Summary of Contents for Provision ISR I3-330WIP536
- Page 2 Notes Before operating the camera, we strongly advise users to read this manual and keep it for later use. Please use the specified power supply to connect. Avoid incorrect operation, shock vibration, heavy pressing which can cause damage to the product.
-
Page 3: Ie Remote Access
Page 1 IP CAMERA USER MANUAL Introduction This IPC (short for IP Camera) is designed for high-performance CCTV solutions. It adopts the state of the art video processing chips and utilizes most advanced technologies, such as video encoding and decoding technology, complies with the TCP/IP protocol, SoC, etc to ensure that this system will be extremely stable and reliable. - Page 4 Page 2 IP CAMERA USER MANUAL ④ Double click on the IP address of the system will pop up IE browser and connect to the IPC. IE browser will auto download the Active X control. You must install it in order for the camera to work.
-
Page 5: Video Configuration
Page 3 IP CAMERA USER MANUAL Port and IP setup ④ Go to the router’s management interface through IE browser to forward the IP address and port of the camera to the “Virtual Server”. In the picture example below you will see an example of the setting as if the IPC IP address is “192.168.6.6”... -
Page 6: Image Setup
Page 4 IP CAMERA USER MANUAL You will see the following options: Power Frequency: Choose between NTSC (60HZ) or PAL(50HZ) Stream: Choose between main stream and sub stream Channel name: Choose the camera name Resolution: The higher the resolution is, the bigger the image is. Bitrate Control Type: CBR (Constant) and VBR (Variable) are available. - Page 7 Page 5 IP CAMERA USER MANUAL The display parameters are as follows: Parameter Meaning Contrast Set the image contrast Brightness Set the image brightness Saturation Set the image saturation Set the image hue Sharpness Enable/Disable the sharpness and set its level Image Mirror Mirror the image horizontally Image Flip...
-
Page 8: Image Setting
Page 6 IP CAMERA USER MANUAL 2.1.3 Image Setting Go to “Media” “Image Setting” interface as shown below. Scene Mode Choose between Auto/Indoor/Outdoor White Balance Set the white balance of the camera IR Cut Mode Set the day/night mode Set WDR to deal with advanced light conditions WDR Range Set the WDR level... -
Page 9: Privacy Mask
Page 7 IP CAMERA USER MANUAL 2.1.4 Privacy Mask You can set 4 mask areas at most. To set up video mask 1. Enable video mask. 2. draw the mouse to draw the video mask area. 3. Click Save button to save the settings. 4. -
Page 10: Osd Configuration
Page 8 IP CAMERA USER MANUAL 2.1.5 OSD Configuration Go to “Video Config” “OSD” menu to display the interface as shown below. You may set the device name, time stamp and custom OSDs here. Drag the time stamp and custom OSD over the image on the left side to set their position. -
Page 11: Motion Detection Area
Page 9 IP CAMERA USER MANUAL 2.1.6 Motion Detection Area Go to “Media””Motion Detection Area” 1. Drag the mouse to “draw” the area that you wish to motion detection will be applied in. 2. Click the Save button to save the settings. 3. -
Page 12: Date And Time Configuration
Page 10 IP CAMERA USER MANUAL 2.2.1 Date & Time Configuration Setting steps: 1. Go to System Configuration Date & Time menu as shown below. 2. Set the time zone. 3. Change the time zone according to your location. You may synchronize the camera time with an NTP server (Internet connection required) or synchronize the camera time with the time of the computer you are using. -
Page 13: Device Info
Page 11 IP CAMERA USER MANUAL 2.2.3 Device Info In the “Basic Information” interface, you can view all the necessary information related to the IPC, as seen below: The following table will explain the available detail field. Parameter Meaning Device name Name of the device –... - Page 14 Page 12 IP CAMERA USER MANUAL 3. Q：IE cannot download ActiveX control. How can I do? a. Your IE browser probably set to block ActiveX controls. Please perform the following steps: ① Open IE browser. Click Tools-----Internet Options…. ② Select Security------Custom Level….Refer to Fig 4-1 ③...
