The states screen contains information about the device and its
current parameters. Find the DoubleButton states in the Ajax app:
1. Go to the Devices tab
2. Select DoubleButton from the list.
Battery Charge
LED Brightness
Works via *range extender name*
https://support.ajax.systems/en/manuals/doublebutton/
.
Parameter Value
Battery level of the device. Two states
available:
ОК
Battery discharged
How battery charge is
displayed in Ajax apps
Indicates the LED brightness level:
Off — no indication
Low
Max
Indicates the status of the ReX range
extender use.
The Feld is not displayed if the device
communicates directly with a hub
Indicates the status of the device:
Active
