Birlea Madison Dressing Table Assembly Instructions Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Assembly Instructions
Thank you for
purchasing a
Birlea product.
Are you happy with your purchase?
Yes:
That's great, we would love to hear more from you. Please leave us a review on
our social media channels or Trustpilot. Your feedback will be greatly appreciated.
No:
If for any reason there is something missing, indifferent or incorrect with
your order, please contact the retailer you purchased the item from. We will
work with the retailer to resolve your issue as quickly as possible.
For a chance to win a Love 2 Shop voucher
simply post a picture of your new product
on your preferred social channels tagging
Birlea Furniture and using the hashtag
#ShareYourStyle and #Birlea. One winner
will be selected at random each month.
To view our full terms and conditions please visit our website. www.birlea.com
www.birlea.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the Madison Dressing Table and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Birlea Madison Dressing Table

Summary of Contents for Birlea Madison Dressing Table

  • Page 1 #ShareYourStyle and #Birlea. One winner Birlea product. will be selected at random each month. To view our full terms and conditions please visit our website. www.birlea.com Are you happy with your purchase? Yes: That’s great, we would love to hear more from you. Please leave us a review on our social media channels or Trustpilot.
  • Page 2 Assembly Video For a step by step guide on how to build our Madison Dressing Table visit our YouTube channel ´BirleaFurnitureLtd ’ or alternatively scan the below code on your smart phone. How to scan a QR code from an apple device Step One: Open up the camera app Step Two:...

  • Page 3: Health And Safety

    ASSEMBLY INSTRUCTIONS MADISON DRESSING TABLE IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR USING YOUR MADISON DRESSING TABLE. PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. HEALTH & SAFETY: DO NOT use this item if any parts are missing, damaged or worn.
  • Page 4 Vendor: S000139 Parts List Description Part Left side Division Right side Footer module drawers Footer Mirror panel Mirror platter Drawer front Larger drawer front Rear of drawer Side of larger left drawer Side of larger right drawer Larger drawer rear Bottom of drawer Back Left side of drawer...
  • Page 5 Hardware List Description Part 5 x 60 mm Screw Glue Trapeze 5 x 50 mm Flanged Screw Metalic bracket Bushing 8 x 30 mm Wooden Dowel Smal plastic foot Structural Screw Allen Key Structural Screw Cover Simple Minifix Screw Cam Lock Bore patch adhesive Nail 4,5 x 45 mm Screw...
  • Page 6 Vendor: S000139 Step 1: Attach hardware part E to the left side of drawer and right of drawer, (76) and (77) using hardware part A1 and a small mallet (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. (2X) (2X) Step 2:...
  • Page 7 Vendor: S000139 Step 4: Attach hardware part E to the side of larger left drawer(14) and side of larger right drawer (15) using small mallet (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 5: Attach hardware part E the mirror panel (09) and to the mirror platter (10) using small mallet (not provided).Attach hardware part A3 the mirror platter (10).
  • Page 8 Vendor: S000139 Step 7: Attach hardware part (XA) to the left side (04) using hardware part P5 and screwdriver (not provided). Insert hardware part E using a small mallet (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. ATTENTION FOR POSITION FOR UP 1st HOLE...
  • Page 9 Vendor: S000139 Step 10: Attach the division (05) and footer (08) and right side (06) using the hardware B, G, H and I. DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 11: Attach the footer module drawers (07) to the division (05) using a hardware G, H and I.
  • Page 10 Vendor: S000139 Step 12: Attach the left side (04) to the footer module drawers (07) using the hardware G, H and I. DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 13: Join the mirror platter (10) and top (03) using the hardware O and a screwdriver (not provided).
  • Page 11 Vendor: S000139 Step 14: Join the mirror panel (09) to the assembled section using hardware part O and screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 15: Attach the assembled section using hardware part L in the left side (04), and division (05),and hardware part L and M in the right side (06) using the a screwdriver (not provided).
  • Page 12 Vendor: S000139 Step 16: Attach the small plastic foot (E7) with the hardware N in the left side (04), and division (05), and right side (06) using a small mallet (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 17: Attach the back (18) using the hardware part N and a small mallet (not provided).Attach the hardware P in the mirror panel (09) and mirror platter (10).
  • Page 13 Vendor: S000139 Step 18: To secure the item to the wall use hardware A, B3 and B7 and a screwdriver (not provided), then attach the hardware part S to the item with a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 19: Attach the left side of drawer (76) and the right side of drawer (77) to the rear of drawer (13) and the bottom of drawer (17) using the hardware O and a screwdriver (not provided).
  • Page 14 Vendor: S000139 Step 20: Attach the drawer front (11) using hardware part A1, and L with a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 21: Attach in the drawer front (11) the handle X4 using hardware part P5 with a screwdriver (not provided). Attach part M the left side of drawer (76) and the right side of drawer (77).
  • Page 15 Vendor: S000139 Step 22: Attach the hardware part XC and XD using the hardware part P5 and screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. THE UNDERSIDE OF THE DRAWER Step 23: Attach the side of larger left drawer (14) and the side of larger right drawer (15) to the larger drawer rear (16) and the bottom of drawer (17) using the hardware O and a screwdriver (not provided).
  • Page 16 Vendor: S000139 Step 24: Attach the larger drawer front (12) using hardware part A1, and L with a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 25: Attach in the larger drawer front (12) the handle X4 using hardware part P5 with a screwdriver (not provided).

  • Page 17: Additional Information

    If you have any issues with your item please contact the retailer directly you purchased it from who will be able to resolve any issues with Birlea. Why don't you send us photos of your assembled furniture to info@birlea.com to be shared in our #birleahome feature on Instagram.
