cada uso. Reemplace el casco de inmediato si nota alguna señal de desgaste, daños, maltrato o deterioro. Esto podría ser señal de que la protección se ha reducido.
  • Page 9 S-24402 1-800-295-5510 uline.ca 3M – CASQUE DE SÉCURITÉ VENTILÉ AVEC UVICATOR SÉCURITÉ • N'utilisez pas ce casque de sécurité ni comme AVERTISSEMENT! Le casque de sécurité H-700 de protection dans les véhicules ni pour les loisirs. ARRÊT 3M fournit uniquement une protection LIMITÉE de la tête.
  • Page 10 ASSEMBLAGE Les casques de sécurité sont expédiés avec la suspension non installée pour éviter toute déformation pendant le transport. La suspension doit être installée conformément à ces instructions et doit être correctement ajustée afin de fournir une protection maximale. 1. Tournez la coque du casque de sécurité à l'envers sur la calotte.
  • Page 11 ASSEMBLAGE SUITE RETRAIT DE LA SUSPENSION ORIENTATION DU PORT INVERSIBLE (OPTIONNEL) Placez votre index sous la courbure d'une des pattes REMARQUE : Les casques de sécurité marqués d'attache et votre pouce sur le dessus de la patte. d'une flèche de port inversible peuvent être Faites bouger la patte d'avant en arrière tout en portés vers l'avant ou vers l'arrière.
  • Page 12: Entretien

    ASSEMBLAGE SUITE RECOMMANDATIONS D'INSPECTION ET DE Figure 9 Détecteur REMPLACEMENT Inspectez le casque de sécurité, y compris la suspension et la coque, avant et après chaque utilisation. Remplacez immédiatement le casque s'il présente des signes d'usure, de dommage, d'un mauvais usage ou de dégradation.
