8MP Pro Motorized HD Analog Series
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DI-380A-MVF and is the answer not in the manual?

Questions and answers

Summary of Contents for Provision ISR DI-380A-MVF

  • Page 1 8MP Pro Motorized HD Analog Series USER MANUAL...
  • Page 2 Contents 1) CAUTIONS 2 ) Product Introduction 2.1 Camera Introduction 2.2 Product Features 3) Menu Setup 4) Product Installation 4.1 General Notes 4.2 Installation Tools and Information 4.3 Installation Method Setting the Camera and Lens Setting the video output type Connection OSD Control OSD Menu Scheme...
  • Page 3 1 CAUTIONS 6. In order to make the camera work smoothly and obtain asatisfactory image, the power cord and video connection can not be too long, otherwise the increase 1. To reduce the risk of electric shock, do not open the of line loss will lead to the inadequate magnitude of the machine and maintain by yourself, please consult a operating voltage of the camera or video signal...
  • Page 4: Product Introduction

    2 Product Introduction 3 Menu Setup 2.1 Camera Introduction AHD/TVI: Click on “Iris+” button from the DVR’s PTZ interface to call the OSD Menu. Use the PTZ interface to PROVISION-ISR’s new series of cameras have scroll through the menu and “Iris+” to confirm. adopted a high performance CMOS image sensor, CVI: Click “...
  • Page 5: Installation

    4.2 Installation Tools and Information b. Bullet Camera Adjust the body so that the lens aims at the main Prepare the required tools and instructions. Before monitoring point and gives a clear picture. Tighten the installation please prepare the following tools: screws to ensure that it does not move.
  • Page 6 4.8 OSD Menu Scheme: 4.6 Connection Main Menu Second Menu Third Menu Connection as shown in the figure below Brightness 0~100 Exposure Mode Global / BLC AF Mode Semi / Auto / Manual Zoom Focus Boot Mode Save Pos / Wide End / Tele TDN AF Close / Open Focus Trigger...
  • Page 7 DI-380A-MVF DAI-380A-MVF Model Image Sensor Sensor: 1/2.5" 8MP Sensor Image Format 8MP/4MP - 16:9, 5MP - 4:3 Effective Pixels 3864x2202 Scanning System Progressive Resolution 8MP: 3840x2160 AHD/TVI/CVI, 5MP: 2592x1944 AHD/TVI 4MP: 2560x1440 AHD/TVI/CVI, CVBS: 700TVL 8MP @ 12/15FPS, 5MP @ 20FPS, 4MP @ 25/30FPS, CVBS @ 25/30FPS Min.
