Dacor OB36 Planning Manual

Dacor OB36 Planning Manual

36”, 52” wide outdoor grills 16” wide side burner
Hide thumbs Also See for DACOR OB36:
Table of Contents

Advertisement

Quick Links

See also: Use and Care Manual , Instruction and Installation Manual
OB36, OB52, OBS36, OBS52, OBSB162
Document # PG13-001
9 1/8"
(232mm)
23 3/4"
(603mm)
26 1/2"
(673mm)
27" *
(686mm)
OB/OBS36 OvErALL DImENSIONS
9 1/8" ***
(232mm)
23 3/4"
(603mm)
26 1/2"
(673mm)
OBSB162 OvErALL DImENSIONS
Model type
electrical Circuit Required
Natural Gas
120 Vac, 60 Hz, 15 Amp.
LP Gas
120 Vac, 60 Hz, 15 Amp.
Note:
Supply access for the rotisserie power or an alternate 120 Vac duplex outlet location.
www.Dacor.com
Phone: (800) 793-0093
36", 52" Wide Outdoor Grills
16" Wide Side Burner
36"
(914mm)
(406mm)
27" **
(686mm)
total Connected Load
2.9 Amps (0.35 kW)
2.9 Amps (0.35 kW)
All tolerances: +1/16", -0, (+1.6mm, -0) unless otherwise stated
25 1/8"
(638mm)
◊
Observe all governing codes and ordinances during
planning and installation. Contact your local building
department for further information.
◊
This appliance must be installed in accordance with the
accompanying installation instructions.
9 1/8"
(232mm)
16"
*Total depth with handle: 30" (762mm)
**Total depth with knobs: 28 5/8" (753mm)
***Total height with cover: 12" (305mm)
Gas type
Natural
Propane
Specifications are subject to change without notice.
See installation instructions for additional details.
waRNiNG
23 3/4"
(603mm)
26 1/2"
(673mm)
27" *
(686mm)
OB/OBS52 OvErALL DImENSIONS
Manifold Pressure
4" Water Column
11" Water Column
Revised 04/07/09 Page 1/3
PLANNING
GUIDE
25 1/8"
(638mm)
52"
(1321mm)
Minimum Gas Supply
Pressure
5" Water Column
12" Water Column
13.1
