内蔵ハードディスクユニット- 9 G B (P G - H D 9 G 1 C ) 内蔵ハードディスクユニット- 1 8 G B (P G - H D 8 G 1 C ) 内蔵ハードディスクユニット- 3 6 G B (P G - H D 6 G 1 C ) HARD DISK DRIVE 9GB (PG-HD9G1C) HARD DISK DRIVE 18GB (PG-HD8G1C) HARD DISK DRIVE 36GB (PG-HD6G1C)...
Page 9
To ensure correct operation, read this manual carefully before using the product. Verify that all the required components have been included in this package. Hard disk drive 9GB (PG-HD9G1C) or Hard disk drive 18GB (PG-HD8G1C) or Hard disk drive 36GB (PG-HD6G1C)
Contents 1 Introduction ................1 2 Drive settings ................. 1 3 Notes on Settings ..............3 4 Notes on Handling ..............3 5 Before Using the Hard Disk Drive ......... 4 6 Specifications ................ 4...
1 Introduction 1.1 Internal Hard Disk Unit This device is made for PRIMERGY series of servers and employs a SCSI (Small Computer System Interface) interface. 1.2 OverView The actual product has the frame for installing to the storage bay of the server. Power supply connector Interface connector...
Page 12
2.2 Drive number (SCSI) Settings SCSI ID Settings Drive number Pin number:1-2 Pin number:3-4 Pin number:5-6 Pin number:7-8 Open Open Open Open Short Open Open Open Open Short Open Open Short Short Open Open Open Open Short Open Short Open Short Open Open...
3 Notes on Settings If the setting pins need to be changed, use caution to prevent damage to the PC board ● beneath them. Do not touch any other pins and/or switches other than the SCSI ID/Terminator setting ● pin. 4 Notes on Handling CAUTION The hard disk is a precision device.
Do not enable the write cache in the hard disk drives even if some operating systems ● provide functions to enable. Data in the write cache may be lost in such a case of unexpected power failure. 6 Specifications PG-HD6G1C/PG-HD8G1C/PG-HD9G1C/ ● Type PG-HD6G1C PG-HD8G1C...
Page 15
内蔵ハードディスクユニット -36GB(PG-HD6G1C) 取扱説明書 Hard disk drive 9GB(PG-HD9G1C) Hard disk drive 18GB(PG-HD8G1C) Hard disk drive 36GB(PG-HD6G1C) User's Guide P3FY-1480-02-00 発 行 日 2001年 7月 発行責任 富士通株式会社 Issued on July, 2001 Issued by FUJITSU LIMITED Printed in Japan ● 本書の内容は、改善のため事前連絡なしに変更することがあります。 ● 本書に記載されたデータの使用に起因する第三者の特許権およびその 他の権利の侵害については、当社はその責を負いません。 ● 無断転載を禁じます。 ● The contents of this manual may be revised without prior notice. ● Fujitsu assumes no liability for damages to third party copyrights or other rights arising from the use of any information in this manual. ● No part of this manual may be reproduced in any form without the prior written permission of Fujitsu.
