Reach In Coolers and Freezers
Models RE-CN-0021-HC, 0041-HC, 0067-HC,
FR-CN-0737-HC, 1372-HC, 2057-HC
Items 50024, 50026, 50028, 50023, 50025, 50027
Instruction Manual
Revised - 02/01/2022
Toll Free: 1-800-465-0234
Fax: 905-607-0234
Email: service@omcan.com
www.omcan.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RE-CN-0021-HC and is the answer not in the manual?

Questions and answers

Related Manuals for Omcan RE-CN-0021-HC

Summary of Contents for Omcan RE-CN-0021-HC

  • Page 1 Reach In Coolers and Freezers Models RE-CN-0021-HC, 0041-HC, 0067-HC, FR-CN-0737-HC, 1372-HC, 2057-HC Items 50024, 50026, 50028, 50023, 50025, 50027 Instruction Manual Revised - 02/01/2022 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com...

  • Page 2: Table Of Contents

    Table of Contents Model RE-CN-0021-HC / Model RE-CN-0041-HC / Model RE-CN-0067-HC Model FR-CN-0737-HC / Model FR-CN-1372-HC / Model FR-CN-2057-HC Section Page Disclaimer --------------------------------------------------------------------------------------------------- 3 General Information ---------------------------------------------------------------------------------- 4 - 5 Safety and Warranty --------------------------------------------------------------------------------- 5 - 7 Technical Specifications ---------------------------------------------------------------------------- 7 - 8...

  • Page 3: Disclaimer

    Disclaimer OMCAN IS NOT RESPONSIBLE FOR DIMINISHED COOLING OR ANY DAMAGES DUE TO WATER LEAKS. WARRANTY IS VOID IF THE AMBIENT ROOM TEMPERATURE EXCEEDS 75°F AND 55% RELATIVE HUMIDITY, AND THE APPLIANCE DRAIN IS NOT CONNECTED DIRECTLY TO A FLOOR DRAIN.

  • Page 4: General Information

    If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents.

  • Page 5: Safety And Warranty

    Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia.
  • Page 6 2 YEARS PARTS AND LABOUR / 5 YEARS PARTS ONLY ON COMPRESSOR WARRANTY Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule an Omcan authorized service technician to repair the equipment locally. Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures, not improper use.

  • Page 7: Technical Specifications

    In any case, for suitable recycling, we suggest disposing of the products separately (differentiated waste) according to the current norms. DO NOT DISCARD ANY PACKAGING MATERIALS IN THE ENVIRONMENT! Technical Specifications REACH IN COOLERS Model RE-CN-0021-HC RE-CN-0041-HC RE-CN-0067-HC Net Volume 650 L / 23 cu.ft. 1321 L / 47 cu.ft.

  • Page 8: Installation

    Technical Specifications REACH IN FREEZERS Model FR-CN-0737-HC FR-CN-1372-HC FR-CN-2057-HC Net Volume 650 L / 23 cu.ft. 1321 L / 47 cu.ft. 2040 L / 72 cu.ft. Temperature Range -22 to -18°C / -8 to 0°F Max Ambient Temp 32°C / 90°F Rating Horsepower 1/2+ HP...
  • Page 9 Installation CABINET LOCATION GUIDELINES • Install the unit on strong and leveled surfaces - unit may make unpleasant noises if surface is uneven - unit may malfunction if surface is uneven • Install the unit in an indoor, well-ventilated area - unit performs more efficiently in a well-ventilated area - for best performance, please maintain clearance of 6”...

  • Page 10: Maintenance

    Maintenance CLEANING THE CONDENSER COIL • For efficient operation, it is important that the condenser surface be kept free of dust, dirt, and lint. • We recommend cleaning the condenser coil and fins at least once per month. • Clean with a commercial condenser coil cleaner, available from any kitchen equipment retailer. Brush the condenser fins from top to bottom, not side to side.

  • Page 11: Troubleshooting

    Troubleshooting Before requesting any service on your unit, please check the following points. Please note that this guide serve only as a reference for solutions to common problems. SYMPTOM POSSIBLE CAUSE CORRECTIVE ACTION Compressor not running. Fuse blown or circuit breaker Replace fuse or reset circuit tripped.
  • Page 12 Troubleshooting Cabinet Temperature Is too warm. Thermostat set too warm. Set thermostat to lower Temperature. Blocking air flow. Re-arrange product to allow for Proper air flow. Make sure there Is at least four inches of clearance from evaporator. Excessive amount of warm product Allow adequate time for product to Placed in cabinet.

  • Page 13: Controller Instructions

    Controller Instructions Digital controller model: PJEZ for cooler Display and functions During normal operation, the controller displays the value of the probe set using parameter/4(=1 ambient probe, default, = 2 second probe, = 3 third probe).In addition, the display has LEDs that indicate the activation of the control functions (see Table 1), while the 3 buttons can be used to activate/deactivate some of the functions(see Table 2).
  • Page 14 Controller Instructions Table of Functions activated by the buttons - Models S, X, Y, C (Table 2) Button Normal Operation Start Up Pressing the Button Alone Pressed Together More than 3 sec: toggle ON/ Start/Stop ON/OFF continuous cycle Down More than 3 sec: start/stop Pressed For 1 sec.
  • Page 15 Controller Instructions • To display/set the values of the parameter displayed, press SET, then UP/DOWN and finally SET to confirm the changes (returning to the parameter menu). To save all the new values and exit the parameter menu, press SET for 3 s. To exit the menu without saving the changed values (exit by timeout) do not press any button for at least 60 s.
  • Page 16 Controller Instructions Light Auxiliary output light Auxiliary output light Anti-sweat heater function active not active active Service No malfunction Malfunction (eg. EEPROM error or probe fault) HACCP HACCP function HACCP function HACCP alarm (HA and/or enabled HF) not enabled Continuous Enabled Not enabled Request...
  • Page 17 Controller Instructions Accessing the configuration parameter (type F) 1. Hold the “ ” button for more than 5 s (if there are active alarms, first mute the buzzer), the display will show the first modifiable “F” parameter. Modifying the parameters After having displayed the parameter, either type “C”...

  • Page 18: Parts Breakdown

    Parts Breakdown Model RE-CN-0021-HC 50024...
  • Page 19 Parts Breakdown Model RE-CN-0021-HC 50024 Item No. Description Position Item No. Description Position Item No. Description Position AJ129 Cabinet for 50024 AG448 Evaporator Fan Motor for 50024 20, 36 AB595 Filter Fixer for 50024 AJ130 Control Panel for 50024 AB109...
  • Page 20 Parts Breakdown Model RE-CN-0041-HC 50026...
  • Page 21 Parts Breakdown Model RE-CN-0041-HC 50026 Item No. Description Position Item No. Description Position Item No. Description Position AJ133 Cabinet for 50026 AG552 Inner Drain Pan for 50026 AA764 Condenser Fan Motor Blade for 50026 42, 56 Left Evaporator Fan Motor Holder for AJ134 Control Panel for 50026 AG447...
  • Page 22 Parts Breakdown Model RE-CN-0067-HC 50028...
  • Page 23 Parts Breakdown Model RE-CN-0067-HC 50028 Item No. Description Position Item No. Description Position Item No. Description Position AJ147 Cabinet for 50028 AG568 Evaporator for 50028 AA764 Condenser Fan Motor Blade for 50028 44, 63 AJ148 Control Panel for 50028 AG569 Inner Drain Pan for 50028 AG556 Condenser Fan Cover for 50028...
  • Page 24 Parts Breakdown Model FR-CN-0737-HC 50023...
  • Page 25 Parts Breakdown Model FR-CN-0737-HC 50023 Item No. Description Position Item No. Description Position Item No. Description Position Temperature Sensor of Cabinet Inside AJ129 Cabinet for 50023 AA124 Power Switch for 50023 AG455 for 50023 Evaporator Temperature Sensor for AJ130 Control Panel for 50023 AG449 Evaporator Cover for 50023 AJ151...
  • Page 26 Parts Breakdown Model FR-CN-1372-HC 50025...
  • Page 27 Parts Breakdown Model FR-CN-1372-HC 50025 Item No. Description Position Item No. Description Position Item No. Description Position AJ133 Cabinet for 50025 AG553 Evaporator Cover for 50025 AJ159 Compressor for 50025 AJ134 Control Panel for 50025 AA324 Thermostat for 50025 AJ160 Parts of Compressor for 50025 AF048 Front Grill for 50025...
  • Page 28 Parts Breakdown Model FR-CN-2057-HC 50027...
  • Page 29 Parts Breakdown Model FR-CN-2057-HC 50027 Item No. Description Position Item No. Description Position Item No. Description Position AJ147 Cabinet for 50027 AG448 Evaporator Fan Motor for 50027 AF067 Compressor for 50027 AJ148 Control Panel for 50027 AG570 Evaporator Cover for 50027 AJ163 Parts of Compressor for 50027 AF060...

  • Page 30: Electrical Schematics

    Electrical Schematics Model RE-CN-0021-HC 50024 Model RE-CN-0041-HC 50026...
  • Page 31 Electrical Schematics Model RE-CN-0067-HC 50028 Model FR-CN-0737-HC 50023...
  • Page 32 Electrical Schematics Model FR-CN-1372-HC 50025 Model FR-CN-2057-HC 50027...

  • Page 33: Notes

    Notes ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________...
  • Page 34 Notes ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________...

  • Page 35: Warranty Registration

    Warranty Registration Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below. You can also register online by visiting: Merci d’avoir acheté...
  • Page 36 Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North American food service industry. Our success over these many years can be attributed to our commitment to strengthen and develop new and existing relationships with our valued customers and manufacturers.
