- Page 1 IHB EN 2143-3 INSTALLER MANUAL 531854 HRV unit NIBE ERS S40-350...
-
Page 3: Table Of Contents
General ventilation connections Ventilation flow Adjusting ventilation Dimensions and ventilation connections 5 Electrical connection Supply Connecting to main product 6 Commissioning and adjusting Preparations Start-up and inspection 7 Program settings Start guide Menu system NIBE ERS S40-350 Table of Contents... -
Page 4: Important Information
This symbol indicates danger to person or ma- Caution chine . You need the product's serial number for servi- cing and support. Caution This symbol indicates important information about what you should consider when installing or servicing the installation. Chapter 1 | Important information NIBE ERS S40-350... -
Page 5: Recovery
No special tools are required for access. Improper disposal of the product by the user results in administrative penalties in accordance with current le- gislation. NIBE ERS S40-350 Chapter 1 | Important information... -
Page 6: Inspection Of The Installation
In addition, fill in the page for the installation data in the User Manual. Description Notes Signa- Date ✔ ture Electricity (page 16) Connections Main voltage Fuses property Earth circuit-breaker Chapter 1 | Important information NIBE ERS S40-350... -
Page 7: Delivery And Handling
Rail for wall mounting 4 x feet Removing the covers FRONT COVER Loosen the screws that hold the inner front cover Pull the hatch towards yourself. in place. Pull the front cover straight out. NIBE ERS S40-350 Chapter 2 | Delivery and handling... -
Page 8: Physical Configuration
Remove the extract air sensor (BT21) including the insulation plug. This is located furthest in the right- hand space. Extract air Exhaust CONVERSION TO RIGHT-HANDED VERSION Remove the insulation located in the right-hand space. Chapter 2 | Delivery and handling NIBE ERS S40-350... - Page 9 Disconnect the two cables located in the re-heater. Install the re-heater (EB18) furthest in the right-hand space. Remove the re-heater (EB18). Refit the insulation. Connect the two cables to the re-heater. NIBE ERS S40-350 Chapter 2 | Delivery and handling...
- Page 10 Mark the change to the air flows on the duct connec- tion plate (PZ4) on the upper side of the product. Caution In order to complete the conversion, changes are required in menu 7.2.11. Chapter 2 | Delivery and handling NIBE ERS S40-350...
-
Page 11: Assembly
Leave a free space of 800 mm in front of the product. Screw ERS S40 firmly into place on the bracket. NOTE Ensure that there is sufficient space (300 mm) above the HRV unit for installing ventilation hoses. NIBE ERS S40-350 Chapter 2 | Delivery and handling... -
Page 12: Design Of The Hrv Unit
3 Design of the HRV unit XL31 BT20 BM20 BT21 XL33 XL32 BT22 XL34 FQ10 EB18 HQ10 HQ11 AA33 BT23 EP29 W119 W500 Chapter 3 | Design of the HRV unit NIBE ERS S40-350... -
Page 13: Pipe Connections
Rotary heat exchanger Exhaust air fan Supply air fan HQ10 Exhaust air filter HQ11 Supply air filter Miscellaneous Type plate Duct connection rating plate Designations according to standard EN 81346-2. NIBE ERS S40-350 Chapter 3 | Design of the HRV unit... -
Page 14: Ventilation Connections
NOTE To ensure a sealed connection to ERS S40, the supplied hose clips must be used for connect- ing the air ducts. Chapter 4 | Ventilation connections NIBE ERS S40-350... -
Page 15: Dimensions And Ventilation Connections
LEFT-HANDED VERSION 4 x Ø200 4 x Ø160 Exhaust air Extract air Supply air Outdoor RIGHT-HAND VERSION 4 x Ø200 4 x Ø160 Outdoor air Supply air Extract air Exhaust NIBE ERS S40-350 Chapter 4 | Ventilation connections... -
Page 16: Electrical Connection
• S1255 • VVM S325 NOTE CONNECTING COMMUNICATION If the supply cable is damaged, only NIBE, its ERS S40 contains an accessory board (AA33) that con- service representative or similar authorised nects directly to the main product’s input board (terminal person may replace it to prevent any danger block AA2-X30). - Page 17 ISO_GND ISO_12V ISO_GND ERS S40 no. 3 ERS S40 no. 4 ERS S40 2 AA33-X24 ISO_12v ISO_GND ISO_12V ISO_GND ERS S40 and another accessory from NIBE Main product AA2-X30 ERS S40 AA33-X24 ISO_12v ISO_GND ISO_12V ISO_GND Other accessory from NIBE AA5-X24 NIBE ERS S40-350...
-
Page 18: Commissioning And Adjusting
The speed of the fans is also regulated, if necessary. The settings for demand-controlled ventilation are made in menu 7.1.4.4. Chapter 6 | Commissioning and adjusting NIBE ERS S40-350... -
Page 19: Program Settings
Min diff ind and outd air Offset re-heater Setting range: 2 – 10 °C Setting range: 0.0 – 5.0 °C Recovery stop during heating Desired supply air temp. Setting range: on/off Setting range: 16.5 – 25 °C NIBE ERS S40-350 Chapter 7 | Program settings... - Page 20 Set the interval for the reminder to clean the filter in this The ventilation in the accommodation can be temporarily menu. increased or reduced here. Chapter 7 | Program settings NIBE ERS S40-350...
- Page 21 (e.g. every Monday) until you go into the menu and switch it off. Menu 7.4 - Selectable in/outputs Select here whether you want to activate fan speed for the relevant AUX input. NIBE ERS S40-350 Chapter 7 | Program settings...
-
Page 22: Disturbances In Comfort
– Check and clean the exhaust air devices. • Fan speed in reduced mode. – Enter the main product’s menu 1.2.1 and select "normal". • External switch for changing the fan speed activated. – Check any external switches. Chapter 8 | Disturbances in comfort NIBE ERS S40-350... -
Page 23: Accessories
9 Accessories Detailed information about the accessories and complete accessories list available at nibe.eu. TOP CABINET TOC 40 Top cabinet that conceals the ventilation ducts and re- duces the sound to the installation room. Height 245 mm Height 345 mm Part no. -
Page 24: Technical Data
10 Technical data Dimensions 4 x Ø200 4 x Ø160 Chapter 10 | Technical data NIBE ERS S40-350... -
Page 25: Technical Specifications
Temperature and humidity efficiency according to EN 13141-7 Temperature and humidity efficiency (l/s) 100 150 350 400 Luftflöde Airflow Temperatur Temperature Humidity Luftfuktighet RPM: 25 Outdoor air: 7 °C RH <80% Exhaust air: 20 °C RH <38% NIBE ERS S40-350 Chapter 10 | Technical data... -
Page 26: Energy Labelling
General ventilation connections on page 14. Information about pre-/disassembly See section Recovery on page 5. This installer manual can also be accessed at nibe.eu. The annual electricity consumption kWh/year Average: 273 Cold: 810 Warm: 228 Annual heating saved, kWh primary energy per year... -
Page 27: Electrical Circuit Diagram
ELECTRICAL CIRCUIT DIAGRAM NIBE ERS S40-350 Chapter 10 | Technical data... -
Page 28: Item Register
General ventilation connections, 14 Ventilation flows, 14 Important information, 4 Ventilation flow, 14 Recycling, 5 Inspection of the installation, 6 Installation area, 11 Left-handed version, 8 Marking, 4 Menu system, 19 Mounting, 11 Physical configuration Left-handed version, 8 Item register NIBE ERS S40-350... -
Page 31: Contact Information
