Assembly Instructions
Caution: You must read this before you proceed
Please look in the Seat Panel for hardware packs
Caution: This Adirondack is NOT a TOY.
Keep your child / children at bay during the assembly process.
Whenever moving or lifting the Adirondack and to prevent damage to the
Adirondack, two adults are needed to execute this action.
Noble House Home Furnishings LLC
ADIRONDACK
Page 1 OF 9
Advertisement
Related Manuals for Noble House Home Furnishings ADIRONDACK
Summary of Contents for Noble House Home Furnishings ADIRONDACK
- Page 1 Caution: This Adirondack is NOT a TOY. Keep your child / children at bay during the assembly process. Whenever moving or lifting the Adirondack and to prevent damage to the Adirondack, two adults are needed to execute this action. Noble House Home Furnishings LLC...
-
Page 2: Parts List
Parts List Description Label Picture Seat Panel Backrest Pre-fixed Front Leg Right Armrest Left Armrest KD Slat Folding Support Bar Noble House Home Furnishings LLC Page 2 OF 9... - Page 3 Sleeve Nut ( M8x15 ) Long Screw ( M7x70 ) Short Screw ( M7x40 ) Screw (M4x30mm) (Use with Screwdriver) Plastic Washer (M8x3mm) Allen Key Not provided Screwdriver Before Beginning Assembly: Noble House Home Furnishings LLC Page 3 OF 9...
-
Page 4: Assemble Steps
Folding Support Bar (G) FRONT FACING This Adirondack has multiple parts and may require up to 30 minutes to assemble. To give you an overview of the Adirondack parts, the above picture is to help you put the various parts into perspective. Please read through the instructions below to familiarise yourself with the parts and steps before assembly. - Page 5 Washer ( ⑥), and Sleeve Nuts (⑤) with Allen Key (⑦). Do not fully tighten Bolts Note: The Plastic Washer should be placed between the Seat Panel and Pre-fixed Front Leg. Noble House Home Furnishings LLC Page 5 OF 9...
- Page 6 Position Backrest (B) with mortise into housing of Folding Support Bar (G) Secure Folding Support Bar(G) to Backrest (B) using Screw ( ④ ) and Allen key ( ⑦ ) as shown above. Do not fully tighten Screws Noble House Home Furnishings LLC Page 6 OF 9...
- Page 7 Note: Plastic Washer should be placed between Left Armrest and Pre- fixed Front Leg. Repeat the same process with the Left Armrest (E). In a sequential manner, tighten all Bolts and Screws at all joints until fully locked into position. Noble House Home Furnishings LLC Page 7 OF 9...
- Page 8 Step 8 Push the Wooden Pin through the Legs as pictured to Lock the Chair into position. Gently and gracefully, sit onto to the Adirondack. This will help to align all the parts at all joint areas. In a sequential manner, tighten all Bolts and Screws at all joints until fully locked into position.
-
Page 9: Care And Maintenance
Not for commercial use. For residential use only . Stains may be removed with mild soap solution and damp cloth. Dust and pick-up spills using a clean, non-colored, lint-free cloth . Noble House Home Furnishings LLC Page 9 OF 9...
