Summary of Contents for Hans Grohe Ecostat S 15715000

  • Page 1 ® UNIDOMO Web: www.unidomo.de Telefon: 04621- 30 60 89 0 Mail: info@unidomo.com Öffnungszeiten: Mo.-Fr. 8:00-17:00 Uhr a member of DAIKIN group � Individuelle Beratung � Komplettpakete Kostenloser Versand Über 15 Jahre Erfahrung � � Hochwertige Produkte Markenhersteller � �...
  • Page 2 Installation Instructions Ecostat S 15715000...
  • Page 3: Table Of Contents

    Contents Safety and Important Information Pack Contents Diniensions Technical Data Supply Conditions TMV2 Supply Conditions TMV3 Installation Requirements Installation Thermostat Commissioning and in-service tests Commissioning In-service tests Frequency of in-service tests Thermostatic Adjustement Temperature Limitation The Thermostat Kit 15715000 meets the re- Callibrating Thermostat quirements of the TMV2 Scheme.
  • Page 4: Safety And Important Information

    Safety and Important Information Hansgrohe products are safe provided they are installed, used and maintained in accordance with these instructions and recornrnendations. Please read these instructions thoroughly and retain for future use. The plumbing installation of this thermostat mixing valvemust comply with the requirements of UK Water Regulations/Bylaws (Scotland), Building Regulations or any other regulations specified by the local Water Authority and supplier.
  • Page 5: Pack Contents

    Dimensions Pack Contents Please check that you have been supplied with the following: Ecostat S 15715000 1 Handle 2 Face plate 3 Sleeve 4 Fixing screws 5 Fixing plate 6 thermostat cartridge block 7 spindle extension 8 Allen screw 9 Allen Key...
  • Page 6: Technical Data

    Technical Data NB. If a water supply is fed by gravity then the supply pressure should be verified to ensure the con- ditions of use are appropriate for the valve. Valves Ecostat ibox operating outside of these supply conditions cannot This thermostatic valve will suit supplies of: be guaranteed to operate as a TMV2 or TMV3 valve.
  • Page 7: Installation Requirements

    Installation Requirements This thermostatic mixer valve must be installed in compliance with current Water Regulations. If you have any doubts about the Water Regulation requirements contact your local water services provider or use the services of a professional plumber. This mixer valve is suitable for use with the following water supply systems: Gravity Fed Hot and Cold (pressure balanced) 0.1 - 1.0 bar Gas Combination Boiler (multi-point) 1.0 - 10 bar*...
  • Page 8 Unvented System (pressure balanced) Pumped System...
  • Page 9: Installation

    Installation Thermostat 1. With the I-Box fitted and the surface tiled, cut back the plastic rim to within 2mm of the tiles (fig. 1) 2. Unscrew the allen bolts and remove the flushing plate. Seal the gap between the plastic box and the tiles (fig.
  • Page 10 4. Place the fixing plate over the valve and fix with the 4 x 50mm screws supplied (fig. 4). 5. Push the sleeve onto the thermostat cartridge ensuring the notch on the sleeve is in the 12 o'clock position. Fit the faceplate over the sleeve and push-fit evenly into place.
  • Page 11: Commissioning And In-Service Tests Commissioning

    Commissioning and in-service tests Commissioning record the equipment, thermometer etc. used for the measurements Purpose Table A: Guide to maximum stabilised Since the installed supply conditions are likely to temperatures recorded during site be different from those applied in the laboratory tests tests it is appropriate, at commissioning, to carry Application...
  • Page 12: In-Service Tests

    In-service tests Frequency of in-service tests TMV3* Purpose General In the absence of any other instruction or guidance The purpose of in-service tests is to regularly monitor on the means of determining the appropriate and record the performance of the thermostatic frequency of in-service testing, the following mixing valve.
  • Page 13: Thermostatic Adjustement

    Thermostatic Adjustment Temperature Limitation The temperature is limited by the safety stop to 40°C. If a higher temperature is required, it is possible to over ride the safety stop by depressing the safety 40° button. NB. It is recommended that for private domestic use the maximum mixed water temperature be set at the following factory set values: Shower Mixer 43°C...
  • Page 14: Setting Thermostat Max. Temp

    Setting thermostat to a maximum temperature (Optional) The desired maximum temperature (43°C) can be preset using the safety function. Proceed as follows: 1. Undo the screw and pull off the handle. Undo the fixing screw. (fig.1). 2. Remove the faceplate, the sleeve and the spindle extension (fig.2).
  • Page 15: Operating Your Shower

    Operating your Shower Cleaning Cleaning materials for Mixers and Temperature Control Showers Turn the thermostat handle anti-clockwise to increase Acids are necessary ingredients of cleaning the water temperature and clockwise to decrease materials for removing lime. However please pay the water temperature. particular attention to the following points when cleaning mixers and showers: Thermostatic...
  • Page 16: Spare Parts

    Spare Parts Thermostat kit 1 Handle for thermostatic element 38391000 2 Cover plate 98981000 3 Sleeve 97439000 4 Fixing screws 96454000 5 Fixing plate 98793000 6 Thermostatic element 96633000 7 Filter 97367000 8 Check valve 96655000...
  • Page 17: Trouble Shooting

    Trouble Shooting Fault Cause Remedy Insuffient water flow - Supply pressure inadequate - Check mains pressure - Shower filter seal dirty - Clean filter seal between shower and hose - Thermostat cartridge filters dirty - Remove cartridge & clean the filters on the barrel ,Crossflow‘, hot water is forced - check valves dirty or leaking...
