- Page 1 Installation Instructions Dual Sharkee FIND4/GPS[2]D4[W]/SHK[G]4[W]-6-60[-H][-Q][-D] SW3-1025- v1...
- Page 3 Content Installation Instructions Contact Information...
- Page 4 1. Introduction The FIND4/GPS[X]D4/SHK[G]4 series is a multi-function sharkfin style antenna with 4x4 MiMo for 4G/5G. The GPS[X]D4 incorporates either a single or multiple GPS/ GNSS antennas with 26dB gain LNA or a single L1/L2/L5 antenna with up to 37dB LNA gain. The GPS[X]D4 type features an M6 mounting stud for an optional comms whip.
-
Page 5: Fitting The Antenna
In all cases, the earthing washer must make low resistance electrical contact with the ground plane (<0.2 Ω).Select a mounting location, checking for roof curvature to ensure that the antenna base will have a flat mounting surface if possible. The antenna should be located as far as possible from surrounding roof mounted items (e.g light bar, air con unit). - Page 6 When fitting the nut, it is important to ensure that the cables are held centrally whilst the nut is correctly started on the threads. The nut should fit freely by hand and only requires a final tighten by spanner to a recommended torque of 5Nm.
- Page 7 Check that antenna is firmly secure to Assemble shakeproof washer mounting surface and that sealing boot edges and nut tighten to 5Nm. have splayed out into surface to form a seal 5. Routing and terminating coaxial cable(s) If heat shrink tubes are to be used, slide onto antenna cable tails prior to connecting extension cables – it is recommended that these are heat shrunk only after tests have been satisfactorily completed.
- Page 8 7. Notices CAUTION Consider relevant RF exposure rules. Ensure that the antenna is installed to provide a minimum separation distance of at least 20 cm (8”) from all persons during use. DO NOT • operate the transmitter when someone is within 20 cm (8”)of the antenna. •...
- Page 9 EN 300 440-1 V1.6.1 (2010-08) – Electromagnetic compatibility and radio spectrum matters (ERM); short range devices; radio equipment to be used in the 1GHz to 40GHz frequency range; Part 1: Technical characteristics and Test methods in accordance with EN 300 440-2 V1.4.1 (2010-8) - Electromagnetic compatibility and radio spectrum matters (ERM);...
-
Page 10: Contact Information
