TESTED IN ACCORDANCE WITH THE LATEST EDITION OF ANSI Z21.58-1998, CGA 1.6-M98
STANDARD FOR OUTDOOR GAS COOKING APPLIANCES. IN CANADA: INSTALLATIONS
MUST BE IN ACCORDANCE WITH THE CURRENT CAN/CGA-B149.1. NATURAL GAS
INSTALLATION CODE CAN/CGA-B149.2. PROPANE INSTALLATION CODE AND/OR LOCAL
CODE.
CONVENTIONS USED IN THESE INSTRUCTIONS
WARNINGS:
Must be followed carefully to avoid personal injury.
IMPORTANT:
Must be followed carefully to avoid damage.
NOTES:
Contain helpful hints and tips to facilitate the installation.
IMPORTANT
1. Before beginning installation, please thoroughly read and become familiar with these instructions.
2. Installation and service must be completed by a qualified installer or service agency.
3. Installer: Please leave these Installation Instructions with the owner.
4. Owner: Please keep these instructions for local electrical inspector's use and for future reference.
5. Read the accompanying Use & Care Manual prior to operating this appliance.
TABLE OF STEPS
STEP 2
Planning installation - base construction structure with access doors
Part No. 65249 Rev. C
Installation Instructions
Epicure™ Outdoor Grill
Page 2
Page 2-4
Page 5
Page 6-7
Page 7-8
Page 8-9
Page 9
Advertisement
Related Manuals for Dacor Epicure EOG303
Summary of Contents for Dacor Epicure EOG303
-
Page 1: Table Of Contents
Installation Instructions Epicure™ Outdoor Grill TESTED IN ACCORDANCE WITH THE LATEST EDITION OF ANSI Z21.58-1998, CGA 1.6-M98 STANDARD FOR OUTDOOR GAS COOKING APPLIANCES. IN CANADA: INSTALLATIONS MUST BE IN ACCORDANCE WITH THE CURRENT CAN/CGA-B149.1. NATURAL GAS INSTALLATION CODE CAN/CGA-B149.2. PROPANE INSTALLATION CODE AND/OR LOCAL CODE. - Page 3 19. This appliance should be serviced only by qualified service personnel. Contact the nearest Dacor authorized servicer at (800) 772-7778, or at www.dacor.com for examination, repair or adjustment. 20. Keep outdoor cooking gas appliance areas clear and free from combustible materials, gasoline and other flammable vapors and liquids.
-
Page 4: Step 1 Verifying The Package Contents
STEP 1 Verifying the Package Contents EOG303/36/52 Models EOG52 & EOSB162 Models • Grease Tray • Grills • burner grate, caps, and cover • Smoker Tray • Rotisserie - forks - rod - motor • Warming Rack • cleaning cream •... - Page 5 STEP 2 Planning Installation - Base Construction Structure (continued) Locate the electrical supply box within reach of the 48 inch (1219mm) long power cord so the connection is accessible when the grill is completely installed in the enclosure. For self contained LP-gas supply systems, refer to the detail in the Gas Installation section of this manual. LP-gas cylinder shall be ventilated by openings at the level of the cylinder valve and the floor level.
- Page 6 STEP 2 Planning Installation - Base Construction Structure (continued) 6" x 6" EOS16 EOG30 - 30 1/2 (775mm) (152mm x 152mm) 16 1/8" (410mm) EOG36 - 36 1/2" (927mm) Utility Cutout EOG52 - 52 1/2" (1334mm) 8" (203mm) Maximum 3/4" (19mm) 25"...
-
Page 7: Planning Installation - Cart
4. Remove the cart from the shipping pallet before installation assembly. NOTES: 1. The Dacor cart ships assembled ready for the EOG Outdoor Grill installation assembly. 2. All gas and electrical connections should be made after the grill is installed and bolted to the cart. -
Page 8: Step 3 Gas And Electrical Supply Requirements
STEP 3 Gas and Electrical Supply Requirements WARNING: Electrical grounding instructions This outdoor cooking gas appliance is equipped with a three-prong grounding plug for your protection against shock hazard and should be plugged into a properly grounded three-prong receptacle. Do not cut or remove the grounding prong from the plug. NOTES: 1. -
Page 9: Step 3 Gas And Electrical Supply Requirements
Verify gas supply pressures are acceptable based on Table Number 1, on page 6. The Dacor outdoor cooking products ship with a 3/4 inch nipple, regulator, and 1/2” reducer for gas supply connections. Install a 3/4 inch (19mm) or 1/2 inch (13mm) natural gas supply line, with a shut off valve (not included with the outdoor product), in an accessible location under the appliance. -
Page 10: Step 4 Gas Connections
Place the tank into the final position within the base enclosure or cart. NOTE: The Dacor outdoor grills are approved for installation on typical whole-house LP gas supply systems. For proper whole-house LP gas installation order Dacor part # 72601. -
Page 11: Step 6 Verifying Proper Operation
Off position Light & high position burner controls to the OFF position. Turn off the main gas line control valve or LP tank control valve and contract your authorized Dacor service agent to schedule a service call. Low position When installed properly, the flame will be steady and quiet. Flame adjustment will not be necessary, all grill and side burners are factory adjusted, for proper performance. - Page 12 INDICATOR LIGHTS 3-PRONG PLUG SUPPLY CORD & STRAIN RELIEF FOR OUTDOOR USE BK BK BK 4 POINT RE-IGNITOR TERMINAL BLOCK 3-PRONG PLUG ROTISSERIE BOX DIAGRAM IGNITION 10W,12V PLUGS LEFT HALOGEN LIGHT LEFT GRILL INFARED BURNER BURNER RIGHT GRILL CENTER GRILL SUPPLY CORD &...
- Page 13 NOTES: Page 11...
- Page 14 NOTES: Page 12...
- Page 16 Web Site: www.dacor.com For a Dealer/Service: (800) 772-7778 Corporate Phone: (800) 793-0093...
