M/Connect 2
Disassembly Instructions
Tools Required
Safety Glasses
Dock Disassembly
Step 1
Remove Sheetmetal Bracket Security Screw and slide out dock
Step 2
Remove all screws to disassemble unit
Step 3
Remove PCBA
Step 4
K-Lock Plate is head staked to bottom cover
Some components may not be recyclable in your area.
Phillips Screwdriver
Flat Screwdriver
3
FR4
Standard Hex Key Set
2
ABS
4
>ABS<
1
Steel
REV-00
