User Manual
BTS9 Battery Test System
Manufacturer: Neware Technology Ltd.
Add: Shenzhen, Futian district, Excellent city, Tower 3, 15L
Tel: 0755-83108866
Website: http://www.newarebattery.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BTS9 and is the answer not in the manual?

Questions and answers

Related Manuals for Neware BTS9

Summary of Contents for Neware BTS9

  • Page 1 User Manual BTS9 Battery Test System Manufacturer: Neware Technology Ltd. Add: Shenzhen, Futian district, Excellent city, Tower 3, 15L Tel: 0755-83108866 Website: http://www.newarebattery.com...
  • Page 2 Warning: Risky practice that will possibly result a property loss, injury or death. ___________________________________________________________________________________________________________________ Instruction: Please read this manual carefully before using the BTS9.1 for better experience and maintain the performance of the battery test system. The document is subject to change due to the system's continual upgrading. © 2016 Neware.all rights reserved...
  • Page 3 Author Complete/Release Imprint data V1.0/Draft Qian Cao 2015-12-03 Create user manual file for BTS9 battery test system. Uploaded device model list, hardware installation description, V1.1/Draft Qian Cao 2015-12-14 modified operation of channels, modified automatic calibration section, and added FAQ. Add a conditional breakpoints and a function description for the loop number display.
  • Page 4 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Index Chapter 1. BTS9 Instruction....................4 1.1. Purpose of the Document..................................... 4 1.2. Scope of Application....................................4 1.3. Terminology......................................... 4 1.4. BTS9 Instruction......................................5 1.5. System Features......................................5 1.6. Models..........................................6 Chapter2 High Accuracy Tester....................7 2.1. BTS9000........................................7 2.2.

  • Page 5: Chapter 1 Bts9 Instruction

    Chapter 1 BTS9 Instruction Purpose of the Document 1.1. This document is designed for users and pre/after-sales technicians to understand the operation method of BTS9. By introducing the characteristics of the system, overall performance, and application scope of Battery Testing System 9 (BTS9).

  • Page 6: System Features

    The BTS9 battery test system is based on the existing office network and computer of enterprises, units, laboratories, and so on. The operation is simple. Users can remotely log in to the system through the Internet to perform various operations.
  • Page 7 12. Support automatic monitoring. If any abnormal situation occurs, the system automatically sends a report and an email notification to test technicians. Models 1.6. BTS9 battery test system can power-up the equipment below: BTS9000: BTS9002 High accuracy 2-channel tester ...

  • Page 8: Chapter 2 High Accuracy Tester

    Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Chapter 2 High Accuracy Tester This chapter is introduced the standard BTS9 battery test equipment. BTS9000 2.1. The channel of the BTS9000 mid-machine comes with the test channels, which can be used simultaneously to implement the mid/lower-machine functions, which are mainly used for high-precision battery testing.
  • Page 9 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com socket 6 Power supply port It can be connected to 220V power supply and 110V power supply. 7 Air outlet of For internal cooling. radiator fan Technical specifications of BTS9000 series equipment are shown in Form 3:...
  • Page 10 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com method Automatic continue Supported after power failure Hardware upgrade Supported AUX channels Supported Can be implemented by the latest software upgrades, but the paralleled channel is not Channel parallel capable of pulse discharge.

  • Page 11: Specification

    Neware Technology Ltd. BTS User Manual http://www.newarebattery.com CE-5008-20V30A is been used as an example to describe the basic device information. The following figure shows the front panel: Figure 2-3 CT-5008-20V30A Front view 1 Power switch Equipment starter/closer 2 Device Number...
  • Page 12 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Charge: 30mA~30A Output Discharge: 30mA~30A range/channel Current Accuracy ± 0.02% of range(full range) Stability 0.025% Output 600W Power power/channel Stability 0.05% Current response The hardware response time from current to 30A is 30ms...
  • Page 13 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Storage environment 30% ~ 90% RH(No condensation) humidity 12 / 94...
  • Page 14 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com SMBUS 2.3. The tester has a built-in communication module that supports SMBUS, I2C, and HDQ protocols. Which is capacle of real-time data sampling with the battery pack with frequency of 100KBPS. Its data transportation speed is 8-times faster that of traditional products, and it can obtain the real-time status of each cell and make step parameter adjustments more quickly and accurately.

  • Page 15: Connection Of Test Equipment

    This device uses a three-core power cord to connect to the power socket of the mid-machine and then to the grid. Attention: Please note that the input voltage. Grounding terminal is effectively grounded! Mid-machine connection The mid-machine is connected to the BTS9.1 upper-machine through TCP/IP port. Attention: Pay attention to fire prevention and keep away from flammable objects. Aux connection The aux is connected internally with the mid-machine to realize communication without external connection.

  • Page 16: Chapter 3 Installation And Maintenance

    Decompress the BTS.9.1.4 file, open the decompressed BTS91_SETUP file, and run Setup.exe as the administrator to go to the installation wizard page, as shown in Figure 3-2. User can select the Chinese or English version as required. Click Next button to enter BTS9.1.4 installation interface, as figure 3 - 3 shown: 15 / 94...
  • Page 17 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 3-2 Installation guide Figure 3-3 Software version check If you select "Manually specify the installed version directory," you can select a previous software installation directory to overwrite the installation. If you click Next, the Select Installation Content page is displayed. The installation wizard directly locates the directory that was installed before, but this directory must be empty before the next installation can be performed.
  • Page 18 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 3-6 Installation complete Complete the software installation If you select "Install Server" and "Install Backup Service" during personalized installation, check whether the options are correctly installed after the installation: Open“Control panel”→“Managing tools”interface.

  • Page 19: Hardware Maintenance

    Upgrade If the user has installed the elder version of BTS9 operation software, this software can be upgraded directly when compatible with the new version without uninstalling the current software. If they are incompatible, uninstall them first and then install the new version.
  • Page 20 Inside the BTS9000 high precision tester, every 8-channel are corresponding to a mid-machine. When searching for the mid-machine through the client, the mid-machine with the same channels number and the same code will be found, as shown in the figure below, multiple BTS9 devices on the mid-machine have been searched. Figure 3-13 Equipment searching interface When using these devices, you need to change the server IP addresses of these channels to the IP addresses of the current PC.
  • Page 21 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 3-14 BTS9004-GSM Successfully connected with computer Notice: The device search function searches only devices in the current network segment, not across routers. 20 / 94...

  • Page 22: Hardware Adjustment

    Neware Technology Ltd. BTS User Manual http://www.newarebattery.com The TCP/UDP tool searches for devices You can use the TCP/UDP tool to remove or add a device to a server. Start the TCP/UDP tool, enter the device IP address to be searched in the destination IP address box, set the corresponding device port number, select TCP Mode, connect to clients, and click Connect.
  • Page 23 Through the control panel or software directory “Uninstall.exe” program，you can un-install the software. Uninstall the software through the control panel. The steps are as follows: Click the "Start" menu "All Programs" "Neware" "Uninstall" Click to open As shown below, click Next to uninstall: Figure 3-17 Software delete interface After the software is uninstalled, manually clear the software folder to delete the software and test information.

  • Page 24: Chapter 4 Software Features

    Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Chapter 4 Software Features Start the Software 4.1. A BTS client is a human-computer interaction interface that can set and send commands to control devices. Real-time display of channel test data and status. you can query current and historical test data. To operate the device, you must open the client software in the following three ways: Click“Start”→“All program”→“Neware”→“Neware_BTS9_Client”.
  • Page 25 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 4-3 Search criteria setting Figure 4-4 Search result setting Notice: Delete Historical Data will delete the corresponding data index in the database and the corresponding NDA data. Data cannot be restored after being deleted. Therefore, use this function with caution.

  • Page 26: Channel Display Mode

    Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Search history zone History draw down button Collection Refresh Figure 4-7 Historical address display Device list display area: It is located on the left of the lower part of the toolbar. After the server is successfully connected, the searched devices are automatically displayed in this area to display all devices under the current server and their status (online and offline).

  • Page 27: List Display

    Neware Technology Ltd. BTS User Manual http://www.newarebattery.com area, and the voltage and current displayed are the range of the equipment; Other parameter names correspond to the parameter values of the channel on the right. The following figure shows that the current device is 5V6A.
  • Page 28 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 4-15 List customization Field sorting: Click on a data field, and the data can be sorted in ascending or descending order according to the field, as shown in the figure below: Figure 4-16 List customization List operation: Right-click list data to operate directly on the channel.
  • Page 29 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com 2. To select multiple discontinuous channels, hold down the Ctrl key and click the channel to be selected. 3. If multiple channels are selected, hold down the left mouse button and select the target channel.
  • Page 30 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 4-22 Breakpoints The set BreakPoints interface is as shown in the figure. In the figure, it indicates that the channel test stops after the discharging operation at the seventh step in the process. Click the Setup button to complete the setting. Users can also clear the current settings of BreakPoints.

  • Page 31: Channel Information

    Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 4-25 Channel migration setting You can select between channel migration, unit migration, and inter-service migration. In the destination channel option, fill in the destination channel (device number, unit number, and channel number).
  • Page 32 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com After selecting Disable Chl, the icon on the channel is Figure 4-27 Disable/Enable channel If a channel has been identified as disabled, you can use the Enable Chl to restore the channel, as shown in the preceding figure.
  • Page 33 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 4-29 Step copy Figure 4-30 Step paste Step reset Step reset: Namely dynamic modification step. This function can be used when the user needs to modify the step of the current channel during the test. The test data continues normally.
  • Page 34 Users can set the battery batch number and file description as required to facilitate data search and management. Types of step The BTS9 software supports the following step settings: Users can set cut-off conditions. When the cut-off condition is met, the step performs the jump operation. Multiple cut-off conditions can be set. The relationship between each cut-off condition is "or".
  • Page 35 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Charge the battery at a constant power set by the user. Voltage, current, time, capacity, and energy can be set as charging cut-off conditions. CP discharge Charge the battery at a constant power set by the user. Voltage, current, time, capacity, and energy can be set as charging cut-off conditions.
  • Page 36 Record condition Recording conditions of the BTS9 battery test system. The relationship between recording conditions and conditions is logical. As long as any condition is met during the test, the data will be recorded for once. Appropriate selection of recording conditions, such as long time intervals, can keep data files as small as possible but ensure that required data is not missed.
  • Page 37 Precise Query The BTS9 software supports precise queries of test data. Search criteria include device ID, channel row and column ID, bar code of the battery, start time, end time, step description, and a limit on the number of items to be queried. These conditions...
  • Page 38 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 4-39 Exact query condition Data Operation Users can right-click to open the channel information, query data, open data, save data, open folders, delete historical data, and so on. As shown below: Channel information: Open the Channel information corresponding to the relevant historical data.
  • Page 39 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 4-41 Manual report export Report Export Configuration The report export has two default configuration items. One is the RAW Report, which contains test information, step information, and record layer information. The other is the CYC report, which includes test information, step information, and cycle information.
  • Page 40 There are two ways to set the report export path. The first way is to modify the default report export path on the client:D:\Neware\Reports\ Figure 4-45. The second method is to modify the path on the report export screen, as shown in Figure 4-46.Name of the report export fileYou can insert the user name, battery batch number, battery model, test process,...
  • Page 41 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 4-45 Default path for exporting reports Figure 4-46 Report export directory Figure 4-47 Report export directory and name settings Set the filter criteria to filter reports based on the filter type (channel, barcode number, test name, battery model, battery batch number, and user name), name, and time.

  • Page 42: User Management

    Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Battery Barcode loading In the barcode entry configuration configured on the client, set the value of "barcode entry" to "Yes." Start the channel. In the dialog box that appears, enter the barcode for batteries or trays. You can import the barcode from a file or copy and...
  • Page 43 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com the user name, email address, and password, and click "Submit" to create a new user, as shown in the following figure: Figure 4-53 Add User Notice: On the Users management interface, you can define different user groups and their operation rights as required.
  • Page 44 Figure 4-55 Virtual device display Channel Display The BTS9 software supports the display of the main channel and Aux. You can also bind, delete, and locate Aux on the client interface as required. Display of main channels By default, the main channel is displayed based on the physical channel number (device number + unit number + channel number), as shown in the following figure.
  • Page 45 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Click the icon on the primary channel to view the mapping between the main channel and Aux. Alternatively, right-click a mapped Aux and choose Locate main Channel. As shown in Figure 4-59, the map Aux 12-1 to main channel 1-1.
  • Page 46 Figure 4-61 Upgrade setting window Notice: The *.enc file of the upgrade package is provided by NEWARE. The upgrade file automatically matches the up-gradable device, allowing you to upgrade the specified NUID device. You can select the upgraded device as your needs.
  • Page 47 The backup system can also be installed independently. If the backup system is installed independently, specify the data source. A BTS9 system server can back up only one backup system at a time. Configuration Users can set the backup mode and backup directory as required.
  • Page 48 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com The data can be restored only when the test is stopped, the data upload ends, and the backup service is stopped. After data restoration, historical data is still stored in the backup data and is not imported into the database. Restored test data is stored in the database.

  • Page 49: Chapter 5 Bts Software Configuration

    Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Chapter 5 BTS Software Configuration Click the setting button on the title bar, in the pop-up dialog box, users can operate "BTS Client", "barcode input", "Calibration", "Log", "Default step protection parameters", "Download Data", "Press bed parameters", "Server channel Calibration", "Server Log", "Small Icon Display configuration", and "Unit"...
  • Page 50 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 5-3 Calibration configuration Channel Color 5.4. Click the Channel Color option to set the color of the corresponding state of the client channel. For example, the color of channel when it charge, discharge, and rest. The color of channel when testing is finished, etc. As shown below, after...

  • Page 51: Data Download

    Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 5-5 Configuration of default step protection parameters Data Download 5.6. By clicking the "Data Download" option, the user can set the NDA export file directory, cache time, and other settings. You can customize the NDA export path as required, including the save directory and save name, as shown in Figure 5-6. The user-defined content includes the combination of user, batch number, process, channel, test ID, battery bar code, tray bar code, date, NUID of the mid-machine, and NUID of the unit.

  • Page 52: Import/Export Configuration

    Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 5-8 Other parameter configuration Import/Export Configuration 5.8. Import configuration: On the configuration management page, click Import Configuration. The dialog box for selecting a configuration file will be displayed. You can import the saved CONFIGURATION file in XML format to the current configuration page.

  • Page 53: Chapter 6 Btsda Data Analyzing Software

    Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Chapter 6 BTSDA Data Analyzing Software BTSDA----Battery Testing System Data Analyzeris the battery detection system's data analysis software, with a variety of data analysis and processing functions, through the curve-data-operation record associated way will curve and data display in one interface, intuitive and simple.
  • Page 54 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 6-2 Open data display interface Double-click“*.nda”file，start BTSDA.exe software to check and analysis the data. Features 6.2. BTSDA Interface BTSDA interface includes menu bar, toolbar, graphics area, data area and segmented preview, as shown below:...
  • Page 55 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 6-4 Diagram of curve-data association Data segment preview In a large amount of data with multiple cycles, the segmented data viewing tool can be used to realize the segmented data viewing with specific cycles. The operation method is as following: Double-click the yellow scroll bar at the bottom, labeled "Data segment Viewing tool,"...
  • Page 56 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Previous channel, next channel select Data area-step layer folding/unfolding tool DCIR setting tool Data area step layer expansion/collapse Data filtering tool Report export tool Data filtering Implement a data filtering function. Based on the original BTSDA9.0 version, the Mode 2 filtering mode has been added, as shown in Figure 6-6.
  • Page 57 Figure 6-9 and the corresponding image will be drawn. DCIR-P: Through the pulse discharge step, to calculate the internal resistance. Currently, only part of the BTS9 equipment has this function. Select the Pulse DCIR button to enter the pulse DCIR setting interface, as shown in...
  • Page 58 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 6-12 Curve setting Curve The point information on the curve is loaded layer by layer. After the point information for the first layer is obtained, the point information is loaded layer by layer in the background thread. At the same time, the customer can view the data of the current loaded layer and perform other operations.
  • Page 59 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 6-14 X-axis left/right movement zone Figure 6-15 Y-axis up/down movement zone Hold down Shift and scroll wheel to move the curve left and right.  Curve scaling and recovery Users can scale the curve in the following ways as required. Click the restore icon or right click Restore to restore the graph to the initial state.
  • Page 60 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 6-17 Data area hierarchical division Log indicator setting Click the "lamp" image on the left of the watch head, and the loglight can be set in the popup dialog, as shown below:...
  • Page 61 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 6-19 Data display Cycle layer header setting Select the loop layer data, click the table header, right click, and select the loop layer data field that you want to display, as shown below:...
  • Page 62 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 6-21 Step layer data setting interface Record layer header setting As shown below, select step layer data, click the table header, right click, and select the step layer data field to be...
  • Page 63 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 6-24 Step layer information Prompt information of recording layer: When the mouse is placed on the data line of recording layer, prompt information such as "cycle number/step number/step type" will appear, as shown below: Figure 6-25 Record layer information When using the vertical scroll bar in the data area to view data, the data will be a prompt message from "cycle...
  • Page 64 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 6-26 Scroll bar information Right-click function menu Right-click test data, fold/expand cycle layer/step layer/record layer data, set the relevant parameters, view channel information, log, etc. Folding/Unfolding: Users can fold/Unfold test data of the cyclic layer/step layer/recording layer according to different requirements, so as to facilitate data viewing and analysis.
  • Page 65 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 6-28 Time format Parameter setting: In the "Parameter Setting" option under the right-click function, users can set "unit setting," "cycle layer," "step layer," "record layer" and other parameters as required. Unit setting: Users can set the specific unit of data display as well as the quality of active substance and battery ...
  • Page 66 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 6-30 Cycle layer parameter setting Cycle layer statistical method: Including charge first after discharge/discharge first after charge/step default mode/user customized mode, users can test statistical cycle according to personal habits, that is, determine the content structure of each cycle layer.
  • Page 67 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 6-33 Channel information interface Log: In the data display area, right-click and choose Log to view accidental events and error information during the channel test. You can view different types of logs as required, as shown in the following figure: Figure 6-34 View log Step process: Right-click the data display area and choose Step Process from the drop-down list.
  • Page 68 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 6-35 Step process display window 67 / 94...

  • Page 69: Chapter 7 Automatic Calibration

    Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Chapter 7 Automatic Calibration In the device list, right-click the device number → choose Calibration to set the relevant calibration parameters, such as selecting the calibrated device, searching for the calibration tool, and manually adding the multi-meter, as shown in the following figure: The calibration system supports main channel calibration and auxiliary channel calibration.

  • Page 70: Calibration Mode

    Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 7-4 Calibrator channels display Notice: The calibration fixture selected must correspond to the channel in the device list bar one by one. Resistance of the shunt of calibrator The resistance value is the default value and cannot be modified. If the calibration fails, the administrator can modify the calibration.
  • Page 71 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com most. “In the calibration mode of "Calibrate first and then test accuracy", the current calibration points and voltage calibration points are "4-section calibration" by default, and the calibration points can also be modified to "9-section calibration"...

  • Page 72: View Result

    Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 7-12 Calibration/Test status information Status: It is divided into charging current, discharging current, charging voltage, discharging voltage and write KB value. When status is detected by calibration/test, the status is displayed in blue color. As shown in figure, it indicates that the current is the discharge current of calibration/test.
  • Page 73 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 7-14 Calibration history Viewing reports Click the View Report button to automatically jump to the CaliReport folder under the installation directory, as shown in Figure 7-15: Figure 7-15 View report CALI file: To store calibration report data. Double-click the calibration report to view the corresponding calibration...
  • Page 74 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 7-16 Data from the calibration report CHECK profile: It mainly stores equipment-precision testing data. Double-click the accuracy detection report to view the corresponding calibration data: channel number, calibration item, range, range percentage, control value, sampling...
  • Page 75 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 7-17 Accuracy test data Notice: You can set server channel calibration parameters in client configuration. For example, set the maximum and minimum values (ranging from 5~95) of the calibration point percentage, set the file format (PDF/EXCEL/TXT/ATL) of the calibration report, and set the validity days of the calibration/detection report.

  • Page 76: Chapter 8 Build Test Tutorial

    Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Chapter 8 Build Test Tutorial Introduction of step editor interface Figure 8-1 Step file storage path Test file storage (set the root directory and the project folder) File operation (Add, save, save as, delete)
  • Page 77 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure8-3 DBC file storage path The step editor can create two types of files: Figure 8-2, ending with an .njob file, and Figure 8-3, ending with a DBC communication (coulometer) configuration file. These two types of files are stored in the root directory and the storage path, which consists of the project name.
  • Page 78 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com from the coulometer) that is, the charging current is updated in real time according to the data in the coulometer. Figure 8-7: Cut-off conditions are DBC variables, that is, the voltage of the coulometer (gVoltage) > the set charging voltage (ChgVolt).
  • Page 79 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Tag Management 8.2. variable management interface mainly used edit custom expressions custom functions. Figure 8-8 The Variable Management The built-in variable area is the system's default setting and cannot be modified. Self-defining variable area, self-defining variables, independent storage space, and it can be modified.

  • Page 80: Display Settings

    Neware Technology Ltd. BTS User Manual http://www.newarebattery.com The port voltage and pull-up resistance must be configured based on the chip. Click here to add DBC variables. Refer to the chip manual, DBC variable are customizable and easy to recognize, and not able to have the same names as a built-in or custom variable.

  • Page 81: Record Setting

    Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 8-12 Display Setting Double-click to add display variables, double-click or select in the Select variables interface and confirm. The name displayed on the software channel icon The precision format is the data format to be displayed on the client interface. That is, the number of decimal points.
  • Page 82 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 8-14 Selection of Record Setting 81 / 94...
  • Page 83 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Detailed Description of Edit DBC(Voltameter infomation) 8.6. Introduction of how to use the step editor to setting DBC(coulometer) information. 1. DBC editing interface and parameters. Figure 8-15 Editing DBC 1.) #: Serial number 2.) Address (0x): This address is the battery cell communication address.
  • Page 84 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com 83 / 94...
  • Page 85 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com 2. Special data DBC (coulometer) editing scheme Here is the introduction of some special data editing method. 1.) Example of the use of multiway switches. When you need to input a fixed value to read the data, you can use the multiplexing switch function to operate the following operation process.

  • Page 86: Operation Process

    Neware Technology Ltd. BTS User Manual http://www.newarebattery.com 2.) When different positions in a string of data represent different information, you can practice the following operations. Figure 8-18 Manual of chip-BatteryMode As shown in the figure above: BatteryMode is a 16-bit, 2-byte data type. Each bit of BatteryMode represents a specific piece of information.
  • Page 87 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com 1.)Here is a sample test flow (Figure 8-20 shows the test process) 86 / 94...
  • Page 88 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 8-20 Test Requirement Process 2.)According to the test process above, create a new step file (named TEST1) in the main step row. Figure 8-21 Creating a Test file.njob 87 / 94...
  • Page 89 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com 3.) To start editing the step, save the step file and name it TEST1 (save button is in upper left corner). 4.) Import the DBC variable template. Figure 8-22 Import DBC file 4.)Regards there are variables that need to be customized in the step flow, we need to create them in variable management.
  • Page 90 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com 6.)Set up a complete step flow Figure 8-24 Step Flow Here we need to pay attention to step ②, including CC charging, CV charging, and step ③, CC and CV charging. The meaning of the two words is consistent, that is, CC and CV. The first CC is to reach the CV value and then CV. In step ④, a user-defined variable, VoltVar, is used as the voltage parameter, which is easy to understand and simple to operate.
  • Page 91 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Figure 8-26 Start Figure 8-27 DBC Information 90 / 94...
  • Page 92 Neware Technology Ltd. BTS User Manual http://www.newarebattery.com Q：Why the power-on indicator off after the device is connected? A：Check if the lower-machine is well connected with power source, and check if the lower-machine is functional. Q：What we should notice before changing the mid-machine? A：Pay attention to formatting data and deleting historical devices.

  • Page 93: Repair And Maintenance

    Our long-term customer investigation and after-sales service statistics show that equipment failure in many cases is caused by improper operation or incorrect maintenance methods. If the equipment does not work properly, you are advised to read the user manual of this product carefully or contact the customer service of Neware for consultation. After-sales Service Free technical training: Neware provides free technical training before and after sales.
  • Page 94 Contact NEWARE Thank you for using NEWARE products. We wish NEWARE products could become your great helpers. We provide you with various self-service methods to help you quickly solve most problems during device operation. In order to solve the problem quickly and effectively, we suggest you contact us in time through the following methods when you encounter problems.
