Installation INSTRUCTIONS
RIV20
Riviera handset & hose & elb ow –
-
Important
• We recommend that this product is installed by a qualified professional contractor. Such as a plumber who is certified by NVQ
(National Vocational Qualification) or SNVQ (Scottish National Vocational Qualification) Level 3.
• Please check this product immediately to ensure that it has not been damaged and is complete. Before installation, please make
sure this product is the correct model and you have all the parts required for installation and using.
• Please read these instructions carefully and keep it for future reference.
Dimension
1 - 2
A
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Burlington Riviera RIV20
Summary of Contents for Burlington Riviera RIV20
- Page 1 INSTALLATION INSTRUCTIONS RIV20 Riviera handset & hose & elb ow – Important • We recommend that this product is installed by a qualified professional contractor. Such as a plumber who is certified by NVQ (National Vocational Qualification) or SNVQ (Scottish National Vocational Qualification) Level 3. •...
- Page 2 Installation WALL INLET PIPE SHOWER HANDSET ELBOW HOSE CONE END WASHER TAIL WALL PLUG SHOWER ELBOW HOOK SCREW WASHER HOSE NUT END BRASS COV ER 1. Connect the elbow with the water inlet pipe inside the wall (see Fig 1). Wind a suitable sealing tape on the tail to ensure water tightness.
