- Page 1 EuropAce DELUXE SLIM HOOD DELUXE SLIM HOOD ECH 5141S ECH 5141S hout of the Thank You For Purchasing EuropAce Designer Slim Hood. Thank you for purchasing EuropAce Products.
-
Page 2: Table Of Contents
Table of Contents From the Manufacturer Specifications SAFETY : Read this first ! 4. 5 Vent System Requirement Description of Parts Ducted vs. Re-circulating modes Setting Installation 9, 10 Electrical Connection Operation Cleaning & Maintenance Troubleshooting Schematic Diagram... -
Page 3: From The Manufacturer
From the Manufacturer This appliance and it’s packaging are produced by processes that minimize waste and respect the environment. Please help us to continue the protection of the environment by disposing of the packaging in a correct manner. Safety ! Please do not allow young children to play with the plastic bag packaging. - Page 4 Operation SAFETY : Read this First ! Do not connect the appliance if there are obvious signs of transportation dam- The hood is equipped with 3 speed control. age. Use the low speed for simmering, medium speed for light cooking. Read this user manual thoroughly before attempting to use this appliance.
-
Page 5: Safety : Read This First
SAFETY : Read this First ! (Continued) Service agent or similarly qualified persons in order to avoid a hazard. There shall be adequate ventilation of the room when the range hood is used at the same time as appliances burning gas or other fuels (not applicable to appliances that only discharge the air back into he room);... -
Page 6: Description Of Parts
Description of Parts... -
Page 7: Ducted Vs. Re-Circulating Modes
Ducted vs. Re-circulating Your cooker hood can be configured to operate in the ducted or re-circulating mode :- A. DUCTED MODE (VENTED MODE) In the ducted mode, cooking fumes are vented outdoors through suitable connection of 125mm diameter. In this mode, only the aluminum filters are installed, charcoal filter is optional. -
Page 8: Setting
Setting The operating mode of your cooker hood must be set before installation A. To set your hood to operate in the ducted mode By adjusting the plastic parts on the motor housing as per below arrow showed. B. To set your hood to operate in the re-circulation mode By adjusting the plastic parts on the motor housing as per below arrow showed. -
Page 9: Installation
Installation Mounting accessories included 4 screws 5 x 44mm 4 wall plugs (brick fixing) Ø 8mm 4 screws 4,2 x 35 mm Installation (1) — Wall unit mounting (1) Using the drilling temple. (2) Make the holes on the bottom of the cupboard. (3) If the hood is to be used in the extraction version. - Page 10 Installation (2) — Wall Mounting (1) Mark a centre line on the wall. (2) Fit the template onto the wall. (3) Fix the drilling template to the wall. Make 3 Ø 8mm holes in the wall. (4) 2 at upper points, 1 as desired at lower points. Insert the three Ø 8mm expan- sion plugs into the wall.
-
Page 11: Electrical Connection
Electrical Connection Before completing any connection, make sure the house voltage corresponds with the voltage indicated on the label affixed inside the hood. It is advisable to call a qualified technician to make the electrical connection. Appliance fitted with plug Connect it to a socket which conforms with current regulations. -
Page 12: Operation
Operation The hood is equipped with 3 speed control. Use the low speed for simmering, medium speed for light cooking. Use the high speed for frying or heavy cooking. It is also equipped with a light bulb to illuminate you cooking area when needed. -
Page 13: Cleaning & Maintenance
Cleaning & Maintenance SAFETY : Read this First ! (Continued) SURFACES : Wash with warm soapy water and a soft sponge. Never use Service agent or similarly qualified persons in order to avoid a hazard. There shall be adequate ventilation of the room when the range hood is used at the abrasive detergent, scouring pads, steel wool or solvents on any part of this same time as appliances burning gas or other fuels (not applicable to appliances that appliance as this will cause irreparable damage. -
Page 14: Troubleshooting
Troubleshooting Symptoms Possible Cause Action Check that the plug No electrical supply is connected. Check that the main switch is turned on. Aluminum grease Clean the filters and Poor airflow filters clogged replace when dry Charcoal grease Replace charcoal filters clogged filters with new sets Butterfly valve Contact technician... -
Page 15: Schematic Diagram
Schematic Diagram 1 motor version: 2 motor version:... - Page 16 The Warranty Card is not provided in the product packaging. You can register the product warranty online at our website https://www.europace.com.sg/ewarranty/ within 7 (seven) days from the date of purchase. You will enjoy an additional 3 months of the product standard warranty when you register online.
- Page 17 - Full parts warranty apply to Refrigerators, Air Conditioners & Freezers (Outdoor warranty). Check out the warranty coverage of your appliance at www.europace.com.sg b) The owner waives all or any claims to compensation monetary or otherwise which he/she may be entitled to and shall agree to accept any compensation whatsoever by way of additional repairs or otherwise which we in our absolute discretion may deem t to o er.
- Page 18 g) This warranty will not cover chemical cleaning, maintenance service, general service and overhaul, which if con rm is chargeable. h) Defects or fault in the appliance which has been used for commercial purposes or which have been rented/leased or which have been otherwise subject to other than household use.
- Page 19 RELATED PRODUCTS & MAIN CONTACT HOTLINE System Split Aircons | Tel: 6858 0801| Email: systemac@strategic.com.sg (Twin City) Portable & Casement Aircons | Tel: 6291 0800 | Email: portableac@strategic.com.sg (Jia Yue) Refrigerators, Washing machines, Cookers & other major appliances | Tel: 6289 0802 | Email: mda@strategic.com.sg (TnG)
