Neware BTS9 User Manual page 20

First, after the hardware is connected, use the client search function to search for the
device and ensure that the IP address is correct. Ensure that the first three segments of the IP address are the same and that
the last segment is different. Then, connect the TCP/UDP debugging tool to the corresponding device to perform debugging.
The specific operation process is as follows:
1. Hardware connection
Method of connecting the device as described in Section 2.6. After the device is connected, check the circuit, turn the
power on and start the device, and ensure the device indicator is on.
2. Equipment searching
Searching for devices from BTS software
1
Click device search button

You can select Mid-machine, Calibrate Tooling, and Multi-meter as required. Click the Search button to

display all online devices and related device information in the list.
Double-click the device list. The Set Device Information dialog box is displayed. You can change the MAC

address as required. Select the Automatically Obtain IP Address (DHCP) option box to automatically obtain
an IP address. As shown in the picture below, click the OK button to complete the modification.
The device IP address in the device information is the IP address of the mid-machine. The server's IP address

must be the same as the IP address of the PC.
Inside the BTS9000 high precision tester, every 8-channel are corresponding to a mid-machine. When searching for the
mid-machine through the client, the mid-machine with the same channels number and the same code will be found, as
shown in the figure below, multiple BTS9 devices on the mid-machine have been searched.
When using these devices, you need to change the server IP addresses of these channels to the IP addresses of the
current PC. After the modification, the four channels of the device will be activated. The client will map all these
device channels to the same mid-machine in the form of multiple channels of the mid-machine, as shown in the
following figure:
BTS User Manual
on BTS device list display area, the search dialog box will be displayed.
Figure 3-12 Equipment searching interface
Figure 3-13 Equipment searching interface
