Pool Pro CPP Series User Manual & Operation Manual page 17

10. SCHEMATICS AND PART NUMBERS
# CODE
1 PPN00037 CPP/CPPS ALUMINIUM CHASIS
2 PPN00039-1 CPP/CPPS FRONT COVER BLACK
3 PPN00060 CPP/CPPS FRONT STICKER
4 PPN00033 CPP/CPPS ACRYLIC FRONT
5 PPN00038 CPP/CPPS TOP CASE LID
CPP/CPPS TRANSFORMER 220VA
6 PPN00022
FOR 20G/HR MODEL
CPP/CPPS TRANSFORMER 340VA
6 PPN00023-1
FOR 30G/HR MODEL
CPP/CPPS/NEPTUNE
6 PPN00024-1 TRANSFORMER 440VA FOR
40G/HR MODEL
7 PPN00027 CPP/CPPS THERMOSTAT 100
CPP/CPPS HEAT SINK 90MM 40G/
8 PPN00040
HR MODEL
CPP/CPPS HEAT SINK 30MM UP
8 PPN00041
TO 30G/HR MODELS
9 PPN00025 CPP/CPPS SCR 65AMP FLAT BACK
OLD STYLE CPP/CPPS STANDARD
10 PPN00028-1
TIMER - BOSCHE MECHANICAL
OLD STYLE CPP/CPPS DIGITAL
10 PPS0051 TIMER
- FRONTIER QUARTZ
NEW STYLE CPP/CPPS STANDARD
10 PPN00414 TIMER - QUARTZ BOSCHE
MECHANICAL BATTERY B/UP
CPP/CPPS TIMER - BRACKET
11 PPN00029
HOUSING
12 PPN00026 CPP/CPPS ROCKER SWITCH
CPP/CPPS CIRCUIT BREAKER
13 PPN00018
3AMP 20&30G/HR MODELS
CPP/CPPS CIRCUIT BREAKER
13 PPN00019
5AMP 40G/HR MODEL
14 PPN00011 CPP/CPPS POWER CORD-AU
CPP/CPPS AC SOCKET SQUARE -
15 PPN00001
PUMP OUTLET
16 PPN00072 CPP PLASTIC RIVET WHITE
CPP PCB STANDARD WITH 4&6
17 PPN00172
PIN CONNECTOR
17 PPN00030 CPPS PCB REVERSE POLARITY
18 PPN00003 CPP METER STANDARD
18 PPN00002 CPPS METER REVERSE POLARITY
CPP/CPPS KNOB FOR
19 PPN00035
POTENTIOMETER
CPP/CPPS JUNCTION BOX
20 PPN00020
COMPLETE WITH COVER
CPP/CPPS JUNCTION BOX SCREW
21 PPN00160
- CENTRE SMALL
CPP/CPPS JUNCTION BOX SCREW
22 PPN00159
- OUTER LARGE
CPP/CPPS TERMINAL BLOCK 2
23 PPN00021
PIN
DESCRIPTION
C
o
# CODE
CPP/CPPS CABLE GROMMET
24 PPN00034
6N-4
25 PPN00042 CPP/CPPS SCR BRIDGE LONG
26 PPN00043 CPP/CPPS SCR BRIDGE SHORT
CPP POWER PACK COMPLETE
27 PPEC2000PP-C
CPP20
CPP POWER PACK COMPLETE
27 PPEC3000PP-C
CPP30
CPP POWER PACK COMPLETE
27 PPEC4000PP-C
CPP40
CPPS POWER PACK COMPLETE
27 PPRP2000PP-C
CPPS20
CPPS POWER PACK COMPLETE
27 PPRP3000PP-C
CPPS30/CPPS30C
CPPS POWER PACK COMPLETE
27 PPRP4000PP-C
CPPS40/CPPS40C
CPPS POWER PACK COMPLETE
27 PPRP5000COMM
CPPS50C
CPP/CPPS PVC - REDUCING
57 PPN00670-1
BUSH 50X40MM
CPP20 REPLACEMENT CELL-5
50 PPCC20EC PLATES 200MM, SOLID PLATE
CATHODE/ANODE
CPP30 REPLACEMENT CELL-7
50 PPCC30EC PLATES 200MM, SOLID PLATE
CATHODE/ANODE
CPP40 REPLACEMENT CELL-9
50 PPCC40EC PLATES 200MM, SOLID PLATE
CATHODE/ANODE
CPPS20 REPLACEMENT CELL-
50 PPCC20RP 5 PLATES 200MM, REVERSE
POLARITY
CPPS30 REPLACEMENT CELL-
50 PPCC30RP 7 PLATES 200MM, REVERSE
POLARITY
CPPS40 REPLACEMENT CELL-
50 PPCC40RP 9 PLATES 200MM, REVERSE
POLARITY
CPPS50 REPLACEMENT CELL-
50 PPCC50RP-C 13 PLATES 200MM, REVERSE
POLARITY
CPP/CPPS CELL CLIP 9 PLATE
51 PPN00455
BLUE CRYSTAL- NO ROD
CELL CAP (C/W CABLE, COVER,
52 PPSCCAP CAP, BRASSWARE, WASHERS,
RESIN FILLED)
53 PPN00492 CELL CAP LOCKING RING
CPP/CPPS CELL SPACER (RODS
54 PPN00260
ONLY) BLACK
CPP/CPPS CELL SPACER (RODS
54 PPN00322
ONLY) BLUE
CPP/CPPS CRYSTAL CLEAR CELL
55 PPN00465
HOUSING - SMOKEY
56 OR925M CPP/CPPS O-RING CELL HOUSING
CPP/CPPS PVC - REDUCING
57 PPN00670-1
BUSH 50X40MM
DESCRIPTION
17
