Installation Instructions

Ducting Options

spaces between walls, crawl spaces, ceilings, attics, or garages.
All exhaust must be ducted to the outside, unless using the
►
Use single wall rigid metal ductwork only.
►
Fasten all connections with sheet metal screws and tape all joints w/ certified Silver Tape or Duct
Tape.
Rear ducting
Roof Pitch w/
Flashing & Cap
10
WARNING
Fire Hazard: NEVER exhaust air or terminate ductwork into
recirculating option.
