- Page 1 DELUXE CHIMNEY HOOD ECH 6811S Thank you for purchasing EuropAce Products.
-
Page 2: Table Of Contents
Table of Contents From the Manufacturer Specifications SAFETY : Read this irst ! Description of Parts Ducted vs. Recirculation ersion Installation Wall rilling and racket ixing Mounting the ood ody Connections Chimney ssembly Operation Cleaning & Maintenance Troubleshooting Schematic Diagram... -
Page 3: From The Manufacturer
From the Manufacturer This appliance and it’s packaging are produced by processes that minimize waste and respect the environment. Please help us to continue the protection of the environment by disposing of the packaging in a correct manner. Safety ! Protective Cling film, polystyrene and plasti c wrappings must be kept out of reach of babies and young children. -
Page 4: Specifications
Specifications Operation Input The hood is equipped with 3 speed control. 220-2 0V 50Hz Power Use the low speed for simmering, medium speed for light cooking. Use the high speed for frying or heavy cooking. LED Lamps: 2X 1W It is also equipped with a light bulb to illuminate you cooking area 1150 when needed. -
Page 5: Safety : Read This Irst
SAFETY : Read this First ! Chimney assembly (Continued) Service agent or similarly qualified persons in order to avoid a hazard. There shall be adequate ventilation of the room when the range hood is used at the same time as appliances burning gas or other fuels (not applicable to appliances that only discharge the air back into he room);... - Page 6 Multiple plugs and extension cables must not be used. Overload is dangerous and may cause a fire. Ensure that the power cord is free from any heat source or sharp objects. The appliance should be switched off and the electrical supply disconnected before any cleaning or maintenance work can be carried out.
-
Page 7: Description Of Parts
Description of Parts Mounting the hood body Before attaching the hood body, tighten the two screws Vr located on the hood body mounting points. A. Chimney Mounting Bracket B. Upper Chimney Cover Hook the hood body onto the support screws. C. -
Page 8: Ducted Vs. Recirculation Ersion
Ducted vs. Recirculation mode Ducted vs. Recirculation mode You can choose to install the hood as a ducted or recirculation mode :- You can choose to install the hood as a ducted or recirculation mode :- Ducted mode (Vented mode) Ducted mode (Vented mode) In the ducted mode, air is drawn into the hood, grease are trapped by aluminum In the ducted mode, air is drawn into the hood, grease are trapped by aluminum... - Page 9 Installation Installation Wall drilling and bracket fixing Wall drilling and bracket fixing Wall marking: Wall marking: Draw a vertical line on the supporting wall up to the ceiling, or as high as Draw a vertical line on the supporting wall up to the ceiling, or as high as practical, at the center of the area in which the hood will be installed.
- Page 10 Aligning the center of the bracket with the vertical line. Mark the wall at the center of the holes in the bracket. Mark a reference point as indicated at 116mm from the vertical reference line and Y mm above the horizontal reference line. Repeat this step on the other side.
-
Page 11: Mounting The Ood Ody
Mounting the hood body Before attaching the hood body, tighten the two screws Vr located on the hood body mounting points. Hook the hood body onto the support screws. Fully tighten the support screws. Adjust screws Vr to level the hood body. Connection DUCTED MODE AIR EXHAUST SYSTEM When installing the ducted mode, connect the hood... -
Page 12: Connections
RECIRCULATION MODE AIR OUTLET Insert the connection extension pieces Air outlet laterally in air outlet connection. connection Make sure that the outlet of the extension pieces horizontally and vertically aligned with the chimney outlets. Connect the air outlet connection to the hood body outlet using either a flexible or rigid pipe with 150mm. -
Page 13: Chimney Ssembly
Chimney assembly SAFETY : Read this First ! Do not connect the appliance if there are obvious signs of transportation damage. Read this user manual thoroughly before attempting to use this appliance. Installation and repair should be attempted only by qualified technical personnel. -
Page 14: Operation
Cleaning & Maintenance SURFACES : Wash with warm soapy water and a soft sponge. Never use abrasive detergent, scouring pads, steel wool or solvents on any part of this appliance as this will cause irreparable damage. Dry the kitchen hood using a cloth that does not produce fluff. -
Page 15: Troubleshooting
Troubleshooting Symptoms Possible Cause Action Ensure the plug Motor does not No electrical supply is connected properly. working Reset circuit breaker. Aluminum Clean the filters and Poor airflow filters clogged replace when dry Charcoal filters Replace charcoal clogged filters with new sets Motor running but Butterfly valve Contact technician... - Page 16 The Warranty Card is not provided in the product packaging. You can register the product warranty online at our website https://www.europace.com.sg/ewarranty/ within 7 (seven) days from the date of purchase. You will enjoy an additional 3 months of the product standard warranty when you register online.
- Page 17 - Full parts warranty apply to Refrigerators, Air Conditioners & Freezers (Outdoor warranty). Check out the warranty coverage of your appliance at www.europace.com.sg b) The owner waives all or any claims to compensation monetary or otherwise which he/she may be entitled to and shall agree to accept any compensation whatsoever by way of additional repairs or otherwise which we in our absolute discretion may deem t to o er.
- Page 18 g) This warranty will not cover chemical cleaning, maintenance service, general service and overhaul, which if con rm is chargeable. h) Defects or fault in the appliance which has been used for commercial purposes or which have been rented/leased or which have been otherwise subject to other than household use.
- Page 19 RELATED PRODUCTS & MAIN CONTACT HOTLINE System Split Aircons | Tel: 6858 0801| Email: systemac@strategic.com.sg (Twin City) Portable & Casement Aircons | Tel: 6291 0800 | Email: portableac@strategic.com.sg (Jia Yue) Refrigerators, Washing machines, Cookers & other major appliances | Tel: 6289 0802 | Email: mda@strategic.com.sg (TnG)
