Serial Video Inputs (optional)
Standard SD, HD, 3Gb/s, 12Gbps SDI: ST259M, ST292M, ST424M, ST2082
Number of inputs 8
Connector type Micro BNC (HD BNC)
Signal level 800 mV
DC offset 0V ±0.5V
Overshoot Within 10% of signal level
Return loss >15dB up to 1.5GHz, >10dB up to 3Ghz, >7dB up to 6Ghz, >4dB up to 12Ghz
Serial Video Outputs (optional)
Standard SD, HD, 3Gb/s, 12Gbps SDI: ST259M, ST292M, ST424M, ST2082
Number of outputs 8
Connector type Micro BNC (HD BNC)
Signal level 800 mV
DC offset 0V ±0.5V
Overshoot Within 10% of signal level
Wideband Jitter <0.2UI
Return loss >15dB up to 1.5GHz, >10dB up to 3Ghz, >7dB up to 6Ghz, >4dB up to 12Ghz
Serial Video Bi-directional Connections (optional)
Standard
Number of connectors
Connector
Signal level
DC offset
Overshoot
Return loss
14 | February 2022 | Issue 4.9.C
SD,HD, 3Gb/s SDI: ST259M, ST292M, ST424M
24
Micro BNC (HD BNC)
800mV nominal
0V ±0.5V
Within 10% of signal level
>15dB up to 1.5GHz, >10dB up to 3Ghz
