- Page 1 XR-M25 COMPACT DISCSTEREO SYSTEM • BASIC TAPE MECHANISM 2ZM–1 YR6N • TYPE • BASIC CD MECHANISM 3ZG–3 YE1NM SIMPLE MANUAL • Replace this Service Manual with ”Revision Publishing” when it is issued. S/M Code No 09–984–261–5FP...
-
Page 2: Electrical Main Parts List
ELECTRICAL MAIN PARTS LIST NOTE: The characters in the suffix column indicate the part usage. 5KSC ....XX........A....5EZS ....XX........B....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 82-NF7-210-110 0E GUIDE,FL (*) AB....87-010-401-040 0E CAP,E 1-50 SME AB....87-010-178-080 0E CHIP CAP 1000P AB.... - Page 3 87-010-405-080 0E CAP, ELECT 10-50V AB....87-010-544-080 0E CAP, ELECT 0.1-50V AB....87-010-178-080 0E CHIP CAP 1000P AB....87-010-180-080 0E C-CER 1500P AB....87-010-993-080 0E C-CAP,S 0.056-25 B AB....87-012-155-080 0E C-CAP 180P-50CH AB....87-016-369-080 0E C-CAP,S 0.033-25 B K AB....
- Page 4 87-010-403-080 0E CAP, ELECT 3.3-50V AB....87-010-403-080 0E CAP, ELECT 3.3-50V AB....87-010-544-080 0E CAP, ELECT 0.1-50V AB....87-010-260-080 0E CAP, ELECT 47-25V AB....87-010-322-080 0E C-CAP,S 100P-50 CH AB....87-010-544-080 0E CAP, ELECT 0.1-50V AB....87-010-322-080 0E C-CAP,S 100P-50 CH AB....
- Page 5 87-010-263-080 0E CAP, ELECT 100-10V AB....87-010-263-080 0E CAP, ELECT 100-10V AB....87-010-184-080 0E CHIP CAPACITOR 3300P(K) AB....87-010-184-080 0E CHIP CAPACITOR 3300P(K) AB....87-010-195-080 0E C-CAP,S 0.068-25 F AB....87-010-195-080 0E C-CAP,S 0.068-25 F AB....87-010-374-080 0E CAP, ELECT 47-10V AB....
- Page 6 87-014-049-080 0E CAP,PP 470P-100 J AB....87-010-196-080 0E CHIP CAPACITOR,0.1-25 AB....87-010-197-080 0E CAP, CHIP 0.01 DM AB....87-010-197-080 0E CAP, CHIP 0.01 DM AB....87-010-311-080 0E CAP 12P AB....87-010-152-080 0E C-CAP,S 8P-50 CH ....87-010-196-080 0E CHIP CAPACITOR,0.1-25 AB....
- Page 7 87-010-197-080 0E CAP, CHIP 0.01 DM ....87-010-197-080 0E CAP, CHIP 0.01 DM ....87-010-405-080 0E CAP, ELECT 10-50V ....87-010-408-080 0E CAP, ELECT 47-50V ....87-010-194-080 0E CAP, CHIP 0.047 ....87-010-196-080 0E CHIP CAPACITOR,0.1-25 ....87-010-197-080 0E CAP, CHIP 0.01 DM ....
- Page 8 87-010-197-080 0E CAP, CHIP 0.01 DM .B....87-010-196-080 0E CHIP CAPACITOR,0.1-25 .B....87-010-197-080 0E CAP, CHIP 0.01 DM .B....87-010-314-080 0E C-CAP,S 22P-50V .B....87-010-316-080 0E C-CAP,S 33P-50 CH .B....87-010-405-080 0E CAP, ELECT 10-50V .B....87-010-405-080 0E CAP, ELECT 10-50V .B....
-
Page 9: Mechanical Parts List
A....88-CL4-064-010 KEY,POWER AB....88-CL4-066-010 KEY,GEQ D ....88-CL4-067-010 KEY,RDS .B....88-CL4-081-010 KNOB,RTRY VOL AB....88-CL4-082-010 KNOB,RTRY MIC AB....82-NE6-067-010 1A BADGE,AIWA 30N AB....88-CL4-051-010 WINDOW,DISP AB....88-CL4-052-010 WINDOW,CASS AB....88-CL4-053-010 WINDOW,TOP AB....88-CL4-054-010 WINDOW,DISP D ....88-CL4-085-010 LENS,RC AB.... -
Page 10: Accessories/Package List
87-CL4-762-010 0E SPKR CER TWEETER AB....87-CL4-763-010 SPKR, DUST CAP AB....87-CL4-764-010 1A CORD SPKR AB....88-CL4-761-010 SPKR, WOOFER AB....86-CT4-036-010 0E BADGE,AIWA AB....87-067-758-010 0E BVT2+3-12 W/O SLOT AB....87-761-097-410 0E VFT2+3-10 GLD AB....88-CL4-215-010 CUSH,FOOT FR AB....88-CL4-216-010 CUSH,FOOT REAR AB.... - Page 11 SCHEMATIC DIAGRAM _ 1 (MAIN 1/2)
- Page 12 SCHEMATIC DIAGRAM _ 2 (EZ : MAIN 2/2)
- Page 13 SCHEMATIC DIAGRAM _ 3 (K : MAIN 2/2)
- Page 14 SCHEMATIC DIAGRAM _ 4 (FRONT)
- Page 15 SCHEMATIC DIAGRAM _ 5 (CD)
- Page 16 SCHEMATIC DIAGRAM _ 6 (PT)
- Page 17 9630472 Tokyo Japan Printed in Singapore...
