XR-MP50
EZ
SERVICE MANUAL
COMPACT DISC
BASIC TAPE MECHANISM : 2ZM-1 R11NM
STEREO SYSTEM
BASIC CD MECHANISM : 3ZG-3 E13NM
REMOTE
SPEAKER
SYSTEM
CONTROLLER
SX–M510
XR–MP50
RC–AAT17
• This Service Manual is the "Revision Publishing" and replaces "Simple Manual"
XR-MP50 (EZ), (S/M Code No. 09-00B-439-6T1).
S/M Code No. 09-011-439-6R1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XR-MP50 and is the answer not in the manual?

Questions and answers

Related Manuals for Aiwa XR-MP50

Summary of Contents for Aiwa XR-MP50

  • Page 1 BASIC TAPE MECHANISM : 2ZM-1 R11NM STEREO SYSTEM BASIC CD MECHANISM : 3ZG-3 E13NM REMOTE SPEAKER SYSTEM CONTROLLER SX–M510 XR–MP50 RC–AAT17 • This Service Manual is the “Revision Publishing” and replaces “Simple Manual” XR-MP50 (EZ), (S/M Code No. 09-00B-439-6T1). S/M Code No. 09-011-439-6R1...

  • Page 2: Table Of Contents

    All manuals and user guides at all-guides.com TABLE OF CONTENTS SPECIFICATIONS ................................3 PROTECTION OF EYES FROM LASER BEAM DURING SERVICING ............... 4 PRECAUTION TO REPLACE OPTICAL BLOCK ......................4 DISASSEMBLY INSTRUCTIONS ..........................5 ~ 8 NOTES DURING RE-ASSEMBLING ..........................9 ELECTRICAL MAIN PARTS LIST ...........................

  • Page 3: Specifications

    All manuals and user guides at all-guides.com SPECIFICATIONS Main unit <General> <FM tuner section> Power requirements 230 V AC, 50 Hz Tuning range 87.5 MHz to 108 MHz Power consumption 90 W Usable sensitivity (IHF) 16.8 dBf Standby power consumption 1.0 W (power-economizing Antenna terminals 75 ohms (unbalanced) mode set to ON or AUTO)

  • Page 4: Protection Of Eyes From Laser Beam During Servicing

    All manuals and user guides at all-guides.com PROTECTION OF EYES FROM LASER BEAM DURING SERVICING This set employs laser. Therefore, be sure to follow carefully CAUTION the instructions below when servicing. Use of controls or adjustments or performance of procedures other than those specified herin may result in hazardous radiation expo- WARNING!! sure.

  • Page 5: Disassembly Instructions

    All manuals and user guides at all-guides.com DISASSEMBLY INSTRUCTIONS 1. Removing the outside appearance parts 1) Remove the six screws (1-4, 2-2) and remove the PANEL, SIDE R. 2) Remove the six screws (1-4, 2-2) and remove the PANEL, SIDE L. 3) Remove the three screws 1 and lift up the PANEL, TOP ASSY 2.
  • Page 6 All manuals and user guides at all-guides.com 5) Remove the 11 screws and remove the CABI, REAR. 6) Remove the screw and JOINT, CABI. 7) This is the state after the outside appearance parts are removed. 2. Removing the PWB, CD AFP-4 1) Remove the five screws, pull out the FFC and other parts, then remove the PWB, CD AFP-4.
  • Page 7 All manuals and user guides at all-guides.com 3. Removing the PWB, MAIN ASSY 1) Remove the screw 1, then remove the connector 2. 2) Remove the screw 1 and remove the PWB, MAIN ASSY 2 in the direction of the arrow. (The board is hooked. While lifting up the HOOK, remove the board.) 4.
  • Page 8 All manuals and user guides at all-guides.com 2) Remove the two screws 1 and remove the CABI, FR ASSY in the direction of arrow 2. 5. Removing the CD board (3ZG-3) 1) Remove the four screws 1 and remove the CD block 2. 2) This is the state after the CD block is removed.

  • Page 9: Notes During Re-Assembling

    All manuals and user guides at all-guides.com NOTES DURING RE-ASSEMBLING When assemble the magical change panel, adjust the phase of the gear. 1. Phase adjustment of the GEAR, OPE 1 and GEAR, WORM WHEEL. 1) Align holes 1. 2) Then, move the position of the holes of each gear as shown by 2 in the illustration. HLDR, GEAR GEAR, WORM WHEEL GEAR, OPE 1...

  • Page 10: Electrical Main Parts List

    All manuals and user guides at all-guides.com ELECTRICAL MAIN PARTS LIST REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 87-A40-270-080 C-DIODE,MC2838 87-A40-269-080 C-DIODE,MC2836 87-070-274-080 DIODE,1N4003 SEM 8A-FP4-608-030 C-IC,UPD784216AYGC-107-8EU 87-070-022-010 DIODE,IN5402 8A-AV6-605-030 C-IC,UT611024LC-12 87-A40-345-080 ZENER,MTZJ10C 87-A20-965-040 C-IC,S-80842ANNP-ED6 87-A21-021-040 C-IC,BU2099FV 87-A40-650-080...
  • Page 11 All manuals and user guides at all-guides.com REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C213 87-010-195-080 C-CAP,S 0.068-25 F C386 87-010-196-080 CHIP CAPACITOR,0.1-25 C214 87-010-195-080 C-CAP,S 0.068-25 F C388 87-012-156-080 C-CAP,S 220P-50 CH C215 87-012-368-080 C-CAP,S 0.1-50 F C389 87-010-380-080...
  • Page 12 All manuals and user guides at all-guides.com KANRI REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. DESCRIPTION FC502 8A-CJ4-648-210 FF-CABLE,14P 1.0 CNA401 88-802-092-420 CONN ASSY,9P RED FC504 88-906-201-110 FF-CABLE,6P 1.25 D151 87-A40-317-080 LED,SLR-342VCT31 RED H101 87-A90-511-010 HLDR,WIRE 2.5-10P D152 87-A40-317-080 LED,SLR-342VCT31 RED...
  • Page 13 All manuals and user guides at all-guides.com KANRI REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. DESCRIPTION C251 87-010-831-080 C-CAP,U,0.1-16F C759 87-016-459-080 CAP,E 470-10 SMG C252 87-010-831-080 C-CAP,U 0.1-16F C760 87-012-286-080 CAP, U 0.01-25 C253 87-010-382-080 CAP, ELECT 22-25V C762 87-010-831-080 C-CAP,U,0.1-16F...
  • Page 14 All manuals and user guides at all-guides.com REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION SOL2 82-ZM3-628-010 SOL ASSY,23 SO R892 87-022-198-080 C-RES,S680 1/10WF 87-036-110-010 SW,MICRO SPPB62 R893 87-022-360-080 C-RES,S 39K-1/10WF 87-036-110-010 SW,MICRO SPPB62 S801 87-A90-095-080 SW,TACT EVQ11G04M 87-036-110-010 SW,MICRO SPPB62...
  • Page 15 All manuals and user guides at all-guides.com KANRI REF. NO. PART NO. DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C828 87-010-196-080 CHIP CAPACITOR,0.1-25 C775 87-010-404-080 CAP,ELECT 4.7-50V C829 87-010-196-080 CHIP CAPACITOR,0.1-25 C776 87-012-286-080 CAP,U 0.01-25 C940 87-012-286-080 C-CAP,U 0.01-25 KB C777 87-010-493-080 CAP,E 0.47-50 M 5L SRE...

  • Page 16: Transistor Illustration

    All manuals and user guides at all-guides.com TRANSISTOR ILLUSTRATION E C B B C E E C B E C B CC5551 2SB1370 CSD655 2SC4115 CSA1585 2SB1625 CSB1058 2SD2494 CSC4115 KTA1266 KTC3198 E C B B C E 2SA1357 2SB1132 2SK543 (4/5) HN1C03FB DTA123JKA...

  • Page 17: Wiring - 1 (Main)

    All manuals and user guides at all-guides.com WIRING – 1 (MAIN) – 17 –...

  • Page 18: Schematic Diagram - 1 (Main / Pt1 / Pt2 / Head)

    All manuals and user guides at all-guides.com SCHEMATIC DIAGRAM – 1 (MAIN / PT1 / PT2 / HEAD) – 18 –...

  • Page 19: Wiring - 2 (Front / Sw - 1 / Sw - 2)

    All manuals and user guides at all-guides.com WIRING – 2 (FRONT / SW – 1 / SW – 2) – 19 –...

  • Page 20: Schematic Diagram - 2 (Front / Sw - 1 / Sw - 2 / Face - A / Face - B / Face - C / Deck)

    All manuals and user guides at all-guides.com SCHEMATIC DIAGRAM – 2 (FRONT / SW – 1 / SW – 2 / FACE – A / FACE – B / FACE – C / DECK) – 20 –...

  • Page 21: Wiring - 3 (Face - A / Face - B / Face - C)

    All manuals and user guides at all-guides.com WIRING – 3 (FACE – A / FACE – B / FACE – C) – 21 –...

  • Page 22: Wiring - 4 (Cd - Mp3) <1 / 2

    All manuals and user guides at all-guides.com WIRING – 4 (CD – MP3) <1 / 2> – 22 –...

  • Page 23: Wiring - 4 (Cd - Mp3 / Cd Load / Cd Drive) <2 / 2

    All manuals and user guides at all-guides.com WIRING – 4 (CD – MP3 / CD LOAD / CD DRIVE) <2 / 2> – 23 –...

  • Page 24: Schematic Diagram - 3 (Cd - Mp3 : 1 / 2 / Cd Load / Cd Drive)

    All manuals and user guides at all-guides.com SCHEMATIC DIAGRAM – 3 (CD – MP3 : 1 / 2 / CD LOAD / CD DRIVE) – 24 –...

  • Page 25: Schematic Diagram - 4 (Cd - Mp3 : 2 / 2)

    All manuals and user guides at all-guides.com SCHEMATIC DIAGRAM – 4 (CD – MP3 : 2 / 2) – 25 –...

  • Page 26: Wiring - 5 (Tuner)

    All manuals and user guides at all-guides.com WIRING – 5 (TUNER) – 26 –...

  • Page 27: Schematic Diagram - 5 (Tuner)

    All manuals and user guides at all-guides.com SCHEMATIC DIAGRAM – 5 (TUNER) – 27 –...

  • Page 28: Wiring - 6 (Pt1 / Pt2)

    All manuals and user guides at all-guides.com WIRING – 6 (PT1 / PT2) – 28 –...

  • Page 29: Wiring - 7 (Deck / Head)

    All manuals and user guides at all-guides.com WIRING – 7 (DECK / HEAD) – 29 –...

  • Page 30: Ic Block Diagram

    All manuals and user guides at all-guides.com IC BLOCK DIAGRAM – 30 –...
  • Page 31 All manuals and user guides at all-guides.com – 31 –...
  • Page 32 All manuals and user guides at all-guides.com – 32 –...

  • Page 33: Fl (13 - St - 44Gnk Acj - 4) Grid Assignment / Anode Connection

    All manuals and user guides at all-guides.com FL (13 44GNK ACJ 4) GRID ASSIGNMENT / ANODE CONNECTION – – – GRID ASSIGNMENT – 33 –...
  • Page 34 All manuals and user guides at all-guides.com ANODE CONNECTION – 34 –...

  • Page 35: Ic Description

    All manuals and user guides at all-guides.com IC DESCRIPTION IC, LC876572V-5S39 AFP-4 Pin No. Pin Name Description I-STEREO/I-DRF During TU FUNC, tuner stereo signal input / during CD FUNC, CD DSP IC DRF data input. O-BEEP Buzzer control. I-RDSDATA/ During TU FUNC, RDS serial data input / during CD FUNC, CD DSP IC command in O-CD-CE data output.
  • Page 36 All manuals and user guides at all-guides.com Pin No. Pin Name Description DEMO/P14 No demo (initial clock) setting switch input (not used) / FL segment output. Feature select switch 1&2 input / FL segment output. DOLBY B-NR F2/P13 F1/P12 B3/P11 Tuner band switch 3 input (not used) / FL segment output.
  • Page 37 All manuals and user guides at all-guides.com Pin No. Pin Name Description O-SREQ From MD unit serial data transfer request control output. (Not used) I-MREQ To MD unit serial data transfer request control input. – 37 –...
  • Page 38 All manuals and user guides at all-guides.com IC, UPD784216AYGC-107-8EU Pin No. Pin Name Description Digital out ON/OFF control H : ON. X2FLG Not used. DRVMUT Servo driver mute. CDDAMUT CDDA-DAC mute. LRMUT – Not used. DOUTON – Not used. 7, 8 –...
  • Page 39 All manuals and user guides at all-guides.com Pin No. Pin Name Description – Ground. SRAM / decode address. SRAM CS SRAM chip select. DEC CS Decode chip select. – Not connected. SRAM / decode read. SRAM / decode write. MP3RST IC, MAS3507D-G10 reset.
  • Page 40 All manuals and user guides at all-guides.com IC, DAC3550A-C2 Pin No. Pin Name Description AGNDC Analog reference voltage. AVSS1 VSS 1 for audio back-end. AVSS0 VSS 0 for audio output amplifiers. – Not connected. OUTL Audio output: headphone left or speaker +. (Not used) –...
  • Page 41 All manuals and user guides at all-guides.com Pin No. Pin Name Description FINR Input for FOUTR or filter OP-AMP output (line out). VREF Analog reference ground. IC, LC89513K Pin No. Pin Name Description – Ground. 2 ~ 8 RA0 ~ RA6 Address signal output to data buffer RAM pin.
  • Page 42 All manuals and user guides at all-guides.com IC, CXD2585Q Pin No. Pin Name Description – Digital power supply. XRST System reset. Reset at "L". MUTE Muting input. Mute at "H". (Connected to GND) DATA Serial data input from CPU. XLAT Latch input from CPU.
  • Page 43 All manuals and user guides at all-guides.com Pin No. Pin Name Description Tracking error signal input. Middle point servo analog input. RFDC RF signal input. ADIO Testing pin. (Not used) AGND – Analog GND. IGEN Constant current input for OP amplifier. AVDD –...
  • Page 44 All manuals and user guides at all-guides.com IC, MAS3507D-G10 Pin No. Pin Name Description Test Enable. (Connected to VSS) Reset, active low. I2CC C clock line. I2CD C data line. – Positive supply for digital parts. – Ground supply for digital parts. DCEN Enable DC/DC converter.
  • Page 45 All manuals and user guides at all-guides.com Pin No. Pin Name Description Start-up : clock output scaler on / off. Operation : MPEG CRC error. XVDD – Positive supply of output buffers. XVSS – Ground of output buffers. Serial input data. (Not used) Serial input frame identification.

  • Page 46: Adjustment (Tuner / Deck / Front)

    All manuals and user guides at all-guides.com ADJUSTMENT (TUNER / DECK / FRONT) < TUNER SECTION > 1. Clock Frequency Check 6. AM IF Adjustment Settings : • Test point : TP2 (CLK) Settings : • Test point : TP8 (Lch), TP9 (Rch) Method : Set to MW 1602kHz and check that the test •...
  • Page 47 All manuals and user guides at all-guides.com < DECK SECTION > 6. REC/PB Sensitivity Adjustment 1. Tape Speed Adjustment Settings : • Test tape : TTA–602 Settings : • Test tape : TTA–100 • Test point : TP8 (Lch), TP9 (Rch) •...

  • Page 48: Cd Test Mode

    All manuals and user guides at all-guides.com CD TEST MODE 1. How to Activate CD Test Mode While pressing the CD function button, insert the AC plug to the outlet. The message “CD TEST” appears on the display. 2. How to Cancel CD Test Mode Exit the CD test mode by any of the following procedures.

  • Page 49: Mechanical Exploded View 1 / 1

    All manuals and user guides at all-guides.com MECHANICAL EXPLODED VIEW 1 / 1 HT-SINK PWB PWB BINDER,WIRE 41 42 2ZM-1 DUST, CAP ZZA-1 3ZG-3 CHAS MAIN – 49 –...

  • Page 50: Mechanical Parts List 1 / 1

    All manuals and user guides at all-guides.com MECHANICAL PARTS LIST 1 / 1 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 1 8A-CJ4-042-010 WINDOW,SENSOR 46 86-ZG1-221-010 PULLEY,TT 2 8A-CJ4-017-010 KNOB,RTRY JOG 47 86-ZG1-231-010 SPR-C,WORM 3 8A-FP4-010-010 KNOB,RTRY MAIN 48 86-ZG1-225-010 BELT,SQ1.2-32.9...

  • Page 51: Tape Mechanism Exploded View 1 / 1

    All manuals and user guides at all-guides.com TAPE MECHANISM EXPLODED VIEW 1 / 1 SH, 1.63-3.2 -0.5 SLT HLDR, MOTOR PLATE, SHLD MOTOR HLDR, IC – 51 –...

  • Page 52: Tape Mechanism Parts List 1 / 1

    All manuals and user guides at all-guides.com TAPE MECHANISM PARTS LIST 1 / 1 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 1 82-ZM1-247-210 PULLEY,MOTOR 31 82-ZM1-240-110 LVR,REC(*) 2 82-ZM1-354-010 BELT,SBU MAIN2 EPDM 32 82-ZM1-241-310 LVR,MC 3 82-ZM1-234-310 FLY-WHL ASSY,L 33 82-ZM1-257-010...

  • Page 53: Cd Mechanism Exploded View 1 / 2 < 3Zg - 3 E13Nm

    All manuals and user guides at all-guides.com CD MECHANISM EXPLODED VIEW 1 / 2 < 3ZG – 3 E13NM > CUSH-G, MAIN CUSH-G, MAIN 3ZG-2 E3NM – 53 –...

  • Page 54: Cd Mechanism Parts List 1 / 2 < 3Zg - 3 E13Nm

    All manuals and user guides at all-guides.com CD MECHANISM PARTS LIST 1 / 2 < 3ZG – 3 E13NM > REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 1 83-ZG3-224-510 HLDR M2 16 86-ZG1-238-010 HLDR,MAGNET 6ZG N 2 83-ZG3-228-610 CHAS,L6 17 87-045-305-010...

  • Page 55: Cd Mechanism Exploded View 2 / 2 < 3Zg - 2 E3Nm

    All manuals and user guides at all-guides.com CD MECHANISM EXPLODED VIEW 2 / 2 < 3ZG – 2 E3NM > CD MECHANISM PARTS LIST 2 / 2 < 3ZG – 2 E3NM > REF. NO. PART NO. KANRI DESCRIPTION 1 83-ZG2-262-010 CHAS ASSY,E3 2 87-A90-836-010 PICKUP,KSS-213F...

  • Page 56: General Speaker Disassembly Instructions (For Reference)

    All manuals and user guides at all-guides.com GENERAL SPEAKER DISASSEMBLY INSTRUCTIONS (FOR REFERENCE) Type.1 Type.4 Insert a flat-bladed screwdriver into the position indicated by the TOOLS arrows and remove the panel. Remove the screws of each speaker 1 Plastic head hammer unit and then remove the speaker units.

  • Page 57: Speaker Parts List

    All manuals and user guides at all-guides.com SPEAKER PARTS LIST (SX – M510) REF. NO. PART NO. KANRI DESCRIPTION 1 8A-FP4-403-010 PANEL,FR FP 2 8A-FP4-404-010 PANEL,SP FP 3 8A-CJ4-405-010 PANEL,RING TW 4 8A-CJ4-406-010 GRILLE,FRAME ASSY L 5 8A-CJ4-410-010 SPKR,W 130 6 8A-CJ4-501-010 CORD,SP 7 8A-CJ5-417-010...
