GRASS BAGGER ASSEMBLY AND INSTALLATION
1. Remove the two attachment mounting covers from the mower to expose two mounting holes (Fig. 8). Place the
attachment mounting covers in the storage compartment of your mower.
2. Insert the posts into the mounting holes of the mower as shown (Fig. 9).
8
Attachment
Mounting
Cover Storage
3. Lift the top cover assembly above the posts and lower it so that the upper tips of the posts are inserted into the top
cover assembly as shown (Fig. 10). To simplify the process, it is recommended that two persons perform this step.
Insert two lock pins into the holes and secure them with the retention pins (Fig. 11).
WARNING: Use of this product with improperly secured bolts could result in serious personal injury.
10
10
GRASS BAGGER KIT — ABK5200
Attachment Mounting Covers
9
Post
Storage
Compartment
Mounting Hole
11
