Prince Castle DHB2PT-GMCN Operation Manual

Operation
Manual
DHB3PT-GMCN
This product is warranted to be free from defects in material and/or
workmanship
for a period of 1 year from date of original installation, not to exceed 18 months
from the date of manufacture.
Any component which proves to be faulty in material and/or workmanship will be
replaced or repaired (at the option of Prince Castle, Inc.) without cost to the
customer for parts and labor. This warranty covers on location service (i.e. trip
charges and or mileage). Travel mileage is limited to 100 miles (200 Kilometers)
round trip (one trip warranty) from an authorized service agency or its sub-
service
agency.
This warranty is subject to the following exceptions/conditions:
• Use of any non-genuine Prince Castle parts voids this warranty.
• All labor to be performed during regular work hours. Overtime premium (the
incremental amount) will be charged to the customer.
• Damage caused by carelessness, neglect and/or abuse (e.g., dropping,
tampering or altering parts, equipment damaged in shipment, by fire, flood or
an act of God) is not covered under this warranty.
• All problems due to operation at voltages other than that specified on
equipment nameplates are not covered by this warranty. Conversion to correct
voltage is the customer's responsibility.
• This equipment must be serviced by Prince Castle Authorized Service Agency
or a Prince Castle Service Technician during the warranty period.
Note: 520-120 wire frame and 520-202 tray is consumable, not covered under
this warranty.
Building 5, No. 889 Kungang Road.,XiaoKunShan Town, Songjiang District, Shanghai, China, Zip Code 201614
520-500revA-EN
LIMITED WARRANTY
Tel: +86-021-6040-1705 www.princecastle.com
DHB2PT-GMCN & DHB3PT-GMCN
DHB2PT-GMCN
1
Holding Bin
Button 1、2、3

TABLE OF CONTENTS

Safety Information.......................................................................2
Electrical Specification................................................................2
Product Identification.................................................................2
Installation...................................................................................3
Operation....................................................................................3
Cleaning......................................................................................4
Setting the Temperature.............................................................4
Calibrating Heater......................................................................5
Trouble Shooting.........................................................................6
Wiring Diagram...........................................................................6
Exploded View and Parts List.....................................................7
Display
Set point
UP arrow
Down arrow
