FrontRow CB6000 Installer's Manual page 11

b. With CM3000 as power source
WARNING: CONNECT THE CM3000 TO THE CB6000'S 'NETWORK ONLY' JACK!
YOU CAN DAMAGE YOUR DEVICES IF YOU CONNECT TO THE 'AUX' JACK.
CB6000
Control
NOTE: This is a schematic illustration
intended to clarify the relationship of
components to each other. The location
of jacks shown here may not reflect their
true position on specific devices.
c. With TB14 as power source
WARNING: CONNECT THE TB14 TO THE CB6000'S 'AUX' JACK! YOU CAN
DAMAGE YOUR DEVICES IF YOU CONNECT TO THE 'NETWORK ONLY' JACK.
Adapter
NOTE: This is a schematic illustration
intended to clarify the relationship of
components to each other. The location
of jacks shown here may not reflect their
true position on specific devices.
Power
NETWORK CLAN3
CM3000
Amplifier/Switch
Panel
or Soundpost
Power
AUX AUX
CB6000
TB14
Control
Panel
LAN1 NETWORK
Computer
Cat 5 cable
Other cable
NETWORK NETWORK
Control cable
Signal + control
Computer
ezRoom mounting plate
Cat 5 cable
Crossover cable
Other cable
8
