Ice Cream Dipping Freezers
Models FR-CN-0160-S, 0260-S, 0360-S, 0460-S, 0560-S
Items 44590, 48657, 44588, 44589, 48648
Instruction Manual
Revised - 02/25/2025
Toll Free: 1-800-465-0234
Fax: 905-607-0234
Email: service@omcan.com
www.omcan.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the FR-CN-0160-S and is the answer not in the manual?

Questions and answers

Related Manuals for Omcan FR-CN-0160-S

Summary of Contents for Omcan FR-CN-0160-S

  • Page 1 Ice Cream Dipping Freezers Models FR-CN-0160-S, 0260-S, 0360-S, 0460-S, 0560-S Items 44590, 48657, 44588, 44589, 48648 Instruction Manual Revised - 02/25/2025 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com...

  • Page 2: Table Of Contents

    Table of Contents Model FR-CN-0160-S / Model FR-CN-0260-S / Model FR-CN-0360-S Model FR-CN-0460-S / Model FR-CN-0560-S Section Page Disclaimer ------------------------------------------------------------------------------------------------------ 3 General Information --------------------------------------------------------------------------------- 4 - 5 Safety and Warranty --------------------------------------------------------------------------------- 5 - 7 Technical Specifications ------------------------------------------------------------------------------- 7 Installation ---------------------------------------------------------------------------------------------------- 8...

  • Page 3: Disclaimer

    Disclaimer OMCAN IS NOT RESPONSIBLE FOR ANY DAMAGES DUE TO WATER LEAKS. WARRANTY FOR WATER LEAKS IS VOID IF THE WICKING PAD IS NOT REPLACED EVERY SIX MONTHS, AND IF THE AMBIENT ROOM TEMPERATURE EXCEEDS 75°F AND 55% RELATIVE HUMIDITY, AND THE APPLIANCE DRAIN IS NOT CONNECTED DIRECTLY TO THE FLOOR DRAIN.

  • Page 4: General Information

    If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents.

  • Page 5: Safety And Warranty

    Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia.
  • Page 6 1 YEAR PARTS AND LABOUR WARRANTY Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule an Omcan authorized service technician to repair the equipment locally.

  • Page 7: Technical Specifications

    Safety and Warranty according to the current norms. DO NOT DISCARD ANY PACKAGING MATERIALS IN THE ENVIRONMENT! Technical Specifications Model FR-CN-0160-S FR-CN-0260-S FR-CN-0360-S FR-CN-0460-S FR-CN-0560-S Item Number 44590 48657 44588 44589 48648 Freezer 120 L / 4.23 cu.ft. 210 L / 7.4 cu.ft.

  • Page 8: Installation

    Installation GLASS CANOPY ASSEMBLY INCLUDED HARDWARE • 1 - Front Rail. • 2 - Side Rails. • 4 - Metal Plate for Side Rails. • 8 - L-Shaped Brackets. • 11 - Screws and Metal Washers for Rails. • 20 - Fasteners for Glass Panels. Note: if the fasteners are loose after assembling, you may fasten it with the white washer.

  • Page 9: Maintenance

    Maintenance • The freezer should be cleaned regularly. When cleaning, turn off the power, take out the food in the cabinet, clean the inside using water or a little neutral detergent. • Do not use boiling water, acid, chemical diluents, petrol and oil, or dirt-removing powder. •...
  • Page 10 Troubleshooting The compressor works normally, The door is opened too frequently. Reduce open times. but the temperature in the cabinet The food in the cabinet is too Place foods properly, keep space lowers too slowly. much, or placed improperly. between them for ventilation of cold air.

  • Page 11: Parts Breakdown

    Parts Breakdown Model FR-CN-0160-S 44590...
  • Page 12 Parts Breakdown Model FR-CN-0160-S 44590 Item No. Description Position Item No. Description Position Item No. Description Position 69421 Upper Glass Door for 44590 64766 Thermostat Support for 44590 28448 Plug Series for 44590 41162 Key/Lock for 44590 39587 Indicator Lamp for 44590...
  • Page 13 Parts Breakdown Model FR-CN-0260-S 48657...
  • Page 14 Parts Breakdown Model FR-CN-0260-S 48657 Item No. Description Position Item No. Description Position Item No. Description Position Upper Glass Door Assembly for AU389 AU394 LED Light for 48657 AU399 Power Supply Cord for 48657 48657 AN963 Key and Lock for 48657 AI315 Plastic Cover (2 Tubs) for 48657 39586...
  • Page 15 Parts Breakdown Model FR-CN-0360-S 44588 Model FR-CN-0460-S 44589...
  • Page 16 Parts Breakdown Model FR-CN-0360-S 44588 Item No. Description Position Item No. Description Position Item No. Description Position 69423 Upper Glass Door for 44588 64766 Thermostat Support for 44588 28448 Plug Series for 44588 41162 Key/Lock for 44588 39587 Indicator Lamp for 44588 AE623 Compressor Feet for 44588 69424...
  • Page 17 Parts Breakdown Model FR-CN-0460-S 44589 Item No. Description Position Item No. Description Position Item No. Description Position 69425 Upper Glass Door for 44589 69433 Thermostat Support for 44589 69442 Power Cord for 44589 69426 Key for 44589 69434 Indicator Lamp for 44589 AE638 Compressor Feet for 44589 69427...
  • Page 18 Parts Breakdown Model FR-CN-0560-S 48648...
  • Page 19 Parts Breakdown Model FR-CN-0560-S 48648 Item No. Description Position Item No. Description Position Item No. Description Position AC120 Screws for Rails for 48648 AN922 Fan Bracket for 48648 AN973 Compressor Protector for 48648 AN960 Tie Bar for 48648 AN923 M6x14 Tapping Screw for 48648 AN974 Compressor Housing for 48648 Upper Glass Door Assembly for...

  • Page 20: Electrical Schematics

    Electrical Schematics Model FR-CN-0160-S 44590 Model FR-CN-0360-S 44588 Model FR-CN-0460-S 44589...
  • Page 21 Electrical Schematics Model FR-CN-0260-S 48657 Model FR-CN-0560-S 48648...

  • Page 22: Notes

    Notes ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________...

  • Page 23: Warranty Registration

    Warranty Registration Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below. You can also register online by visiting: Merci d’avoir acheté...
  • Page 24 à plus de 6500 produits provenant du monde entier. Desde 1951 Omcan ha crecido hasta convertirse en un líder en la distribución de equipos y suministros de alimentos en América del Norte industria de servicios. Nuestro éxito en estos años se puede atribuir a nuestro compromiso de fortalecer y desarrollar nuevas relaciones...
