Installation Instructions
6 or 8 Element Omni-Directional Antennas
DWMM8[X]-6-60 / DWMM6[X]-6-60
SW3-1184 - v1
1. Introduction
The DWMM8[X]-6-60-[X] and DWMM6[X]-6-60-[X] are antennas for fixed site applications using multiple mo-
dems. The DWMM8[X]-6-60-[X] supports dual 4x4 MiMo modems while the DWMM6[X]-6-60-[X] is suitable for
3x 2x2 MiMo applications.
Electrical Safety Note
DWMM8G-6-60-[X] / DWMM6G-6-60-[X] contain an active L1 Band GPS/GNSS antenna. Rated
voltage: 3-5VDC Rated current: 17mA maximum.
DWMM8G5-6-60-[X] / DWMM6G5-6-60-[X]contain an active L1/L5 Band GPS/GNSS antenna.
Rated voltage: 3-5VDC Rated current: 50mA maximum.
The supply to these devices must be provided with over current protection of 1A
maximum.
2. Planning and Installation
Choose an installation type and location. The antenna can be wall mounted using the four screw positions
or the supplied offset bracket. If mounting to internal walls like drywall, plasterboard or other non-conductive
surfaces then the antenna can be directy mounted to the wall. If mounting to concrete walls or walls contaning
pipes, wiring or foil backed insulation it is advised to use the offset bracket.
The antenna can be mounted to masts of 20-50mm (0.8" – 2") diameter using the supplied offset bracket and
mast mount clamps. It can also be desk or panel mounted mounted using the supplied pressed metal feet.
To minimize the effects of surrounding objects, the antenna should be located as far away from other objects
and structures as possible. If fitted with GPS/GNSS the antenna should have a clear view of the sky. The an-
tenna is omni-directional, so it does not need to be facing a particular direction. The orientation of the antenna
should be with the cables exiting downwards.
