Install the Camera

• For outdoor use, the camera
MUST be installed upside
down for better waterproof
performance and better PIR
motion sensor's efficiency.
• Install the camera 2-3 meters
(7-10 ft) above the ground. This
height maximizes the detection
range of the PIR motion sensor.
• For better motion detection
performance, please install the
camera angularly.
NOTE: If a moving object
approaches the PIR sensor
vertically, the camera may fail to
detect motion.
7 English
Mounting Height:
2-3 Meters
PIR Detection Distance:
2-10 Meters
Mount the Camera
1
2
Install the antenna to the camera.
NOTE: For better WiFi connection, it is recommended to install the antenna upward or horizontally.
Drill holes in accordance with the
mounting hole template and screw the
security mount to the wall.
NOTE: Use the drywall anchors included in
the package if needed.
3
2
3
1
Screw the camera to the security mount
and adjust to the proper direction.
English 8
