Humanscale M/Connect 2 Disassembly Instructions

Hide thumbs Also See for M/Connect 2:

M/Connect 2

Disassembly Instructions

Tools Required

Safety Glasses

Step 1

Remove Stem Screw

Step 2

Remove Dock by pulling off from Hub

Step 3

Remove Cable Retainer Screw to detach cable

Some components may not be recyclable in your area.

Phillips Screwdriver

Flat Screwdriver

Standard Hex Key Set

Steel

Aluminum

ABS

>ABS<

REV-00

Table of Contents

Do you have a question about the M/Connect 2 and is the answer not in the manual?

Page 1 M/Connect 2 Disassembly Instructions Tools Required Safety Glasses Phillips Screwdriver Flat Screwdriver Standard Hex Key Set Initial Disassembly Step 1 Remove Stem Screw Steel Step 2 Remove Dock by pulling off from Hub Aluminum Step 3 Remove Cable Retainer Screw to detach cable >ABS<...
Page 2 M/Connect 2 Disassembly Instructions Tools Required Safety Glasses Phillips Screwdriver Flat Screwdriver Standard Hex Key Set Hub and Clamp Disassembly Step 1 Remove 4 Screws to detach from Slim Clamp and pull apart and set Hub aside >ABS< Step 2...
Page 3 M/Connect 2 Disassembly Instructions Tools Required Safety Glasses Phillips Screwdriver Flat Screwdriver Standard Hex Key Set Hub Disassembly Continued >ABS< >ABS< Remove all screws and covers to completely disassemble Note: Foam pad can be removed from bottom by scraping off.
