Installation and Setup

Mounting the FOX 2G Tx/Rx AV

The 1U high, quarter rack wide units can be placed on a
tabletop, mounted in a rack, or mounted under or through
a desk or other furniture. In addition, the receiver can be
mounted close to a projector, using the Extron PMK 350
(PN 70-563-0x).

Tabletop placement

Attach the four included rubber feet to the bottom of the unit
and place it in any convenient location.

Rack Mounting

UL guidelines for rack mounting

The following Underwriters Laboratories (UL) guidelines are
relevant to the safe installation of the FOX 2G Tx/Rx AV in a
rack:
1.
2.
3.
4.
5.
FOX 2G Tx/Rx AV • Installation and Setup
2-2
Elevated operating ambient temperature — If the unit
is installed in a closed or multi-unit rack assembly, the
operating ambient temperature of the rack environment
may be greater than room ambient temperature. Therefore,
install the equipment in an environment compatible with
the maximum ambient temperature (Tma: +122 °F, +50 ° C)
specified by Extron.
Reduced air flow — Install the equipment in the rack
so that the equipment gets adequate air flow for safe
operation.
Mechanical loading — Mount the equipment in the rack
so that uneven mechanical loading does not create a
hazardous condition.
Circuit overloading — Connect the equipment to
the supply circuit and consider the effect that circuit
overloading might have on overcurrent protection and
supply wiring. Give appropriate consideration to the
equipment nameplate ratings when addressing this
concern.
Reliable earthing (grounding) — Maintain reliable
grounding of rack-mounted equipment. Pay particular
attention to supply connections other than direct
connections to the branch circuit (such as the use of power
strips).
