Dacor EOG303 Installation Instructions

Part No. 65289 Rev. B
9 1/8"
(232mm)
23 3/4"
(603mm)
2" (51mm)
Min. to Non-Combustible
9 1/2" (241mm)
Min. to Combustible
3/4" (193mm)
Minimum

Installation Instructions

Outdoor Grill Trim Finish

25 1/8"
(638mm)
A
24 3/4"
(629mm)
B
1 1/2" (38mm)
Typical All
Sides
9" (228mm)
Maximum
C
Model "A"
BBQ:
EOG303 30" (762mm)
EOG36 36" (914mm)
EOG52 52" (1321mm)
Side Burner:
EOSB162 16"(406mm)
BBQs ONLY
1" (25mm)
Typical All
Sides
"B"
30 3/8" (772mm) 30 1/2" (775mm)
36 3/8" (924mm) 36 1/2" (927mm)
52 3/8" (1330mm) 52 1/2" (1334mm)
16 1/16" (408mm) 16 1/8" (410mm)
"C"
