M/Connect 2
Disassembly Instructions
Tools Required
Safety Glasses
Hub and Clamp Disassembly
Step 1
Remove 4 Screws to detach from Slim Clamp and pull apart and set Hub aside
Step 2
Remove L-Bracket Cover
Step 3
Remove all screws, clips and washers to completely disassemble
Some components may not be recyclable in your area.
Phillips Screwdriver
Flat Screwdriver
1
Standard Hex Key Set
Steel
3
Steel
Steel
2
ABS
>ABS<
Steel
REV-00
