COMMUNITY

BARBECUE SERIES

CBBQ 600 &

Instructions and

General Information

CBBQ 850

Need help?

Do you have a question about the COMMUNITY BARBECUE CBBQ 600 and is the answer not in the manual?

Questions and answers

Summary of Contents for Heatlie Barbecues COMMUNITY BARBECUE CBBQ 600

Page 1 COMMUNITY BARBECUE SERIES CBBQ 850 CBBQ 600 & Instructions and General Information...
Page 2 COMMUNITY BARBECUE CONGRATULATIONS ON PURCHASING A HEATLIE BARBECUE! Designed for those who love the experience of outdoor cooking, we’re sure you’ll enjoy the power and efficiency of the Ribbon Burner System. Especially the fact that you’ll never have to worry about flare-ups! Here’ s looking forward to many delightful occasions preparing the food you crave, for the ones you love.
Page 3 COMMUNITY BARBECUE CONTENTS Positioning Your Heatlie Barbecue In Unpacking The Box: Installation: Safety Precautions An Outdoor Area Cabinet Preparation CBBQ 850: Bench CBBQ 600: Bench Connecting To A Gas Preparation and Preparation and Supply Installation Installation Using the Barbecue Plate: Cleaning & Seasoning Lighting Instructions Cooking Instructions...
Page 4 COMMUNITY BARBECUE CBBQ 600 CBBQ 850 A-0060-MAN Heatlie Community Barbecue Instruction Manual V2 Updated Dec 2021...
Page 5 COMMUNITY BARBECUE UNPACKING Remove all items from the box and check against the list below to ensure that all components are included. THE BOX Box Contents Before installation, please check that the following components have been supplied: 1x Heatlie Community BBQ (CBBQ 600 or CBBQ 850) 1x Large Ziploc bag with instructions 1x Waste container 1x Serviceable Burner Insert (SBI) in ordered configuration...
Page 6 COMMUNITY BARBECUE POSITIONING This barbecue is only to be used in an above ground, open air situation with natural ventilation, without stagnant areas, where gas leakage and YOUR HEATLIE products of combustion are rapidly dispersed by wind and natural convection. BARBECUE IN The Community Barbecue is not for use indoors.
Page 7 COMMUNITY BARBECUE INSTALLATION Firstly, all Community Barbecues need to be kept under a weather proof cover. The requirements and instructions for using your Heatlie Barbecue in a purpose-built cabinet are outlined below. The Community Barbecue can be installed into a bench and bench top which are made from combustible and/or non-combustible materials.
Page 8 COMMUNITY BARBECUE Natural Gas When the Community Barbecue is connected to a main gas supply (Natural Gas), a separate compartment is not required. A 40mm diameter hole is required on the rear of the cabinet (on the side which has the control knob) to allow access to the natural gas connection.
Page 9 COMMUNITY BARBECUE CBBQ 600 Bench Preparation NB. If you are installing a CBBQ 850 please refer to page 10. Before cutting your bench top please ensure you have a minimum of 170mm clear of combustible materials below the bench top to accommodate the body of the barbecue.
Page 10 COMMUNITY BARBECUE CBBQ 850 Bench Preparation NB. If you are installing a CBBQ 600 please refer to page 9. Before cutting your bench top please ensure you have a minimum of 170mm clear of combustible materials below the bench top to accommodate the body of the barbecue.
Page 11 An LPG barbecue cannot be connected directly to a natural gas (piped) supply. Whilst the Barbecue can be converted, you will need to contact Heatlie Barbecues or your nearest stockist or for details on parts required. Natural Gas Connection Where the barbecue is supplied for use with Natural Gas, a hose fitting complying to AS1869 is attached.
Page 12 COMMUNITY BARBECUE USING THE Cleaning the Barbecue Plate (Before first time use) The Barbecue plate has a food grade lanolin protective coating on it to BARBECUE prevent rust before use. Before cooking with the barbecue this coating needs to be completely removed. Remove as much of the coating as PLATE possible with paper toweling.
Page 13 COMMUNITY BARBECUE LIGHTING Before Lighting Check the fat container is not full, empty if required. INSTRUCTIONS 2. Ensure the knob is in the LOW position. 3. Inspect Gas cylinder for damage and valid test date. 4. Turn on valve at the gas cylinder (for gas cylinder connection AND if it is an accessible valve).
Page 14 COMMUNITY BARBECUE COOKING Turn the barbecue on high for 2 minutes to pre-heat the hotplate. As a guide: INSTRUCTIONS For a 20mm thick, medium cooked steak, cook for 3-4 minutes each side. For a medium-rare steak, cook for 2 minutes on each side. For gourmet sausages (25mm thick) cook for approximately 10 minutes, turning every couple of minutes.
Page 15 • Correct operation of the gas system and burners. The SBI can be removed and returned to Heatlie for servicing. The Servicing must only be carried out by Heatlie Barbecues or a licensed gas fitter. This appliance contains no user serviceable parts.
Page 16 Timer unit failure required. If gas fitter is unavailable to change, SBI changeover is required. If any of the above conditions cannot be rectified, contact the place of purchase or Heatlie Barbecues. A-0060-MAN Heatlie Community Barbecue Instruction Manual V2 Updated Dec 2021...
Page 17 COMMUNITY BARBECUE CBBQ 600 CONSUMPTION Gas Type Natural Gas Universal LPG 1.60mm 0.90mm Injector Diameter Burner Pressure 1.00kPa 2.75kPa Nominal Hourly Gas Consumption 10 MJ/hr 9 MJ/hr per burner NHGC Total 20 MJ/hr 18 MJ/hr CBBQ 850 Gas Type Natural Gas Universal LPG Injector Diameter Burner Pressure...
Page 18 COMMUNITY BARBECUE WARRANTY Heatlie Barbecues warrants its products to be free of original manufacturing defects in material and workmanship, for a period of ten POLICY (10) years from the date of purchase for domestic use and one (1) year for commercial use.
Page 19 Designed and manufactured by: M&A Mead Investments Pty Ltd t/as Heatlie Engineering ABN 55 111 671 008 60 Kinkaid Ave NORTH PLYMPTON SA 5037 Phone (08) 8376 9330 Email Address: info@heatlie.com.au Web Page: www.heatlie.com.au...
