Altronix NetWaySP8A Installation Manual page 3

Recommended Altronix SFP Modules:
Altronix P1MM and P1SM10 are hot-pluggable SFP fiber transceiver modules and are readily usable with all
Altronix Spectrum fiber optic equipment for 1Gb transmission rates.
P1MM - For use with Multi-Mode Fiber for distances up to 550m.
P1SM10 - For use with Single-Mode Fiber for distances up to 10km.
Fig. 2
NetWay Spectrum
Ethernet over Fiber
Data & PoE
PoE Switch
30W/60W
Media Converter
NetWaySP16A - Front Panel
NetWaySP16A - Rear Panel
1 2
9 10
Parameter Description
NetWaySP8A:
Number of Ports
(SFP / Ethernet) NetWaySP16A:
Input Power NetWaySP8A:
Requirements NetWaySP16A:
Operating Ambient Temperature (50W): – 40ºC to 50ºC (– 40ºF to 122ºF)
Environmental Relative Humidity: 85%, +/– 5%
Conditions Storage Temperature: – 40ºC to 85ºC (– 40ºF to 185ºF).
Operating Altitude: – 304.8 to 2,000m.
Regulatory
I.T.E. 43KC
Compliance
NetWaySP8A:
Weights (approx.)
NetWaySP16A:
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence
of an insulated DANGEROUS VOLTAGE within the product's enclosure that may be of sufficient magnitude to
constitute an electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating
and maintenance (servicing) instructions in the literature accompanying the appliance.
NetWaySP8A / NetWaySP16A
All manuals and user guides at all-guides.com
Typical Application:
or
Fiber from
NetWaySP16A NetWaySP16A
SFP 1 SFP 2
SFP 9 SFP 10
3 4 5
11 12 13
Switch
Technical Specifications:
Eight (8) Gigabit SFP Ports.
Eight (8) ports 10/100/1000Mbps Ethernet ports.
Sixteen (16) Gigabit SFP Ports.
Sixteen (16) ports 10/100/1000Mbps Ethernet ports.
115VAC, 60Hz, 0.5A or 230VAC, 50/60Hz, 0.3A.
115VAC, 60Hz, 1.0A or 230VAC, 50/60Hz, 0.5A.
UL/cUL Listed for Information Technology Equipment (UL 60950-1)
CE European Conformity.
Product: 3.81 lb. (1.72kg)
Product: 4.5 lb. (2.04kg)
CAUTION: To reduce the risk of electric shock do not open enclosure.
There are no user serviceable parts inside. Refer servicing to qualified service personnel.
NetWay Spectrum
Ethernet over Fiber
PoE Switch
or
Media Converter
Fiber from
SFP 3 SFP 4 SFP 5
SFP 11 SFP 12 SFP 13
6 7 8
14 15 16
| Shipping: 6.00 lb. (2.72kg)
| Shipping: 6.69 lb. (3.03kg)
Data & PoE
30W/60W
SFP 6 SFP 7 SFP 8
SFP 14 SFP 15 SFP 16
115/230VAC Input
- 3 -
