    Store this manual carefully so that it can be referenced any time while using the product. What is CAUTION symbols indicate the following risks may be involved if the product is CAUTION incorrectly handled or operated: Personal Injury Damage to the product or mainframe of the computer All Rights Reserved, Copyright© FUJITSU LIMITED 2002...

  • Page 11

    1. Outline 1.1 Outline of the Hard Disk Drive This product is the hard disk with IDE (Integrated Device Electronics) Interface. 1.2 Appearance In case of PG-HD4E7C the product has the frame for installing to the storage bay of the server.

  • Page 12: Installing The Drive

    2. Installing the Drive To install and use this product with the mainframe, see the User’s Guide included with the mainframe. Before installation, setting pins for drive type must be set. Setting Drive Type Master(at shipment) Slave Cable Select Bottom In Cable Select mode, the drive can be configured either master drive or slave drive.

  • Page 13: Notes On Handling

    3. Notes on Handling CAUTION The hard disk is a precision device. Strictly observe the following when handling the product; otherwise, the product and/or the data in the disk may be destroyed. Do not touch the connector section and/or the component installation surface of the PC board when handling the product.

  • Page 14: Specifications

    4. Before Using the Hard Disk Drive Before using this product, perform the required setting changes by referencing the included related hardware and software manuals. 5. Specifications GP5-HD4E71/PG-HD4E7C Type GP5-HD4E71/PG-HD4E7C Interface Storage media 3.5-inch hard disk Storage capacity* 40.0GB Average rotational 4.16ms...

  • Page 15

    User's Guide B7FY-0571-01-00 Issued on July, 2002 Issued by FUJITSU LIMITED...
