Page 1 C141-E280-01EN MHZ2320BJ, MHZ2250BJ, MHZ2200BJ, MHZ2160BJ, MHZ2120BJ, MHZ2080BJ DISK DRIVES PRODUCT/MAINTENANCE MANUAL...
Page 2 “Important Alert Items” in this manual. Keep this manual handy, and keep it carefully. FUJITSU makes every effort to prevent users and bystanders from being injured or from suffering damage to their property. Use the product according to this manual.
Page 3: Revision History
Revision History (1/1) Revised section (*1) Edition Date Details (Added/Deleted/Altered) 2008-03-31 *1 Section(s) with asterisk (*) refer to the previous edition when those were deleted. C141-E280...
Page 4 This page is intentionally blank. left...
Page 5 This manual describes MHZ2320BJ, MHZ2250BJ, MHZ2200BJ, MHZ2160BJ, MHZ2120BJ, MHZ2080BJ model of the MHZ Series, 2.5-inch hard disk drives. These drives have a built-in controller that is compatible with the Serial-ATA interface. This manual describes the specifications and functions of the drives and explains in detail how to incorporate the drives into user systems.
Page 6: Operating Environment
Preface Acronyms and Abbreviations This section gives the meanings of the definitions used in this manual. Conventions for Alert Messages This manual uses the following conventions to show the alert messages. An alert message consists of an alert signal and alert statements. The alert signal consists of an alert symbol and a signal word or just a signal word.
Page 7 "Disk drive defects" refers to defects that involve adjustment, repair, or replacement. Fujitsu is not liable for any other disk drive defects, such as those caused by user misoperation or mishandling, inappropriate operating environments, defects in the power supply or cable, problems of the host system, or other causes outside the disk drive.
Page 8: Hot Plug
Preface Hot Plug These drives support Hot Plug which is based on Serial ATA Revision 2.6 Specification. However, the disk drive installation and removal notes on safety precautions with regard to hot-plugging vary depending on the specific requirements and environment-related conditions of the system to which the drive is connected by hot-plugging.
Page 9: Important Alert Items
Important Alert Items Important Alert Messages The important alert messages in this manual are as follows: A hazardous situation could result in minor or moderate personal injury if the user does not perform the procedure correctly. Also, damage to the product or other property, may occur if the user does not perform the procedure correctly.
Page 10 Data corruption When asking for repair, save all data stored in the disk drive beforehand. Fujitsu Limited is not responsible for any loss of data during service and repair. Device damage The disk enclosure (DE) must never to be opened in the field.
Page 11: Manual Organization
Manual Organization MHZ2320BJ, MHZ2250BJ, MHZ2200BJ, MHZ2160BJ, MHZ2120BJ, MHZ2080BJ DISK DRIVES PRODUCT/MAINTENANCE MANUAL (C141-E280) <This manual> C141-E280 • Device Overview • Device Configuration • Installation Conditions • Theory of Device Operation • Interface • Operations • Maintenance and Diagnosis...
Page 12 This page is intentionally left blank.
Page 13: Table Of Contents
CHAPTER 1 Device Overview ... 1-1 Features ... 1-2 1.1.1 Functions and performance... 1-2 1.1.2 Adaptability ... 1-2 1.1.3 Interface ... 1-3 Device Specifications... 1-5 1.2.1 Specifications summary... 1-5 1.2.2 Model and product number... 1-7 Power Requirements ... 1-8 Environmental Specifications ... 1-11 Acoustic Noise ...
Page 14 Contents System Configuration...2-3 2.2.1 SATA interface ...2-3 2.2.2 Drive connection...2-3 CHAPTER 3 Installation Conditions... 3-1 Dimensions...3-2 Mounting ...3-3 Connections with Host System...3-9 3.3.1 Device connector ...3-9 3.3.2 Signal segment and power supply segment ...3-10 3.3.3 Connector specifications for host system...3-10 3.3.4 SATA interface cable connection ...3-11 3.3.5...
Page 15 4.6.3 Read circuit... 4-11 4.6.4 Digital PLL circuit... 4-11 Servo Control ... 4-12 4.7.1 Servo control circuit ... 4-12 4.7.2 Data-surface servo format... 4-14 4.7.3 Servo frame format ... 4-16 4.7.4 Actuator motor control ... 4-17 4.7.5 Spindle motor control ... 4-18 CHAPTER 5 Interface...
Page 16 Contents (9) DOWNLOAD MICROCODE (X '92') ... 5-43 (10) STANDBY IMMEDIATE (X '94' or X 'E0')... 5-46 (11) IDLE IMMEDIATE (X '95' or X 'E1')/UNLOAD IMMEDIATE (X '95' or X 'E1')... 5-47 (12) STANDBY (X '96' or X 'E2')... 5-49 (13) IDLE (X '97' or X 'E3') ...
Page 17 (44) SET MAX ADDRESS EXT (X '37')... 5-156 (45) WRITE MULTIPLE EXT (X '39') ... 5-158 (46) WRITE DMA FUA EXT (X '3D')... 5-159 (47) WRITE LOG EXT (X '3F') ... 5-160 (48) READ VERIFY SECTOR(S) EXT (X '42') ... 5-164 (49) WRITE UNCORRECTABLE EXT (X '45') ...
Page 18 Contents Read-ahead Cache ...6-13 6.4.1 Data buffer structure ...6-13 6.4.2 Caching operation ...6-14 6.4.3 Using the read segment buffer ...6-16 Write Cache...6-20 6.5.1 Cache operation ...6-20 CHAPTER 7 Maintenance and Diagnosis ... 7-1 Maintenance ...7-2 7.1.1 Rules for maintenance...7-2 7.1.2 Maintenance requirements ...7-3 7.1.3 Maintenance levels...7-5...
Page 19 Figures Figure 1.1 Permissible range of +5V rise slope... 1-8 Figure 1.2 The example of negative voltage waveform at +5 V when power is turned off ... 1-9 Figure 1.3 Current fluctuation (Typ.) at +5 V when power is turned on... 1-11 Figure 2.1 Disk drive outerview ...
Page 20 Contents Figure 5.12 Execution example of READ MULTIPLE command...5-90 Figure 5.13 Non-data command protocol ...5-177 Figure 5.14 PIO data-in command protocol...5-179 Figure 5.15 PIO data-out command protocol...5-181 Figure 5.16 DMA data-in command protocol...5-182 Figure 5.17 DMA data-out command protocol...5-183 Figure 5.18 READ FP DMA QUEUED command protocol ...5-185 Figure 5.19 WRITE FP DMA QUEUED command protocol ...5-186 Figure 5.20 Power-on sequence...5-187 Figure 5.21 COMRESET sequence ...5-188...
Page 21 Tables Table 1.1 Specifications ... 1-5 Table 1.2 Examples of model names and product numbers ... 1-7 Table 1.3 Current and power dissipation... 1-10 Table 1.4 Environmental specifications ... 1-11 Table 1.5 Acoustic noise specification... 1-12 Table 1.6 Shock and vibration specification ... 1-12 Table 1.7 Advanced Power Management...
Page 22 Contents Table 5.27 WRITE SAME ...5-77 Table 5.28 ERROR RECOVERY CONTROL...5-78 Table 5.29 FEATURE CONTROL COMMAND ...5-79 Table 5.30 SCT DATA TABLE...5-80 Table 5.31 HDA Temperature ...5-81 Table 5.32 DEVICE CONFIGURATION IDENTIFY data structure...5-87 Table 5.33 Information to be read by IDENTIFY DEVICE command...5-105 Table 5.34 Features field values and settable modes...5-119 Table 5.35 Contents of SECURITY SET PASSWORD data...5-126 Table 5.36 Relationship between combination of Identifier and...
Page 23: Chapter 1 Device Overview
CHAPTER 1 Device Overview Features Device Specifications Power Requirements Environmental Specifications Acoustic Noise Shock and Vibration Reliability Error Rate Media Defects 1.10 Load/Unload Function 1.11 Advanced Power Management (APM) 1.12 Interface Power Management (IPM) Overview and features are described in this chapter, and specifications and power requirement are described.
Page 24: Features
320 GB (MHZ2320BJ), 250 GB (MHZ2250BJ), 200 GB (MHZ2200BJ), 160 GB (MHZ2160BJ), 120 GB (MHZ2120BJ), and 80 GB (MHZ2080BJ) respectively. (4) High-speed Transfer rate The disk drive (the MHZ2xxxBJ Series) has an internal data rate up to 118.4 MB/s.
Page 25: Interface
2.0 B [MHZ2160BJ/MHZ2120BJ/ MHZ2080BJ] / 2.5 B [MHZ2320BJ/MHZ2250BJ/ MHZ2200BJ]. The Sound Pressure level is 23 dB [MHZ2160BJ/MHZ2120BJ/ MHZ2080BJ] / 29 dB [MHZ2320BJ/MHZ2250BJ/ MHZ2200BJ], as measured 0.3 m from the drive in Idle mode.
Page 26 Device Overview (6) Write cache When the disk drive receives a write command, the disk drive posts the command completion at completion of transferring data to the data buffer completion of writing to the disk media. This feature reduces the access time at writing. C141-E280...
Page 27: Device Specifications
118.4 MB/s Max. 1.5 Gbps (150 MB/s) (Gen1i) [1.5 Gbps model] 16 MB (16,777,216 bytes) 9.5 mm × 100.0 mm × 70.0 mm (*6) 115 g (Max.) 1.2 Device Specifications MHZ2120BJ MHZ2080BJ 120 GB 80 GB 234,441,648 156,301,488 107 g (Max.)
Page 28 8.45 GB MHZ2160BJ 8.45 GB MHZ2120BJ 8.45 GB MHZ2080BJ 8.45 GB *1: One gigabyte (GB) = one billion bytes; accessible capacity will be less and actual capacity depends on the operating environment and formatting. No. of Cylinder No. of Heads...
Page 29: Model And Product Number
MHZ2160BJ 160 GB MHZ2120BJ 120 GB MHZ2080BJ 80 GB *1: One gigabyte (GB) = one billion bytes; accessible capacity will be less and actual capacity depends on the operating environment and formatting. *2: Serial ATA Generation-1 (1.5 Gbps) is also supported.
Page 30: Power Requirements
Device Overview 1.3 Power Requirements (1) Input Voltage ± 5 % • + 5 V • It is unnecessary for this drive to supply +3.3 V and +12 V power supplies. (2) Ripple Maximum Frequency (3) Slope of an input voltage at rise The following figure shows the restriction of the slope which is +5 V input voltage at rise.
Page 31: Figure 1.2 The Example Of Negative Voltage Waveform At +5 V When Power Is Turned Off
(4) A negative voltage like the bottom figure isn't to occur at +5 V when power is turned off and, a thing with no ringing. Permissible level: − 0.2 V Figure 1.2 The example of negative voltage waveform at +5 V C141-E280 Time [ms] when power is turned off...
Page 32: Table 1.3 Current And Power Dissipation
(0.0025 W/GB): MHZ2320BJ e rank (0.0032 W/GB): MHZ2250BJ e rank (0.0040 W/GB): MHZ2200BJ ⎯ d rank (0.0050 W/GB): MHZ2160BJ d rank (0.0067 W/GB): MHZ2120BJ d rank (0.0100 W/GB): MHZ2080BJ Gen2 (3.0 Gbps) 5.5 W 0.80 W 2.3 W 2.5 W 0.13 W...
Page 33: Environmental Specifications
(6) Current fluctuation (Typ.) at +5 V when power is turned on Figure 1.3 Current fluctuation (Typ.) at +5 V when power is turned on 1.4 Environmental Specifications Table 1.4 lists the environmental specifications. Table 1.4 Environmental specifications Item Temperature •...
Page 34: Acoustic Noise
Vibration (Swept sine, 1/4 octave per minute) • Operating Non-operating Shock (half-sine pulse) • Operating • Non-operating 1-12 Specification 2.0 B [MHZ2160BJ/MHZ2120BJ/MHZ2080BJ] 2.5 B [MHZ2320BJ/MHZ2250BJ/MHZ2200BJ] 23 dB [MHZ2160BJ/MHZ2120BJ/MHZ2080BJ] 29 dB [MHZ2320BJ/MHZ2250BJ/MHZ2200BJ] Specification 5 to 500 Hz, 9.8m/s (without non-recovered errors) 5 to 500 Hz, 49m/s...
Page 35: Reliability
1.7 Reliability (1) Mean time between failures (MTBF) Conditions of 300,000 h MTBF is defined as follows: Total operation time in all fields MTBF= number of device failure in all fields (*1) *1 "Disk drive defects" refers to defects that involve repair, readjustment, or replacement.
Page 36: Error Rate
Device Overview 1.8 Error Rate Known defects, for which alternative blocks can be assigned, are not included in the error rate count below. It is assumed that the data blocks to be accessed are evenly distributed on the disk media. (1) Unrecoverable read error Read errors that cannot be recovered by maximum read retries of drive without user's retry and ECC corrections shall occur no more than 1 time when reading...
Page 37: Recommended Power-Off Sequence
When the power is shut down, the controlled Unload cannot be executed. Therefore, the number of Emergency other than Unload is specified. 1.10.1 Recommended power-off sequence We recommend cutting the power supply of the HDD for this device after the Head Unload operation completes.
Page 38: Table 1.7 Advanced Power Management
Device Overview Active Idle: Low Power Idle: Standby: In APM Mode-1, which is the APM default mode, the operation status shifts till it finally reaches "Low Power Idle." Table 1.7 Advanced Power Management APM Mode Mode-0 Mode-1 Mode-2 When the maximum time that the HDD is waiting for commands has been exceeded: Mode-0: Mode shifts from Active condition to Active Idle in 0.2-1.2, and to Low Power Idle in 15 minutes.
Page 39: Interface Power Management (Ipm)
1.12 Interface Power Management (IPM) 1.12.1 Host-initiated interface power management (HIPM) When the disk drive is waiting for commands, it can enter one of three IPM modes as requested by the host. The three IPM modes are: 1) Partial mode: 2) Slumber mode: PMREQ_S is sent when the host requests the Slumber mode.
Page 40: Table 1.8 Interface Power Management
Device Overview Table 1.8 Interface power management IPM Mode I/F power state Active Active State Partial Partial State Slumber Slumber State 1-18 Return time to active I/F condition − Active 5 to 10 µs maximum Power Down 5 to 10 ms maximum Power Down C141-E280...
Page 41: Chapter 2 Device Configuration
CHAPTER 2 Device Configuration Device Configuration System Configuration This chapter describes the internal configurations of the hard disk drives and the configuration of the systems in which they operate. C141-E280...
Page 42: Figure 2.1 Disk Drive Outerview
Device Configuration 2.1 Device Configuration Figure 2.1 shows the disk drive. The disk drive consists of a disk enclosure (DE), read/write preamplifier, and controller PCA. The disk enclosure contains the disk media, heads, spindle motor, actuator, and a circulating air filter. Figure 2.1 Disk drive outerview (1) Disk The outer diameter of the disk is 65 mm.
Page 43: System Configuration
(5) Air circulation system The disk enclosure (DE) is sealed to prevent dust and dirt from entering. The disk enclosure features a closed loop air circulation system that relies on the blower effect of the rotating disk. This system continuously circulates the air through the circulation filter to maintain the cleanliness of the air within the disk enclosure.
Page 44 This page is intentionally blank. left...
Page 45: Chapter 3 Installation Conditions
CHAPTER 3 Installation Conditions Dimensions Mounting Connections with Host System This chapter gives the external dimensions, installation conditions, surface temperature conditions, cable connections, and switch settings of the hard disk drives. C141-E280...
Page 46: Dimensions
Installation Conditions 3.1 Dimensions Figure 3.1 illustrates the dimensions of the disk drive. All dimensions are in mm. The PCA and connectors are not included in these dimensions. Dimension from the center of the user tap to the base of the connector pins Length of the connector pins Dimension from the outer edge of the user tap to the center of the connector pins...
Page 47: Mounting
3.2 Mounting For information on mounting, see the "FUJITSU 2.5-INCH HDD INTEGRATION GUIDANCE (C141-E144)." (1) Orientation The disk drives can be mounted in any direction. (2) Frame The MR head bias of the HDD disk enclosure (DE) is zero. The mounting frame is connected to Signal Ground (SG).
Page 48: Figure 3.2 Mounting Frame Structure
Installation Conditions (3) Limitation of mounting Note) These dimensions are recommended values; if it is not possible to satisfy them, contact us. Bottom surface mounting Frame of system cabinet 3.0 or less Details of A Figure 3.2 Mounting frame structure Side surface mounting Frame of system...
Page 49: Figure 3.3 Location Of Breather
3.2 Mounting Because of breather hole mounted to the HDD, do not allow this to close during mounting. Locating of breather hole is shown as Figure 3.3. For breather hole of Figure 3.3, at least, do not allow its around φ 3 to block.
Page 50: Figure 3.4 Surface Cover Temperature Measurement Points
Installation Conditions (4) Ambient temperature The temperature conditions for a disk drive mounted in a cabinet refer to the ambient temperature at a point 3 cm from the disk drive. The ambient temperature must satisfy the temperature conditions described in Section 1.4, and the airflow must be considered to prevent the DE surface cover temperature from exceeding 60 °C.
Page 51: Figure 3.5 Service Area
(5) Service area Figure 3.5 shows how the drive must be accessed (service areas) during and after installation. Mounting screw hole Cable connection Data corruption: Avoid mounting the disk drive near strong magnetic sources such as loud speakers. Ensure that the disk drive is not affected by external magnetic fields.
Page 52: Figure 3.6 Handling Cautions
Installation Conditions General notes Wrist strap Use the Wrist strap. Do not hit HDD each other. Do not place HDD vertically to avoid falling down. Figure 3.6 Handling cautions Installation Please use the driver of a low impact when you use an electric driver. HDD is occasionally damaged by the impact of the driver.
Page 53: Connections With Host System
3.3 Connections with Host System 3.3.1 Device connector The disk drive has the SATA interface connectors listed below for connecting external devices. Figure 3.7 shows the locations of these connectors and terminals. SATA interface and power connectors Figure 3.7 Connector locations C141-E280 3.3 Connections with Host System...
Page 54: Signal Segment And Power Supply Segment
Installation Conditions 3.3.2 Signal segment and power supply segment Figure 3.8 shows each segment of the SATA interface connector and pin numbers. Power supply segment P1 pins in the power supply segment Figure 3.8 Power supply pins (CN1) 3.3.3 Connector specifications for host system The connector of host system for mating with the disk drive must be compliant with Serial-ATA Revision 2.5 specification.
Page 55: Sata Interface Cable Connection
3.3.4 SATA interface cable connection The cable that connects the disk drive to the host system must be compliant with the Serial ATA Revision 2.6 specification. 3.3.5 Note about SATA interface cable connection Take note of the following precaution about plugging a SATA interface cable into the SATA interface connector of the disk drive and plugging the connector into a host receptacle: When plugging together the disk drive SATA interface connector...
Page 56 This page is intentionally blank. left...
Page 57: Chapter 4 Theory Of Device Operation
CHAPTER 4 Theory of Device Operation Outline Subassemblies Circuit Configuration Power-on Sequence Self-calibration Read/write Circuit Servo Control This chapter explains basic design concepts of the disk drive. Also, this chapter explains subassemblies of the disk drive, each sequence, servo control, and electrical circuit blocks.
Page 58: Outline
Theory of Device Operation 4.1 Outline This chapter consists of two parts. First part (Section 4.2) explains mechanical assemblies of the disk drive. Second part (Sections 4.3 through 4.7) explains a servo information recorded in the disk drive and drive control method. 4.2 Subassemblies The disk drive consists of a disk enclosure (DE) and printed circuit assembly (PCA).
Page 59: Air Filter
4.2.4 Air filter There are two types of air filters: a breather filter and a circulation filter. The breather filter makes an air in and out of the DE to prevent unnecessary pressure around the spindle when the disk starts or stops rotating. When disk drives are transported under conditions where the air pressure changes a lot, filtered air is circulated in the DE.
Page 60: Figure 4.1 Power Supply Configuration
Theory of Device Operation (4) Controller circuit Major functions are listed below. • Serial-ATA interface control and data transfer control • Data buffer management • Sector format control • Defect management • ECC control • Error recovery and self-diagnosis S-DRAM Serial-FROM MCU &...
Page 61: Figure 4.2 Circuit Configuration
4.3 Circuit Configuration Serial-ATA Interface Data Buffer MCU & HDC & RDC SDRAM Serial Flash ROM Shock Sensor Crystal SP Motor Thermistor R/W Pre-Amp HEAD Media Figure 4.2 Circuit configuration C141-E280...
Page 62: Power-On Sequence
Theory of Device Operation 4.4 Power-on Sequence Figure 4.3 describes the operation sequence of the disk drive at power-on. The outline is described below. a) After the power is turned on, the disk drive initializes its SATA interface block. b) The disk drive executes the MPU bus test, internal register read/write test, and work RAM read/write test.
Page 63: Figure 4.3 Power-On Operation Sequence
Power-on Start SATA I/F Initialization Self-diagnosis 1 - MPU bus test - Internal register write/read test - Work RAM write/read test The spindle motor starts. Self-diagnosis 2 - Data buffer write/read test Confirming spindle motor speed Load the head assembly Figure 4.3 Power-on operation sequence C141-E280 4.4 Power-on Sequence...
Page 64: Self-Calibration
Theory of Device Operation 4.5 Self-calibration The disk drive occasionally performs self-calibration in order to sense and calibrate mechanical external forces on the actuator, and VCM torque. This enables precise seek and read/write operations. 4.5.1 Self-calibration contents (1) Sensing and compensating for external forces The actuator suffers from torque due to the FPC forces and winds accompanying disk revolution.
Page 65: Execution Timing Of Self-Calibration
To compensate torque constant value change depending on cylinder, whole cylinders from most inner to most outer cylinder are divided into 13 partitions at calibration in the factory, and the compensation data is measured for representative cylinder of each partition. This measured value is stored in the SA area.
Page 66: Read/Write Circuit
Theory of Device Operation 4.6 Read/write Circuit The read/write circuit consists of the read/write preamplifier (PreAMP), the write circuit, the read circuit, and the time base generator in the read channel (RDC) block which is integrated into LSI. Figure 4.4 is a block diagram of the read/write circuit.
Page 67: Read Circuit
4.6.3 Read circuit The head read signal from the PreAMP is regulated by the automatic gain control (AGC) circuit. Then the output is converted into the sampled read data pulse by the programmable filter circuit and the flash digitizer circuit. This signal is converted into the read data by the decoder circuit based on the read data maximum-likelihood-detected by the Viterbi detection circuit.
Page 68: Servo Control
Theory of Device Operation 4.7 Servo Control The actuator motor and the spindle motor are submitted to servo control. The actuator motor is controlled for moving and positioning the head to the track containing the desired data. To turn the disk at a constant velocity, the actuator motor is controlled according to the servo data that is written on the data side beforehand.
Page 69 (1) Microprocessor unit (MPU) The MPU executes startup of the spindle motor, movement to the reference cylinder, seek to the specified cylinder, and calibration operations. The main internal operations of the MPU are shown below. Spindle motor start Starts the spindle motor and accelerates it to normal speed when power is applied.
Page 70: Data-Surface Servo Format
Theory of Device Operation (6) Driver circuit The driver circuit is a power amplitude circuit that receives signals from the spindle motor control circuit and feeds currents to the spindle motor. (7) VCM current sense resistor (CSR) This resistor controls current at the power amplifier by converting the VCM current into voltage and feeding back.
Page 71: Figure 4.6 Physical Sector Servo Configuration On Disk Surface
CYLn CYLn + 1 W/R Recovery W/R Recovery Servo Mark Servo Mark Gray Code Gray Code EVEN1 EVEN2 Post code Figure 4.6 Physical sector servo configuration on disk surface C141-E280 Servo frame (162 servo frames per revolution) CYLn – 1 (n: even number) W/R Recovery Servo Mark Gray Code...
Page 72: Servo Frame Format
Theory of Device Operation 4.7.3 Servo frame format As the servo information, the IDD uses the phase signal servo generated from the gray code and servo EVEN and ODD. This servo information is used for positioning operation of radius direction and position detection of circumstance direction.
Page 73: Actuator Motor Control
4.7.4 Actuator motor control The voice coil motor (VCM) is controlled by feeding back the servo data recorded on the data surface. The MPU fetches the position sense data on the servo frame at a constant interval of sampling time, executes calculation, and updates the VCM drive current.
Page 74: Spindle Motor Control
Hall-less three-phase twelve-pole motor is used for the spindle motor, and the PWM type current control circuit is used as the spindle motor driver (called SVC hereafter). The firmware operates on the MPU manufactured by Fujitsu. The spindle motor is controlled by sending several signals including the serial data from the MPU to the SVC.
Page 75: Chapter 5 Interface
CHAPTER 5 Interface Physical Interface Logical Interface Host Commands Command Protocol Power-on and COMRESET This chapter gives details about the interface, and the interface commands and timings. C141-E280...
Page 76: Physical Interface
Interface 5.1 Physical Interface 5.1.1 Interface signals Figure 5.1 shows the interface signals. TX data TX− RX data Host analog front RX− ComWake ComInit Figure 5.1 Interface signals An explanation of each signal is provided below. TX + / TX - These signals are the outbound high speed differential signals that are connected to the serial ATA cable.
Page 77 RxData Serially encoded 10b data attached to the high speed serial differential line receiver COMWAKE Signal from the out of band detector that indicates the COMWAKE out of band signal is being detected. COMRESET / COMINIT Host: Signal from the out of band detector that indicates the COMINIT out of band signal is being detected.
Page 78: Signal Interface Regulation
Interface 5.1.2 Signal interface regulation 5.1.2.1 Out of band signaling During OOB signaling transmissions, the differential and common mode levels of the signal lines shall comply with the same electrical specifications as for in-band data transmission, specified as follows. COMRESET/COMINIT COMWAKE 106.7 ns 106.7 ns...
Page 79 5.1.2.2 Primitives descriptions The following table contains the primitive mnemonics and a brief description of each. Primitive Name ALIGN Physical layer control CONT Continue repeating previous primitive End of frame PMACK Power management acknowledge HOLD Hold data transmission HOLDA Hold acknowledge PMNAK Power management denial...
Page 80: Electrical Specifications
Interface Primitive Name R_IP Reception in progress R_OK Reception with no error R_RDY Receiver ready Start of frame SYNC Synchronization WTRM Wait for frame termination X_RDY Transmission data ready 5.1.3 Electrical specifications For the electrical requirements of physical layer, refer to "Electrical specifications" section in the "Serial-ATA Revision 2.6."...
Page 81: Connector Pinouts
5.1.4 Connector pinouts The pin definitions are shown in Table 5.1. Table 5.1 Connector pinouts "Key and spacing separate signal and power segments" Staggered Spin-up Mode/ Activity Power segment key Notes: Note) Since applying a single external supply voltage of 5 V enables this drive to operate it is unnecessary to supply +3.3 V and +12 V power supplies.
Page 82: P11 Function
Interface 5.1.5 P11 function The disk drive supports the following functions when P11 pin in the power supply segment of interface connector is used as an input or output pin. P11 pin supports the functions as follows: • Staggered Spin-up: •...
Page 83: Figure 5.2 Example Of The Circuit For Driving Activity Led
5.1 Physical Interface Table 5.2 Requirements for P11 as an output pin Asserted Deasserted ≤ 0.7V ≥ 0.7V +50uA Figure 5.2 Example of the circuit for driving Activity LED C141-E280...
Page 84: Hot Plug
Interface 5.1.6 Hot Plug The disk drive is "Hot Plug Capable" which is based on Serial ATA Revision 2.6. It is recommended to use the pre-charge resistor for protection from over current at +5V power supply circuit in the host system when the disk drive is hot-plugged. (Refer to the Serial ATA Revision 2.6.) The equivalent circuit of +5V power supply at Hot Plugging is in the following figure.
Page 85: Logical Interface
5.2 Logical Interface The host system and the device communicate with each other by sending and receiving serial data. The host and the device have several dedicated communication layers between them. These layers have different functions, enabling communication between the different levels of layers within the host or device and between layers at the same level that link the host and device.
Page 86: Communication Layers
Interface 5.2.1 Communication layers Each of the layers is outlined below. Physical layer • Detects, sends, and receives band signals. • Sends serial data to and receives it from the link layer. Link layer • Negotiates against mutual transfer requests between the host system and device.
Page 87: Outline Of The Shadow Block Register
5.2.2 Outline of the Shadow Block Register Each transport layer in the host system and device has a block register, which is called a Shadow Block Register in the host system, and a Block Register in the device. These registers are used when the host system issues a command to the device. Table 5.3 Shadow Block Register Read Error...
Page 88: Outline Of The Frame Information Structure (Fis)
Interface 5.2.3 Outline of the frame information structure (FIS) The transport layer converts data written in a Block Register into the FIS, and sends it to the upper layer. The FIS, which is generated in the transport layer, is explained below. 5.2.3.1 FIS types The types of FIS are as follows (Each FIS is referred to as abbreviation in square brackets in this manual.):...
Page 89: Figure 5.4 Register - Host To Device Fis Layout
5.2.3.2 Register - Host to Device The Register - Host to Device FIS has the following layout: Features Device Features (exp) LBA High (exp) Control Reserved (0) Reserved (0) Reserved (0) Figure 5.4 Register - Host to Device FIS layout The host system uses the Register - Host to Device FIS when information in the Register Block is transferred from the host system to the device.
Page 90: Figure 5.5 Register - Device To Host Fis Layout
Interface 5.2.3.3 Register - Device to Host The Register - Device to Host FIS has the following layout: Error Device Reserved (0) LBA High (exp) Reserved (0) Reserved (0) Figure 5.5 Register - Device to Host FIS layout The Register - Device to Host FIS is used when information concerning the Shadow Register Block in the host adapter is updated.
Page 91: Figure 5.7 Dma Setup - Device To Host Or Host To Device Fis Layout
5.2.3.5 DMA Setup - Device to Host or Host to Device (Bidirectional) The DMA Setup - Device to Host or Host to Device FIS has the following layout: Reserved (0) Figure 5.7 DMA Setup - Device to Host or Host to Device FIS layout The DMA Setup - Device to Host or Host to Device FIS communicates the start of a first-party DMA access to the host system.
Page 92: Figure 5.8 Bist Active - Bidirectional Fis Layout
Interface 5.2.3.6 BIST Active - Bidirectional The BIST Active - Bidirectional FIS has the following layout: Reserved (0) Pattern definition T A S L F P R V Data [31:24] Data [31:24] Figure 5.8 BIST Active - Bidirectional FIS layout The BIST Active - Bidirectional FIS is used to set the receiver to Loop Back mode.
Page 93: Figure 5.9 Data Fis (Bidirectional) Layout
5.2.3.7 Data - Host to Device or Device to Host (Bidirectional) This Data FIS has the following layout: Reserved (0) Figure 5.9 Data FIS (Bidirectional) layout The Data FIS is used for data transfers between the host system and device. 5.2.3.8 PIO Setup - Device to Host Error Dev / Head...
Page 94 Interface FIS Type - Cyl Low - Cyl Low (exp) - Cyl High - Cyl High (exp) - Dev / Head - Dev / Head (exp) - Contains the contents of the expanded address field of the E_Status - Error - Sector Count - Sector Count (exp) - Contains the contents of the expanded address field of the Sector Number -...
Page 95: Figure 5.11 Set Device Bits Fis
5.2.3.9 Set Device Bits - Device to Host Error R Status Hi R Status Lo R I R Figure 5.11 Set Device Bits FIS The Set Device Bits - Device to Host FIS is used by the device to load Shadow Command Block bits for which the device has exclusive write access.
Page 96: Shadow Block Registers
Interface 5.2.4 Shadow block registers Error Field The Error Field indicates the status of the command executed by the device. The fields are valid when the ERR bit of the Status field is 1. This register contains a diagnostic code after power is turned on, the COMRESET or the EXECUTIVE DEVICE DIAGNOSTIC command is executed.
Page 97 Features Field (exp) The Features Field provides specific feature to a command. For instance, it is used with SET FEATURES command to enable or disable caching. Sector Count Field (exp) The Sector Count Field indicates the number of sectors of data to be transferred in a read or write operation between the host system and the device.
Page 98 Interface Cylinder High Field (exp) The contents of this field indicate high-order 8 bits of the disk-access start cylinder address. At the end of a command, the contents of this field are updated to the current cylinder number. The high-order 8 bits of the cylinder address are set to the Cylinder High Register.
Page 99 Status field The contents of this field indicate the status of the device. The contents of this field are updated at the completion of each command. When the BSY bit is 1, other bits of this field, are invalid. Bit 7 Bit 6 DRDY - Bit 7:...
Page 100 Interface Command Field The Command Field contains a command code being sent to the device. After this field is written, the command execution starts immediately. Table 5.5 lists the executable commands and their command codes. This table also lists the necessary parameters for each command that are written to certain fields before the Command register is written.
Page 101: Host Commands
5.3 Host Commands The host system issues a command to the device by writing necessary parameters in related fields in the shadow block registers and writing a command code in the Command field of the shadow block registers. The device can accept the command when the BSY bit is 0 (the device is not in the busy status).
Page 102 Interface Table 5.5 Command code and parameters (2/3) COMMAND NAME IDLE CHECK POWER MODE SLEEP SMART DEVICE CONFIGURATION READ MULTIPLE WRITE MULTIPLE SET MULTIPLE MODE READ DMA WRITE DMA READ BUFFER FLUSH CACHE WRITE BUFFER IDENTIFY DEVICE IDENTIFY DEVICE DMA SET FEATURES SECURITY SET PASSWORD SECURITY UNLOCK...
Page 103 Table 5.5 Command code and parameters (3/3) COMMAND NAME READ LOG EXT WRITE SECTOR(S) EXT WRITE DMA EXT SET MAX ADDRESS EXT WRITE MULTIPLE EXT WRITE DMA FUA EXT WRITE LOG EXT READ VERIFY SECTOR(S) EXT WRITE UNCORRECTABLE EXT READ LOG DMA EXT WRITE LOG DMA EXT READ FP DMA QUEUED WRITE FP DMA QUEUED...
Page 104: Command Descriptions
Interface 5.3.2 Command descriptions The contents of the shadow block registers to be necessary for issuing a command and the example indication of the shadow block registers at command completion are shown as following in this subsection. Example: READ SECTOR (S) At command issuance (Shadow Block Registers setting contents) CH EXP...
Page 105: Recalibrate (X '10' To X '1F')
RECALIBRATE (X '10' to X '1F') This command performs the calibration. When the device completes the calibration, the device reports the status to the host system. This command can be issued in the LBA mode. • Error reporting conditions (1) An error was detected during head positioning (ST = 51h, ER = 02h). (2) A SATA communication error occurred (ST = 51h, ER = 14h).
Page 106: Read Sector(S) (X '20' Or X '21')
Interface READ SECTOR(S) (X '20' or X '21') This command reads data of sectors specified in the Sector Count field from the address specified in the Device/Head, Cylinder High, Cylinder Low and Sector Number fields. Number of sectors can be specified from 1 to 256 sectors. To specify 256 sectors reading, '00' is specified.
Page 107 At command issuance (Shadow Block Registers setting contents) (R: Retry) At command completion (Shadow Block Registers contents to be read) *1 If the command is terminated due to an error, the remaining number of sectors of which data was not transferred. C141-E280 HD No.
Page 108: Write Sector(S) (X '30' Or X '31')
Interface WRITE SECTOR(S) (X '30' or X '31') This command writes data of sectors from the address specified in the Device/Head, Cylinder High, Cylinder Low, and Sector Number fields to the address specified in the Sector Count field. Number of sectors can be specified from 1 to 256 sectors.
Page 109 At command issuance (Shadow Block Registers setting contents) (R: Retry) At command completion (Shadow Block Registers contents to be read) If the command was terminated because of an error, the number of sectors for which data has not been written is set in this field. C141-E280 HD No.
Page 110: Write Verify (X '3C')
Interface WRITE VERIFY (X '3C') This command operates similarly to the WRITE SECTOR(S) command except that the device verifies each sector immediately after being written. The verify operation is a read and check for data errors without data transfer. Any error that is detected during the verify operation is posted.
Page 111 At command completion (Shadow Block Registers contents to be read) *1 If the command is terminated because of an error, the number of remaining sectors for which data has not been written or verified is set in this register. C141-E280 Status information HD No.
Page 112: Read Verify Sector(S) (X '40' Or X '41')
Interface READ VERIFY SECTOR(S) (X '40' or X '41') This command operates similarly to the READ SECTOR(S) command except that the data is not transferred to the host system. After all requested sectors are verified, the device reports the status to the host system.
Page 113 At command completion (Shadow Block Registers contents to be read) *1 If the command is terminated due to an error, the remaining number of sectors of which data was not transferred is set in this register. C141-E280 Status information HD No. / LBA Start cylinder No.
Page 114: Seek (X '70' To X '7F')
Interface SEEK (X '70' to X '7F') This command performs a seek operation to the track and selects the head specified in the command block registers. After completing the seek operation, the device reports the status to the host system. In the LBA mode, this command performs the seek operation to the cylinder and head position in which the sector is specified.
Page 115: Execute Device Diagnostic (X '90')
EXECUTE DEVICE DIAGNOSTIC (X '90') This command performs an internal diagnostic test (self-diagnosis) of the device. The device reports the diagnostic result and status to the host. Table 5.6 lists the diagnostic code written in the Error field which is 8-bit code. Code X '00' Format Unit is not completed.
Page 116: Initialize Device Parameters (X '91')
Interface INITIALIZE DEVICE PARAMETERS (X '91') The host system can set the number of sectors per track and the maximum head number (maximum head number is "number of heads minus 1") per cylinder with this command. Upon receipt of this command, the device sets the parameters. Then the device reports the status to the host system.
Page 117: Download Microcode (X '92')
DOWNLOAD MICROCODE (X '92') At command issuance (Shadow Block Registers setting contents) At command completion (Shadow Block Registers contents to be read) This command rewrites the microcode of the device (firmware). When this command is accepted, the device does beginning the data transfer of the microcode or the microcode rewriting according to Subcommand code (Rewriting is also possible simultaneously with the data transfer).
Page 118: Table 5.7 Operation Of Download Microcode
Interface Table 5.7 Operation of DOWNLOAD MICROCODE Host Command Sector Offset Subcommand code (FR Field) (CH, CL Field) ---- xxxxh ---- Excluding 01h, and 07h *1: When FR Field = 03 (Mode3) is specified, Abort is returned as an error when the specification of doing Sector Offset (CH, CL Field) is the transfer end the last sector and is not consecutive.
Page 119: Table 5.8 Example Of Rewriting Procedure Of Data 640K Bytes (A0000H Bytes) Of Microcode
Table 5.8 Example of rewriting procedure of data 640K Bytes (A0000h Bytes) Transfer example 1: CMD = 92h SN, SC = 0100h FR = 0lh CMD = 92h SN, SC = 0100h FR = 0lh CMD = 92h SN, SC = 0100h FR = 0lh CMD = 92h SN, SC = 0100h FR = 0lh CMD = 92h SN, SC = 0100h FR = 0lh CMD = 92h SN, SC = 0000h FR = 07h...
Page 120: Standby Immediate (X '94' Or X 'E0')
Interface (10) STANDBY IMMEDIATE (X '94' or X 'E0') Upon receipt of this command, the device enters the standby mode. The device then reports the status to the host system. This command does not support the APS timer function. • Error reporting conditions (1) A SATA communication error occurred (ST = 51h, ER = 14h).
Page 121: Idle Immediate (X '95' Or X 'E1')/Unload Immediate (X '95' Or X 'E1')
(11) IDLE IMMEDIATE (X '95' or X 'E1')/UNLOAD IMMEDIATE (X '95' or X 'E1') • Default Function Upon receipt of this command, the device enters the idle mode. Then, the device reports the status to the host system. This command does not support the APS timer function.
Page 122 Interface • Unload Feature (Unload Immediate Command): When the device received the IDLE IMMEDIATE command with the UNLOAD FEATURE, the head(s) is unloaded to the ramp position. After the device completed the unload operation, the INTRQ signal will be asserted and the BUSY flag will be cleared.
Page 123: Standby (X '96' Or X 'E2')
(12) STANDBY (X '96' or X 'E2') Upon receipt of this command, the device enters the standby mode. If the device has already spun down, the spin-down sequence is not implemented. If the Sector Count field has a value other than "0," the APS timer is set when the command is received.
Page 124: Idle (X '97' Or X 'E3')
Interface (13) IDLE (X '97' or X 'E3') Upon receipt of this command, the device enters the idle mode. The device reports the status even if the device has not fully entered the idle mode. If the spindle of the device is already rotating, the spin-up sequence shall not be implemented.
Page 125 At command completion (Shadow Block Registers contents to be read) C141-E280 Status information Error information 5.3 Host Commands 5-51...
Page 126: Check Power Mode (X '98' Or X 'E5')
Interface (14) CHECK POWER MODE (X '98' or X 'E5') The host checks the power mode of the device with this command. The host system can confirm the power save mode of the device by the contents of the Sector Count field after executing this command. The device sets the following field value.
Page 127: Sleep (X '99' Or X 'E6')
(15) SLEEP (X '99' or X 'E6') This command is the only way to make the device enter the sleep mode. Upon receipt of this command, the device enters the sleep mode, then reports the status to the host system. The device reports the status even if the device has not fully entered the sleep mode.
Page 128: Smart (X 'B0')
Interface (16) SMART (X 'B0') This command predicts the occurrence of device failures depending on the subcommand specified in the Features field. If the Features field contains values that are not supported with the command, the Aborted Command error is issued. Before issuing the command, the host must set the key values in the Cylinder Low and Cylinder High field (4Fh in the Cylinder Low field and C2h in the Cylinder High field).
Page 129: Table 5.9 Features Field Values (Subcommands) And Functions (1/3
Table 5.9 Features Field values (subcommands) and functions (1/3) Features Field X 'D0' SMART READ DATA: A device that received this subcommand saves all the updated attribute values. The device then transfers 512-byte attribute value information to the host after transferring PIOSU. * For information about the format of the attribute value information, see Table 5.10.
Page 130 Interface Table 5.9 Features Field values (subcommands) and functions (2/3) Features Field X 'D5' SMART READ LOG: A device which receives this sub-command reads the log sector specified in the Sector Number Field. Next, it transfers the PIOSU and transmits the log sector to the host computer.
Page 131 Table 5.9 Features Field values (subcommands) and functions (3/3) Features Field X 'D9' SMART DISABLE OPERATIONS: This subcommand disables SMART. The setting is maintained even when the device is turned off and then on. When the device receives this subcommand, it disables SMART, then transfers the RegDH.
Page 132 Interface At command issuance (Shadow Block Registers setting contents) At command completion (Shadow Block Registers contents to be read) The attribute value information is 512-byte data; the format of this data is shown the following Table 5.10. The host can access this data using the SMART READ DATA subcommand (Features field = D0h).
Page 133: Table 5.10 Format Of Device Attribute Value Data
Table 5.10 Format of device attribute value data Byte(hex) 00, 01 Data format version number Attribute 1 03, 04 07 to 0C 0E to 169 Attribute 2 to attribute 30 Off-line data collection status Self-test execution status 16C, 16D Off-line data collection execution time [sec.] Reserved Off-line data collection capability 170, 171...
Page 134 Interface • Data format version number The data format version number indicates the version number of the data format of the device attribute values or guarantee failure thresholds. The data format version numbers of the device attribute values and guarantee failure thresholds are the same.
Page 135 • Status Flag If this bit is 1, it indicates normal operations are assured with the attribute when the attribute value exceeds the threshold value. If this bit is 1 (0), it indicates the attribute only updated by an on- line test (off-line test).
Page 136: Table 5.12 Off-Line Data Collection Status
Interface Table 5.12 Off-line data collection status Status Byte 00h or 80h Off-line data collection is not executed. 02h or 82h Off-line data collection has ended without an error. 04h or 84h Off-line data collection is interrupted by a command from the host. 05h or 85h Off-line data collection has ended before completion because of a command from the host.
Page 137: Table 5.14 Off-Line Data Collection Capability
• Off-line data collection capability Indicates the method of off-line data collection carried out by the drive. If the off- line data collection capability is 0, it indicates that off-line data collection is not supported. Table 5.14 Off-line data collection capability If this bit is 1, it indicates that the SMART EXECUTE OFF- LINE IMMEDATE sub-command (Features field = D4h) is supported.
Page 138: Table 5.16 Drive Error Logging Capability
Interface • Error logging capability Table 5.16 Drive error logging capability If this bit is 1, it indicates that the drive error logging function is supported. 1 to 7 Reserved bits • Checksum Two's complement of the lower byte, obtained by adding 511-byte data one byte at a time from the beginning.
Page 139: Table 5.18 Data Format Of Smart Summary Error Log
• SMART error logging If the device detects an unrecoverable error during execution of a command received from the host, the device registers the error information in the SMART Summary Error Log (see Table 5.18) and the SMART Comprehensive Error Log (see Table 5.19), and saves the information on media.
Page 140 Interface Table 5.18 Data format of SMART Summary Error Log (2/2) Byte(hex) 46 to 58 5A, 5B 5C to 1C3 1C4, 1C5 Total number of drive errors 1C6 to 1FE Reserved Check sum • Command data structure Indicates the command received when an error occurs. •...
Page 141: Table 5.19 Data Format Of Smart Comprehensive Error Log
• Status Bits 0 to 3: Indicates the drive status when received error commands according to the following table. Bits 4 to 7: Vendor unique Status Unclear status Sleep status Standby status Active status (BSY bit = 0) Off-line data collection being executed 5 to F Reserved Table 5.19 Data format of SMART Comprehensive Error Log...
Page 142: Table 5.20 Smart Self-Test Log Data Format
Interface Table 5.20 SMART self-test log data format Byte(hex) 00, 01 Self-test log data structure Self-test log 1 04, 05 07 to 0A 0B to 19 1A to 1F9 Self-test log 2 to 21 1FA, 1FB Vendor unique Self-test index 1FD, 1FE Reserved Check sum...
Page 143: Table 5.21 Selective Self-Test Log Data Structure
Table 5.21 Selective self-test log data structure Byte(hex) 00, 01 Data Structure Revision Number 02 to 09 Test Span 1 0A to 11 12 to 19 Test Span 2 1A to 21 22 to 29 Test Span 3 2A to 31 32 to 39 Test Span 4 3A to 41...
Page 144: Table 5.22 Selective Self-Test Feature Flags
Interface • Current Span under test As the self-test progress, the device shall modify this value to contain the test span number currently being tested. • Feature Flags Table 5.22 Selective self-test feature flags Vendor specific (unused) When set to one, perform off-line scan after selective test. Vendor specific (unused) When set to one, off-line scan after selective test is pending.
Page 145: Table 5.23 Sct Command And The Function
Table 5.23 SCT command and the function Sector Number Features field field X 'E0' X 'D5' X 'E0' X 'D6' X 'E1' X 'D5' X 'E1' X 'D6' C141-E280 Function SCT STATUS REQUEST: A device that received this subcommand transfers Status information of SCT in 512 bytes to the host.
Page 146 Interface • SCT STATUS REQUEST (SN = E0h, FR = D5h) This command is used to know the status data of SCT shown in Table 5.24 of the device. At command issuance (Shadow Block Registers setting) At command completion (Shadow Block Registers contents to be read) 5-72 Key (C2h) Key (4Fh)
Page 147: Table 5.24 Format Of Sct Status Response
Table 5.24 Format of SCT STATUS Response (1/2) Byte(hex) 00, 01 Format Version 02, 03 SCT Version 04, 05 SCT Spec Status Flag Bit31-1: Reserved Bit0: Initialized flag (maintained Power-OFF/ON) 06 to 09 0 = When any user LBA is written, this bit is cleared. This bit is also cleared if the capacity of the drive is changed via SET MAX (EXT), DCO.
Page 148 Interface Table 5.24 Format of SCT STATUS Response (2/2) Byte(hex) 14 to 27 Reserved 28 to 2F Current LBA of SCT command executing in background 30 to C7 Reserved HDA Temp [°C] Current drive HDA temperature Minimum HDA temperature in this power cycle Max Temp [°C] Maximum HDA temperature in this power cycle Minimum HDA temperature for the life of the device...
Page 149: Table 5.25 Sct Status Code
Table 5.25 SCT STATUS code Code(hex) 0000 Command completed without error 0001 Invalid Function Code 0002 Input LBA out of range 0003 Request sector count over flow 0004 Invalid Function Code in Error Recovery Control command 0005 Invalid Selection Code in Error Recovery Control command 0006 Host read command timer is less than minimum value.
Page 150 Interface • SCT COMMAND SET (SN = E0h, FR = D6) This command transfers Key Sector Format in 512 bytes including the action code shown in Table 5.26 to the device, and executes each function to show in Table 5.27 to Table 5.30. 28-bit command At command issuance (Shadow Block Registers setting) At command completion (Shadow Block Registers contents to be read)
Page 151: Table 5.26 Action Code
Code(hex) 0000 Reserved 0001 Not supported WRITE SAME 0002 See Table 5.27. ERROR RECOVERY CONTROL 0003 See Table 5.28. FEATURE CONTROL 0004 See Table 5.29. SCT DATA TABLE 0005 See Table 5.30. 0006 to BFFF Reserved C000 to FFFF Vender specific Table 5.27 WRITE SAME (1/2) Byte(hex) Name...
Page 152: Table 5.28 Error Recovery Control
Interface Table 5.27 WRITE SAME (2/2) Byte(hex) Name Value 0C to13 Count (8 byte) 14 to17 Pattern (4 byte) 18 to 1FF (Reserved) * It is invalid excluding the description value. Table 5.28 ERROR RECOVERY CONTROL Byte(hex) Name Value 00, 01 Action Code 0003h 0001h...
Page 153: Table 5.29 Feature Control Command
Table 5.29 FEATURE CONTROL COMMAND Byte(hex) Name Value 00, 01 Action Code 0004h 0001h Function 0002h 02, 03 Code 0003h 0001h 04, 05 Feature Code 0002h 0003h 06, 07 New State (2 byte) 08, 09 Option Flag (2 byte) 0A to 1FF (Reserved) C141-E280 Description...
Page 154: Table 5.30 Sct Data Table
Interface Table 5.30 SCT DATA TABLE Byte(hex) Name Value 00, 01 Action Code 0005h 02, 03 Function Code 0001h 0000h 0001h 0002h 0003h 04, 05 Table ID CFFFh D000h FFFFh 06 to 1FF (Reserved) 5-80 Description SCT DATA TABLE Read Data Table Invalid Reserved HDA Temperature History Table...
Page 155: Table 5.31 Hda Temperature
Table 5.31 HDA Temperature Byte(hex) 00, 01 Format Version Sampling Period 02, 03 Frequency of sampling each set time of temperature log. Interval 04, 05 Time of temperature log of interval (min) Max Operation Limit (°C) Over Limit (°C) Min Operation Limit (°C) Under Limit (°C) 0A to 1D Reserved...
Page 156 Interface • SCT READ DATA (SN = E1h, FR = D5h) This command reads the data specified with SCT SET COMMAND and number of sectors specified Sector Count field. 28-bit command At command issuance (Shadow Block Registers setting) At command completion (Shadow Block Registers contents to be read) SCT READ DATA Command issue procedure.
Page 157 • SCT WRITE DATA (SN = E1h, FR = D6h) This command writes the data of the number of sectors for which the data specified with SCT SET COMMAND and number of sectors specified Sector Count Field. 28-bit command At command issuance (Shadow Block Registers setting) At command completion (Shadow Block Registers contents to be read) SCT WRITE DATA Command issue procedure.
Page 158: Device Configuration (X 'B1')
Interface (17) DEVICE CONFIGURATION (X 'B1') Individual Device Configuration Overlay feature sub commands are identified by the value placed in the Features field. The following table shows these Features field values. If this command sets with the reserved value of Features field, an aborted command error is posted.
Page 159 • DEVICE CONFIGURATION RESTORE (Features Field = C0h) The DEVICE CONFIGURATION RESTORE command disables any setting previously made by a DEVICE CONFIGURATION SET command and returns the content of the IDENTIFY DEVICE command response to the original settings as indicated by the data returned from the execution of a DEVICE CONFIGURATION IDENTIFY command.
Page 160 Interface • DEVICE CONFIGURATION IDENTIFY (Features Field = C2h) The DEVICE CONFIGURATION IDENTIFY command returns information shown in Table 5.32. The content of this data structure indicates the selectable commands, modes, and feature sets that the device is capable of supporting. If a DEVICE CONFIGURATION SET command has been issued reducing the capabilities, the response to an IDENTIFY DEVICE command will reflect the reduced set of capabilities, however, the DEVICE CONFIGURATION...
Page 161: Table 5.32 Device Configuration Identify Data Structure
Table 5.32 DEVICE CONFIGURATION IDENTIFY data structure (1/2) Word Value X '0002' Data structure revision X '0007' Multiword DMA modes supported Reflected in IDENTIFY information "WORD63". Bits 15-3: Reserved Bit 2: Bit 1: Bit 0: X '003F' Ultra DMA modes supported Reflected in IDENTIFY information "WORD88".
Page 162 Interface Table 5.32 DEVICE CONFIGURATION IDENTIFY data structure (2/2) Word Value X '0015' Serial-ATA command set/function → Reflected in IDENTIFY information "Word 76 to 79". Bits 15-5: Reserved Bit 4: Bit 3: Bit 2: Bit 1: Bit 0: X '0000' Reserved for Serial-ATA 10 to 20 X '0000'...
Page 163: Read Multiple (X 'C4')
(18) READ MULTIPLE (X 'C4') The READ MULTIPLE command performs the same tasks as the READ SECTOR(S) command except that this command sends the PIO Setup FIS before sending data blocks of multiple sectors. The PIO Setup FIS is sent only before the first data block is transferred, and it is not sent before any subsequent transfer of sector blocks.
Page 164: Figure 5.12 Execution Example Of Read Multiple Command
Interface Host Figure 5.12 Execution example of READ MULTIPLE command • Error reporting conditions (1) A specified address exceeds the range where read operations are allowed (ST = 51h, ER = 10h). (2) The range where read operations are allowed will be exceeded by an address during a read operation (ST = 51h, ER = 10h).
Page 165 At command issuance (Shadow Block Registers setting contents) At command completion (Shadow Block Registers contents to be read) *1 If the command is completed normally, the number of remaining sectors is set in this field. If the command is terminated because of an error, the number of sectors for which data has not been transferred is set in the field.
Page 166: Write Multiple (X 'C5')
Interface (19) WRITE MULTIPLE (X 'C5') The WRITE MULTIPLE command performs the same tasks as the WRITE SECTOR(S) command except that this command sends the PIO Setup FIS before sending data blocks of multiple sectors. The PIO Setup FIS is sent only before the first data block is transferred, and it is not sent before any subsequent transfer of sector blocks .
Page 167 At command issuance (Shadow Block Registers setting contents) (R: Retry) At command completion (Shadow Block Registers contents to be read) *1 If the command was terminated because of an error, the number of sectors for which data has not been written is set in this field. C141-E280 HD No.
Page 168: Set Multiple Mode (X 'C6')
Interface (20) SET MULTIPLE MODE (X 'C6') This command enables the device to perform the READ MULTIPLE and WRITE MULTIPLE commands. The block count (number of sectors in a block) for these commands is also specified by the SET MULTIPLE MODE command.
Page 169 At command completion (Shadow Block Registers contents to be read) C141-E280 Status information Sector count/block Error information 5.3 Host Commands 5-95...
Page 170: Read Dma (X 'C8' Or X 'C9')
Interface (21) READ DMA (X 'C8' or X 'C9') The READ DMA command reads data from sectors, starting from the sectors specified in the Device/Head, Cylinder High, Cylinder Low, and Sector Number fields and continuing for as many sectors as specified in the Sector Count field. A value ranging from 1 to 256 can be specified for the number of sectors.
Page 171 At command issuance (Shadow Block Registers setting contents) At command completion (Shadow Block Registers contents to be read) *1 If the command is terminated due to an error, the remaining number of sectors of which data was not transferred is set in this register.
Page 172: Write Dma (X 'Ca' Or X 'Cb')
Interface (22) WRITE DMA (X 'CA' or X 'CB') The WRITE DMA command writes data to sectors starting from the sectors specified in the Device/Head, Cylinder High, Cylinder Low, and Sector Number fields and continuing for as many sectors as specified in the Sector Count field. A value ranging from 1 to 256 can be specified for the number of the sectors.
Page 173 At command issuance (Shadow Block Registers setting contents) At command completion (Shadow Block Registers contents to be read) *1 If the command was terminated because of an error, the number of sectors for which data has not been written is set in this field. C141-E280 HD No.
Page 174: Read Buffer (X 'E4')
Interface (23) READ BUFFER (X 'E4') The host system can read the current contents of the data buffer of the device by issuing this command. Upon receipt of this command, the device transfers the PIO Setup. After that, the host system can read up to 512 bytes of data from the buffer. •...
Page 175: Flush Cache (X 'E7')
(24) FLUSH CACHE (X 'E7') This command is used to write every write cache data stored by the device into the medium. When the device completes all the data writing, it reports the status to the host system. The device performs every error recovery so that the data are read correctly.
Page 176: Write Buffer (X 'E8')
Interface (25) WRITE BUFFER (X 'E8') The host system can overwrite the contents of the data buffer of the device with a desired data pattern by issuing this command. Upon receipt of this command, the device transfers the PIO Setup. After that, 512 bytes of data are transferred from the host and the device writes the data to the buffer, then reports the status.
Page 177: Identify Device (X 'Ec')
(26) IDENTIFY DEVICE (X 'EC') The host system issues the IDENTIFY DEVICE command to read parameter information from the device. When it receives the command, the device prepares the parameter information to be sent to the host. Next, the device sends the PIO Setup FIS to the host, then sends the parameter information including a 512-byte data.
Page 178: Identify Device Dma (X 'Ee')
Interface (27) IDENTIFY DEVICE DMA (X 'EE') When this command is not used to transfer data to the host in DMA mode, this command functions in the same way as the Identify Device command. • Error reporting conditions (1) A SATA communication error occurred (ST = 51h, ER = 84h). At command issuance (Shadow Block Registers setting contents) At command completion (Shadow Block Registers contents to be read) 5-104...
Page 179: Table 5.33 Information To Be Read By Identify Device Command
Table 5.33 Information to be read by IDENTIFY DEVICE command (1/3) Word Value X '045A' General Configuration X '3FFF' Number of Logical cylinders X 'C837' Detailed Configuration X '0010' Number of Logical Heads X '0000' Undefined X '003F' Number of Logical sectors per Logical track X '0000' Undefined 10-19...
Page 180 Interface Table 5.33 Information to be read by IDENTIFY DEVICE command (2/3) Word Value X '0000' Reserved X 'xx07' Multiword DMA transfer mode X '0003' Advance PIO transfer mode support status X '0078' Minimum multiword DMA transfer cycle time per word: 120 [ns] X '0078' Manufacturer's recommended DMA transfer cycle time: 120 [ns] X '0078'...
Page 181 Table 5.33 Information to be read by IDENTIFY DEVICE command (3/3) Word Value 104-105 X '00' Reserved Physical sector size per logical sector X '0000' Reserved X 'xxxx' 15:12 NAA_ID(3:0) 11:0 X 'xxxx' 15:4 X 'xxxx' 15:0 X 'xxxx' 15:0 112-116 X '0000' Reserved...
Page 182 X '3FFF' X '10' X '10' X '3F' X '3F' X 'FFFFFFF' X 'FFFFFFF' X '1D1C5970' X '1749F1B0' MHZ2120BJ MHZ2080BJ X '3FFF' X '3FFF' X '10' X '10' X '3F' X '3F' X 'DF94BB0' X '950F8B0' X 'DF94BB0' X '950F8B0'...
Page 183 *4 Word 49: Capabilities Bits 15-14: Reserved Bit 13: Standby timer value. ATA spec is '1.' Bit 12: Reserved Bit 11: '1' = IORDY supported Bit 10: '1' = IORDY inhibition supported Bit 9: '1' = DMA supported Bit 8: '1' = LBA supported Bits 7-0: Undefined...
Page 184 Interface *9 Word 63: Multiword DMA transfer mode Bits 15-11: Reserved Bit 10: '1' = multiword DMA mode 2 is selected. Bit 9: '1' = multiword DMA mode 1 is selected. Bit 8: '1' = multiword DMA mode 0 is selected. Bits 7-3: Reserved Bit 2:...
Page 185 *13 WORD 78 Bits 15-7: Reserved Bit 6: '1' = Supports the software settings preservation. Bit 5: Reserved Bit 4: '1'= Supports the in-order data delivery. Bit 3: '1'= Supports the Power Management initiation from the device to Bit 2: '1' = Supports the DMA Setup FIS Auto-Activate optimization.
Page 186 Interface *16 WORD 82 Bit 15: Undefined Bit 14: '1' = Supports the NOP command. Bit 13: '1' = Supports the READ BUFFER command. Bit 12: '1' = Supports the WRITE BUFFER command. Bit 11: Undefined Bit 10: '1' = Supports the Host Protected Area feature set. Bit 9: '1' = Supports the DEVICE RESET command.
Page 187 Bit 4: Bit 3: Bit 2: Bit 1: Bit 0: *18 WORD 84 Bit 15: Bit 14: Bit 13: Bits 12-9: Bit 8: Bit 7: Bit 6: Bit 5: Bits 4-2: Bit 1: Bit 0: *19 WORD 85 Bit 15: Bit 14: Bit 13: Bit 12:...
Page 188 Interface Bit 6: '1' = Enables the read cache function. From the SET FEATURES Bit 5: '1' = Enables the write cache function. Bit 4: '1' = Enables the P PACKET command set. Bit 3: '1' = Supports the Power Management function. Bit 2: '1' = Supports the Removable Media function.
Page 189 Bit 10: '1' = Mode 2 is selected. Bit 9: '1' = Mode 1 is selected. Bit 8: '1' = Mode 0 is selected. Bits 7-0: Supportable Ultra DMA transfer mode Bit 6: '1' = Supports the Mode 6 Bit 5: '1' = Supports the Mode 5 Bit 4: '1' = Supports the Mode 4...
Page 190 Interface *26 WORD 106 Bit 15: 0 The device always returns the fixed value indicated on the left. Bit 14: 1 The device always returns the fixed value indicated on the left. Bit 13: '1' = Each device has several logical sectors per physical sector. Bit 12: '1' = Logical sector of the device is greater than 256 Words.
Page 191 *29 WORD 128 Bits 15-9: Reserved Bit 8: Security level. 0: High, 1: Maximum Bits 7-6: Reserved Bit 5: '1' = Enhanced security erase supported Bit 4: '1' = Security counter expired Bit 3: '1' = Security frozen Bit 2: '1' = Security locked Bit 1: '1' = Security enabled...
Page 192 Interface *33 WORD 220: Write Read Verify mode (Optional) Verify mode display when Write Read Verify function is set by SET FEATURES command. Bits 15-8: Reserved Bits 7-0: Verify mode display Value: 00h-03h *34 WORD 234: Minimum number of 512Byte units per DOWNLOAD When the command for which mode 3(FR reg = 03h) is specified with DOWNLOAD MICROCODE (0x92) is issued, the host is a unit of possible transfer of the minimum transfer sector.
Page 193: Set Features (X 'Ef')
(28) SET FEATURES (X 'EF') The host system issues the SET FEATURES command to set parameters in the Features field for the purpose of changing the device features to be executed. Upon receipt of this command, the device sets the parameters in the Features field, then reports the status to the host system.
Page 194 Interface Table 5.34 Features field values and settable modes (2/2) Features Field X '88' Undefined (Note 1) X '8B' Disable Write-Read-Verify feature set. X '90' Disables the Serial ATA function. X '99' Undefined (Note 1) X 'AA' Enables the read cache function. Specifies the transfer of 4-byte ECC for READ LONG and WRITE LONG X 'BB' commands.
Page 195 • Error reporting conditions (1) An undefined code is specified in the FR or SC field (ST = 51h, ER = 04h). (2) A SATA communication error occurred (ST = 51h, ER = 14h). At command issuance (Shadow Block O registers setting contents) At command completion (Shadow Block Registers contents to be read) C141-E280 xx or *5...
Page 196 Interface Data Transfer Mode The host sets X '03' to the Features field. By issuing this command with setting a value to the Sector Count Field, the transfer mode can be selected. Upper 5 bits of the Sector Count register defines the transfer type and lower 3 bits specifies the binary mode value.
Page 197 Advanced Power Management (APM) The host writes the Sector Count field with the desired power management level and executes this command with the Features field X '05', and then Advanced Power Management is enabled. The drive automatically shifts to power saving mode up to the specified APM level when the drive does not receive any commands for a specific time.
Page 198 Interface Serial ATA Functions The host can enable and disable the following Serial ATA functions by issuing this command after setting X '10/90' in the Features field and an applicable value in the Sector Count field: Serial ATA function Non-zero buffer offset in DMA Setup FIS DMA Setup FIS Auto-Activate optimization Device-initiated interface power state Transitions Guaranteed In-Order Data Delivery...
Page 199 Automatic Acoustic Management (AAM) The host writes to the Sector Count filed with the requested acoustic management level and executes this command with subcommand code 42h, and then Automatic Acoustic Management is enabled. The AAM level setting is preserved by the drive across power on and COMRESET.
Page 200: Security Set Password (X 'F1')
Interface (29) SECURITY SET PASSWORD (X 'F1') This command enables a user password or master password to be set. The host transfers the 512-byte data shown in Table 5.35 to the device. The device determines the operation of the lock function according to the specifications of the Identifier bit and Security level bit in the transferred data.
Page 201 • Error reporting conditions (1) The device is in Security Locked mode (ST = 51h, ER = 04h). (2) The device is in Security Frozen mode (ST = 51h, ER = 04h). (3) A SATA communication error occurred (ST = 51h, ER = 14h). At command issuance (Shadow Block Registers setting contents) At command completion (Shadow Block Register contents to be read) C141-E280...
Page 202: Security Unlock (X 'F2')
Interface (30) SECURITY UNLOCK (X 'F2') This command cancels LOCKED MODE. The host transfers the 512-byte data shown in Table 5.37 to the device. Operation of the device varies as follows depending on whether the host specifies the master password. •...
Page 203 • Error reporting conditions (1) An incorrect password is specified (ST = 51h, ER = 04h). (2) The device is in Security Frozen mode (ST = 51h, ER = 04h). (3) A SATA communication error occurred (ST = 51h, ER = 14h). At command issuance (Shadow Block Registers setting contents) At command completion (Shadow Block Register contents to be read) C141-E280...
Page 204: Security Erase Prepare (X 'F3')
Interface (31) SECURITY ERASE PREPARE (X 'F3') The SECURITY ERASE UNIT command feature is enabled by issuing the SECURITY ERASE PREPARE command and then the SECURITY ERASE UNIT command. The SECURITY ERASE PREPARE command prevents data from being erased unnecessarily by the SECURITY ERASE UNIT command. •...
Page 205: Security Erase Unit (X 'F4')
(32) SECURITY ERASE UNIT (X 'F4') This command erases all user data. This command also invalidates the user password and releases the lock function. The host transfers the 512-byte data shown in Table 5.38 to the device. The device compares the user password or master password in the transferred data with the user password or master password already set.
Page 206 Interface • Error reporting conditions (1) An incorrect password is specified (ST = 51h, ER = 04h). (2) The Security Erase Prepare command did not complete normally beforehand (ST = 51h, ER = 04h). (3) The device is in Security Frozen mode (ST = 51h, ER = 04h). (4) A SATA communication error occurred (ST = 51h, ER = 14h).
Page 207: Security Freeze Lock (X 'F5')
(33) SECURITY FREEZE LOCK (X 'F5') This command puts the device into FROZEN MODE. The following commands used to change the lock function return the Aborted Command error if the device is in FROZEN MODE. • SECURITY SET PASSWORD • SECURITY UNLOCK •...
Page 208 Interface • DEVICE CONFIGURATION IDENTIFY • READ LOG EXT • WRITE DMA FUA EXT • WRITE LOG EXT • WRITE UNCORRECTABLE EXT • READ LOG DMA EXT • WRITE LOG DMA EXT • READ FP DMA QUEUED • WRITE FP DMA QUEUED •...
Page 209: Security Disable Password (X 'F6')
(34) SECURITY DISABLE PASSWORD (X 'F6') This command invalidates the user password already set and releases the lock function. The host transfers the 512-byte data shown in Table 5.37 to the device. The device compares the user password or master password in the transferred data with the user password or master password already set, and releases the lock function if the passwords are the same.
Page 210 Interface • Error reporting conditions (1) An incorrect password is specified (ST = 51h, ER = 04h). (2) The device is in Security Locked mode (ST = 51h, ER = 04h). (3) The device is in Security Frozen mode (ST = 51h, ER = 04h). (4) A SATA communication error occurred (ST = 51h, ER = 14h).
Page 211: Read Native Max Address (X 'F8')
(35) READ NATIVE MAX ADDRESS (X 'F8') This command posts the maximum address intrinsic to the device, which can be set by the SET MAX ADDRESS command. Upon receipt of this command, the device indicates the maximum address in the DH, CH, CL and SN field. Then reports the status to the host system.
Page 212: Set Max (X 'F9')
Interface (36) SET MAX (X 'F9') SET MAX Features Register Values Value 05h - FFh • SET MAX ADDRESS A successful READ NATIVE MAX ADDRESS command shall immediately precede a SET MAX ADDRESS command. This command allows the maximum address accessible by the user to be set in LBA or CHS mode.
Page 213 • Error reporting conditions (1) The command has been issued more than twice (ST = 51h, ER = 10h). (2) The READ NATIVE MAX ADDRESS command has not been issued prior to the SET MAX ADDRESS command (ST = 51h, ER = 04h). (3) The SET MAX ADDRESS (EXT) command has been issued (ST = 51h, ER = 04h).
Page 214 Interface • Error reporting conditions (1) The device is in Set Max Locked mode or Set Max Freeze Locked mode (ST = 51h, ER =04h). (2) A SATA communication error occurred (ST = 51h, ER = 14h). At command issuance (Shadow Block Registers setting contents) At command completion (Shadow Block Registers contents to be read) Words 1 to 16...
Page 215 • SET MAX LOCK (Features Field = 02h) The SET MAX LOCK command sets the device into SET_MAX_LOCK state. After this command is completed, any other SET MAX commands except SET MAX UNLOCK and SET MAX FREEZE LOCK commands are rejected. And the device returns command aborted.
Page 216 Interface • SET MAX UNLOCK (Features Field = 03h) This command requests a transfer of single sector of data from the host, and defines the contents of SET MAX ADDRESS password. The password supplied in the sector of data transferred shall be compared with the stored password.
Page 217 • SET MAX FREEZE LOCK (Features Field = 04h) The Set MAX FREEZE LOCK command sets the device to SET_MAX_Frozen state. After the device made a transition to the Set Max Freeze Lock state, the following SET MAX commands are rejected, then the device returns command aborted: −...
Page 218: Read Sector(S) Ext (X '24')
Interface (37) READ SECTOR(S) EXT (X '24') • Description This command is the extended command of the READ SECTOR (S) command. The LBA specification is increased from 28 bits to 48 bits, and the maximum number of sectors that can be transferred by a single command is changed from 100h to 10000h.
Page 219: Read Dma Ext (X '25')
(38) READ DMA EXT (X '25') • Description This command is the extended command of the READ DMA command. The LBA specification is increased from 28 bits to 48 bits, and the maximum number of sectors that can be transferred by a single command is changed from 100h to 10000h.
Page 220: Read Native Max Address Ext (X '27')
Interface (39) READ NATIVE MAX ADDRESS EXT (X '27') • Description This command is used to assign the highest address that the device can initially set with the SET MAX ADDRESS EXT command. The maximum address is displayed in the CH(EXP), CL(EXP), SN(EXP) filed of the device shadow block registers.
Page 221: Read Multiple Ext (X '29')
(40) READ MULTIPLE EXT (X '29') • Description This command is the extended command of the READ MULTIPLE command. The LBA specification is increased from 28 bits to 48 bits, and the maximum number of sectors that can be transferred by a single command is changed from 100h to 10000h.
Page 222: Read Log Ext (X '2F')
Interface (41) READ LOG EXT (X '2F') The READ LOG EXTEND command reads versatile log data. Versatile log data includes the Extended SMART Comprehensive Error log, the Extended SMART Self-test log, and the SMART Selective log. The effectiveness of the log types depends on customization.
Page 223 At command issuance (Shadow Block Registers setting contents) CH EXP CL EXP SN EXP SC EXP FR EXP At command completion (Shadow Block Registers contents to be read) CH EXP CL EXP SN EXP SC EXP C141-E280 Sector offset (15-8) Sector offset (7-0) Log address Sector count (15-8)
Page 224: Table 5.39 Data Format Of Read Log Ext Log Page 10H
Interface Table 5.39 Data format of Read Log Ext log page 10h Byte(hex) Tag field Reserved Status field value Error field value Sector Number field value Cylinder Low field value Cylinder High field value Dev/Head field value Sector Number Exp field value Cylinder Low Exp field value Cylinder High Exp field value Reserved...
Page 225: Table 5.41 Data Format Of Read Log Ext Log Page 11H
Table 5.41 Data format of Read Log Ext log page 11h Byte(hex) 00 to 03 Reserved 04 to 05 Counter 1 Identifier 06 to 09 Counter 1 Value 0A to 0B Counter 2 Identifier 0C to 0F Counter 2 Value 4C to 4D Counter 10 Identifier 4E to 51...
Page 226 Interface • SCT STATUS REQUEST (SN = E0h) Refer to SMART Command Transport (SCT). At command issuance (Shadow Block Registers setting) CH EXP CL EXP SN EXP SC EXP FR EXP At command completion (Shadow Block Registers contents to be read) CH EXP CL EXP SN EXP...
Page 227 • SCT READ DATA (SN = E1h, FR = D5) Refer to SMART Command Transport (SCT). At command issuance (Shadow Block Registers setting) CH EXP CL EXP SN EXP SC EXP FR EXP At command completion (Shadow Block Registers contents to be read) CH EXP CL EXP SN EXP...
Page 228: Write Sector(S) Ext (X '34')
Interface (42) WRITE SECTOR(S) EXT (X '34') • Description This command is the extended command of the WRITE SECTOR (S) command. The LBA specification is increased from 28 bits to 48 bits, and the maximum number of sectors that can be transferred by a single command is changed from 100h to 10000h.
Page 229: Write Dma Ext (X '35')
(43) WRITE DMA EXT (X '35') • Description This command is the extended command of the WRITE DMA command. The LBA specification is increased from 28 bits to 48 bits, and the maximum number of sectors that can be transferred by a single command is changed from 100h to 10000h.
Page 230: Set Max Address Ext (X '37')
Interface (44) SET MAX ADDRESS EXT (X '37') • Description This command limits specifications so that the highest address that can be accessed by users can be specified only in LBA mode. The address information specified with this command is set in words 1, 54, 57, 58, 60, 61, and 100 to 103 of the IDENTIFY DEVICE command response.
Page 231 At command issuance (Shadow Block Registers setting contents) CH EXP CL EXP SN EXP SC EXP FR EXP At command completion (Shadow Block Registers contents to be read) CH EXP CL EXP SN EXP SC EXP C141-E280 SET MAX LBA (47-40) SET MAX LBA (23-16) SET MAX LBA (39-32) SET MAX LBA (15-8)
Page 232: Write Multiple Ext (X '39')
Interface (45) WRITE MULTIPLE EXT (X '39') • Description This command is the extended command of the WRITE MULTIPLE command. The LBA specification is increased from 28 bits to 48 bits, and the maximum number of sectors that can be transferred by a single command is changed from 100h to 10000h.
Page 233: Write Dma Fua Ext (X '3D')
(46) WRITE DMA FUA EXT (X '3D') • Description The WRITE DMA FUA EXT command reports the status of a command after user data is written to a medium, regardless of whether the write cache feature is enabled or disabled. The other command control and error reporting conditions are the same as those of the WRITE DMA EXT command.
Page 234: Write Log Ext (X '3F')
Interface (47) WRITE LOG EXT (X '3F') The WRITE LOG EXTEND command writes versatile log data. Versatile log data includes the Extended SMART Comprehensive Error log, the Extended SMART Self-test log, and the SMART Selective log; and each log can be partially written with this command.
Page 235 At command issuance (Shadow Block Registers setting contents) CH EXP CL EXP SN EXP SC EXP FR EXP At command completion (Shadow Block Registers contents to be read) CH EXP CL EXP SN EXP SC EXP C141-E280 Sector offset (15-8) Sector offset (7-0) Log address Sector count (15-8)
Page 236 Interface • SCT COMMAND SET (SN = E0h) Refer to SMART Command Transport (SCT). At command issuance (Shadow Block Registers setting) CH EXP CL EXP SN EXP SC EXP FR EXP At command completion (Shadow Block Registers contents to be read) CH EXP CL EXP SN EXP...
Page 237 • SCT WRITE DATA (SN = E1h) Refer to SMART Command Transport (SCT). At command issuance (Shadow Block Registers setting) CH EXP CL EXP SN EXP SC EXP FR EXP At command completion (Shadow Block Registers contents to be read) CH EXP CL EXP SN EXP...
Page 238: Read Verify Sector(S) Ext (X '42')
Interface (48) READ VERIFY SECTOR(S) EXT (X '42') • Description This command is the extended command of the READ VERIFY SECTOR (S) command. The LBA specification is increased from 28 bits to 48 bits, and the maximum number of sectors that can be transferred by a single command is changed from 100h to 10000h.
Page 239: Write Uncorrectable Ext (X '45')
(49) WRITE UNCORRECTABLE EXT (X '45') • Description In this command, it is a purpose to make the uncorrectable error for specified LBA intentionally. It reports on the uncorrectable error in the LBA against corresponding LBA after this command ends the lead operation etc. However, if a usual light operates afterwards even when the uncorrectable error is made by this command, it is recoverable.
Page 240: Table 5.43 Operation Mode
Interface At command issuance (Shadow Block Registers setting contents) CH EXP CL EXP SN EXP SC EXP FR EXP At command completion (Shadow Block Registers contents to be read) CH EXP CL EXP SN EXP SC EXP Table 5.43 Operation mode Feature (bit 7-0) *1 Create a pseudo-uncorrectable error...
Page 241: Read Log Dma Ext (X '47')
(50) READ LOG DMA EXT (X '47') • Description This command does operation that it is the same as READ LOG EXT doing transfer to the host in the DMA mode. For details, refer to READ LOG EXT. At command issuance (Shadow Block Registers setting contents) CH EXP CL EXP SN EXP...
Page 242: Write Log Dma Ext (X '57')
Interface (51) WRITE LOG DMA EXT (X '57') • Description This command does operation that it is the same as WRITE LOG EXT doing transfer to the host in the DMA mode. For details, refer to WRITE LOG EXT. At command issuance (Shadow Block Registers setting contents) CH EXP CL EXP SN EXP...
Page 243: Read Fp Dma Queued (X '60')
(52) READ FP DMA QUEUED (X '60') • Description For details about control of the READ FP DMA QUEUED command, see Section 5.4.6. At command issuance (Shadow Block Registers setting contents) CH EXP CL EXP SN EXP SC EXP FR EXP At command completion (Shadow Block Registers contents to be read) CH EXP CL EXP...
Page 244: Write Fp Dma Queued (X '61')
Interface (53) WRITE FP DMA QUEUED (X '61') • Description For details about control of the WRITE FP DMA QUEUED command, see Section 5.4.6. At command issuance (Shadow Block Registers setting contents) CH EXP CL EXP SN EXP SC EXP FR EXP At command completion (Shadow Block Registers contents to be read) CH EXP...
Page 245: Write Multiple Fua Ext (X 'Ce')
(54) WRITE MULTIPLE FUA EXT (X 'CE') • Description The WRITE MULTIPLE FUA EXT command reports the status of a command after user data is written to a medium, regardless of whether the write cache feature is enabled or disabled. The other command control and error reporting conditions are the same as those of the WRITE MULTIPLE EXT command.
Page 246: Flush Cache Ext (X 'Ea')
Interface (55) FLUSH CACHE EXT (X 'EA') • Description This command executes the same operations as the FLUSH CACHE command (E7h). However, only LBA=1 can be specified in the command. • Error reporting conditions (1) A SATA communication error occurred (ST = 51h, ER = 14h). At command issuance (Shadow Block Registers setting contents) CH EXP CL EXP...
Page 247: Error Posting
5.3.3 Error posting Table 5.43 lists the defined errors that are valid for each command. Table 5.44 Command code and parameters (1/2) COMMAND NAME RECALIBRATE READ SECTOR(S) WRITE SECTOR(S) WRITE VERIFY READ VERIFY SECTOR(S) SEEK EXECUTE DEVICE DIAGNOSTIC INITIALIZE DEVICE PARAMETERS DOWNLOAD MICROCODE STANDBY IMMEDIATE...
Page 248 Interface Table 5.44 Command code and parameters (2/2) COMMAND NAME SECURITY UNLOCK SECURITY ERASE PREPARE SECURITY ERASE UNIT SECURITY FREEZE LOCK SECURITY DISABLE PASSWORD READ NATIVE MAX ADDRESS SET MAX READ SECTOR(S) EXT READ DMA EXT READ NATIVE MAX ADDRESS EXT READ MULTIPLE EXT READ LOG EXT WRITE SECTOR(S) EXT...
Page 249: Command Protocol
5.4 Command Protocol The host should confirm that the BSY bit of the Shadow Block Status register of the device is 0 prior to issue a command. If BSY bit is 1, the host should wait for issuing a command until BSY bit is cleared to 0. Commands can be executed only when the DRDY bit of the Status register is 1.
Page 250: Non-Data Command Protocol
Interface 5.4.1 Non-data command protocol Execution of the following commands does not involve data transfer between the host and the device. • RECALIBRATE • SEEK • READ VERIFY SECTOR(S) (EXT) • WRITE UNCORRECTABLE EXT • EXECUTE DEVICE DIAGNOSTIC • INITIALIZE DEVICE PARAMETERS •...
Page 251: Figure 5.13 Non-Data Command Protocol
• SLEEP • DEVICE CONFIGRATION RESTORE • DEVICE CONFIGRATION FREEZE LOCK • WRITE UNCORRECTABLE EXT The following is the protocol for command execution without data transfer: 1) The device receives a non-data command with the RegHD FIS. 2) The device executes the received command. 3) Command execution is completed.
Page 252: Pio Data-In Command Protocol
Interface 5.4.2 PIO data-in command protocol Execution of the following commands involves data transfers from the device to the host system: • IDENTIFY DEVICE • READ SECTOR(S) (EXT) • READ MULTI (EXT) • READ BUFFER • SMART READ DATA • SMATR READ LOG SECTOR •...
Page 253: Figure 5.14 Pio Data-In Command Protocol
5.4 Command Protocol RegHD Host Device PIO Setup DATA Figure 5.14 PIO data-in command protocol C141-E280 5-179...
Page 254: Pio Data-Out Command Protocol
Interface 5.4.3 PIO data-out command protocol Execution of the following commands involves data transfers from the host system to the device: • WRITE SECTOR (S) (EXT) • WRITE MULTI (EXT) (FUA EXT) • WRITE BUFFER • WRITE VERIFY • SMART WRITE LOG SECTOR •...
Page 255: Figure 5.15 Pio Data-Out Command Protocol
4) The device receives the DATA FIS from the host. 5) When all data has been transferred, the device sends the RegDH FIS (with 1 set in the I bit) to complete execution of the command. If the device has an error, it reports the error.
Page 256: Dma Data-In Command Protocol
Interface 5.4.4 DMA data-in command protocol DMA data-in commands include the following commands: • READ DMA (EXT) • IDENTFY DEVICE DMA • READ LOG DMA EXT The DMA mechanism transfers data of more than one block from the device to the host.
Page 257: Dma Data-Out Command Protocol
5.4.5 DMA data-out command protocol The DMA data-out command is the following command: • WRITE DMA (EXT) (FUA EXT) • WRITE LOG DMA EXT The DMA mechanism transfers data of more than one block from the host to the device. The completion of the command is reported by an interruption. An outline of this protocol is as follows: 1) The device receives the DMA data-out command with the RegHD FIS.
Page 258: Native Command Queuing Protocol
Interface 5.4.6 Native Command Queuing protocol Native Queued commands include the following commands: • READ FP DMA QUEUED • WRITE FP DMA QUEUED An outline of the command queuing protocol is as follows: 1) After the device receives a Native Queued command, if the command is executable, the device sends to the host the RegDH FIS with the settings of I bit = 0, BSY bit = 0, and DRQ bit = 0, and it places the command in the command queue.
Page 259: Figure 5.18 Read Fp Dma Queued Command Protocol
8) If an uncorrectable error occurs during command queuing, the device sends to the host the Set Device Bits FIS with the settings of ERR bit = 1, ERRReg = ATAErrCode, I bit = 1, and SActive = 0 to report an error. 9) After reporting the error, the device accepts only the READ LOG EXT command with page 10h specified and the reset requests (SoftReset and COMRESET).
Page 260: Figure 5.19 Write Fp Dma Queued Command Protocol
Interface Host Figure 5.19 WRITE FP DMA QUEUED command protocol 5-186 RegHD Device RegDH DMA Setup DMACT DATA SetDB C141-E280...
Page 261: Power-On And Comreset
5.5 Power-on and COMRESET Figure 5.20 shows the power-on sequence, and Figure 5.21 shows the COMRESET sequence. Immediately after power-on or COMRESET, the host sets 0x7Fh in the Status field of the Shadow Block Register and 0xFFh in other fields. After the power-on sequence shown below and after communication with the SATA interface is established, the host sets 0xFFh in the Status field of the Shadow Block Register.
Page 262: Figure 5.21 Comreset Sequence
Interface Host Host releases Host/device releases Host Host ComReset calibrate ComWake Align Host Host Host ComReset ComWake data Host TX (Device RX) Device TX (Host RX) Device Device Device ComInit ComWake data Device Device Device releases Calibrate Align ComInit Figure 5.21 COMRESET sequence 5-188 C141-E280...
Page 263: Chapter 6 Operations
CHAPTER 6 Operations Reset and Diagnosis Power Save Power Save Controlled by Interface Power Management (IPM) Read-ahead Cache Write Cache This chapter explains each of the above operations. C141-E280...
Page 264: Reset And Diagnosis
Operations 6.1 Reset and Diagnosis This section explains the device responses to power-on and an accepted reset. 6.1.1 Response to power-on Immediately after power is turned on, the host sets 0x7Fh in the Status field of the Shadow Block and 0xFFh in other fields. After communication with the SATA interface is established, the host sets 0xFFh in the Status field of the Shadow Block.
Page 265: Figure 6.2 Response To Power-On (When The Device Is Powered On Earlier Than The Host)
6.1 Reset and Diagnosis Figure 6.2 Response to power-on (when the device is powered on earlier than the host) C141-E280...
Page 266: Response To Comreset
Operations 6.1.2 Response to COMRESET The response to COMRESET is almost the same as the response when power is turned on and a power-on reset is then cancelled. The device establishes communication with the SATA interface (PHY Ready) and sends the RegDH FIS (STS = 50h) to notify the host that the device is ready.
Page 267 6.1.2.1 Software settings preservation When a device is enumerated, software will configure the device using SET FEATURES and other commands. These software settings are often preserved across software reset but not necessarily across hardware reset. In Parallel ATA, only commanded hardware resets can occur, thus legacy software only reprograms settings that are cleared for the particular type of reset it has issued.
Page 268 Operations • SET ADDRESS MAX (EXT) The maximum LBA specified in SET MAX ADDRESS or SET MAX ADDRESS EXT. • SET FEATURES (Write Cache Enable/Disable) The write cache enable/disable setting established by the SET FEATURES command with subcommand code of 02h or 82h. •...
Page 269: Response To A Software Reset
6.1.3 Response to a software reset When a software reset is accepted, the device performs a self-diagnosis, and it sends the RegDH FIS (STS = 50h) to notify the host that the device is ready. Then, the software reset sequence is completed. Figure 6.4 Response to a software reset C141-E280 6.1 Reset and Diagnosis...
Page 270: Power Save
Operations 6.2 Power Save The host can change the power consumption state of the device by issuing a power command to the device. 6.2.1 Power save mode There are five types of power consumption state of the device including active mode where all circuits are active.
Page 271 • Upon receipt of a COMRESET • Upon receipt of Idle/Idle Intermediate (4) Standby mode In this mode, the spindle motor has stopped from the low power idle state. The device can receive commands through the interface. However if a command with disk access is issued, response time to the command under the standby mode takes longer than the active, active idle, or low power idle mode because the access to the disk medium cannot be made immediately.
Page 272: Power Commands
Operations 6.2.2 Power commands The following commands are available as power commands. • IDLE • IDLE IMMEDIATE • STANDBY • STANDBY IMMEDIATE • SLEEP • CHECK POWER MODE • SET FEATURES (APM setting) 6-10 C141-E280...
Page 273: Power Save Controlled By Interface Power Management (Ipm)
6.3 Power Save Controlled by Interface Power Management (IPM) 6.3 Power Save Controlled by Interface Power Management (IPM) The host system can change the power consumption status of the interface by issuing the PARTIAL or SLUMBER request to the device. 6.3.1 Power save mode of the interface The interface power consumption states of this device can be separated into the following three modes, including the Active mode where the device is in the...
Page 274 Operations (3) Slumber mode In this mode, the (deep) Power Save mode is set for the interface circuit. The device switches to Slumber mode when the following occurs: • The device receives the PMREQ_P signal from the host and responds with the PMACK signal.
Page 275: Read-Ahead Cache
6.4 Read-ahead Cache Read-ahead Cache is the function for automatically reading data blocks upon completion of the read command in order to read data from disk media and save data block on a data buffer. If a subsequent command requests reading of the read-ahead data, data on the data buffer can be transferred without accessing the disk media.
Page 276: Caching Operation
Operations 6.4.2 Caching operation The caching operation is performed only when the commands listed below are received. If any of the following data are stored on the data buffer, the data is sent to the host system. • All of the sector data that this command processes. •...
Page 277 (3) Invalidating caching-target data Data that is a target of caching on the data buffer is invalidated under the following conditions: 1)-1 Any command other than the following commands is issued. (All caching- target data is invalidated.) READ BUFFER WRITE BUFFER RECALIBRATE FORMAT TRACK SET FEATURES...
Page 278: Using The Read Segment Buffer
Operations 6.4.3 Using the read segment buffer Methods of using the read segment buffer are explained for following situations. 6.4.3.1 Miss-hit In this situations, the top block of read requested data is not stored at all in the data buffer. As a result, all of the read requested data is read from disk media. 1) HAP (host address pointer) and DAP (disk address pointer) are defined in the head of the segment allocated from Buffer.
Page 279 6.4.3.2 Sequential hit When the read command that is targeted at a sequential address is received after execution of the read commands is completed, the read command transmits the Read requested data to the host system continuing read-ahead without newly allocating the buffer for read.
Page 280 Operations 6.4.3.3 Full hit In this situation, all read requested data is stored in the data buffer. Transfer of the read requested data is started from the location where hit data is stored. For data that is a target of caching and remains before a full hit, the data is retained when execution of the command is completed.
Page 281 6.4.3.4 Partial hit In this situation, a part of read requested data including the top sector is stored in the data buffer. A transfer of the read requested data starts from the address where the data that is hit is stored until the top sector of the read requested data. Remaining part of insufficient data is read then.
Page 282: Write Cache
Operations 6.5 Write Cache Write Cache is the function for reducing the command processing time by separating command control to disk media from write control to disk media. When Write Cache is permitted, the write command can be keep receiving as long as the space available for data transfers remains free on the data buffer.
Page 283 (3) Status report in the event of an error The status report concerning an error occurring during writing onto media is created when the next command is issued. Where the command reporting the error status is not executed, only the error status is reported. Only the status of an error that occurs during write processing is reported.
Page 284 This page is intentionally left blank.
Page 285: Chapter 7 Maintenance And Diagnosis
CHAPTER 7 Maintenance and Diagnosis Maintenance Operation Confirmation Troubleshooting Procedure Disk Drive Removal Procedure Spare Disk Drive This chapter describes the maintenance, diagnosis, operation check, troubleshooting, removal, and replacement of the disk drive. The following are explained: • Rules for regular maintenance and troubleshooting •...
Page 286: Maintenance
Maintenance and Diagnosis 7.1 Maintenance 7.1.1 Rules for maintenance The following cautions must be observed to prevent injury during troubleshooting or maintenance. Static, Damage Don't install or remove a PCA or connect or disconnect a cable or connector plug when the drive is powered. This may give you an electric shock.
Page 287: Maintenance Requirements
The PCA and the DE cannot be replaced separately in the field. Replace the whole disk drive. (4) Service system and repair Fujitsu Limited has a disk drive service system and repair facility. When making a request for repair or parts replacement, you should provide related information usually including:...
Page 288 Maintenance and Diagnosis Data corruption When asking for repair, save all data stored in the disk drive beforehand. Fujitsu Limited is not responsible for any loss of data during service and repair. (5) Notes on handling General notes a) Vibrations and shocks more severe than allowed will cause fatal damage to the device so be very careful.
Page 289: Maintenance Levels
Place the device in an antistatic vinyl bag along with a desiccant (silica gel). b) It is recommended that you use the shock absorption cushion material and packaging that contained the device when it was delivered by Fujitsu. If the same packaging material cannot be used, use a shock absorbent box that will transmit shocks directly to the device.
Page 290: Disk Drive Revision Number
Maintenance and Diagnosis 7.1.4 Disk drive revision number The disk drive revision number is a single alphabetic character followed by a single alphanumeric character. It is stuck on the DE and marked on the revision number label. Figure 7.1 shows the disk drive revision number label format. Disk drive revision number Figure 7.1 Disk drive revision number label...
Page 291: Figure 7.2 Display Of Disk Drive Revision Number
First 4-digit indicates a firmware code and rest 4-digit indicates its revision. Note: For a change of revision number after delivery, Fujitsu issues a "Change Request/Notice" and the disk drive revision number after the change. When a change is made at the user site, the revision number level should be changed as described above.
Page 292: Tools And Test Equipment
Maintenance and Diagnosis 7.1.5 Tools and test equipment At the field maintenance level, only ordinary hand tools are required for troubleshooting and repairing the disk drive. Special tools and test equipment is not required. Factory level tools and test equipment are beyond the scope of this manual. 7.1.6 Self-diagnostics The disk drive has the following self-diagnostics.
Page 293: Figure 7.3 Test Flowchart
Start Operation test with the host computer or test equipment Test acceptable? Continue with the operation C141-E280 Check the host system (Table 7.1) System normal? Disk drive replacement or repair Disk drive normal? Diagnostic test with the host computer or test equipment Test acceptable? Test using voltage or...
Page 294: Table 7.1 Status Field Contents
Maintenance and Diagnosis Table 7.1 Status Field contents BIT0=1 Shown in Table 7.2 BIT1, 2 It is not necessary to take any measure when other bits are normal, in spite of these bits. (Normal) BIT3=1 (1) Check whether vibration is transmitted because of the way BIT5=1 Any of these (2) Check the power, cable, and connector.
Page 295: Operation Confirmation
7.2 Operation Confirmation 7.2.1 Operation test When the host computer is processing data, the disk drive monitors disk drive operation errors including data, command, and seek errors. The host is notified of the error that the disk drive detected and the user is notified of its result. The user may notice intermittent and indefinite failures such as overlong execution time, abnormal noise, abnormal odor, or failures in particular processes.
Page 296: Troubleshooting Procedure
Maintenance and Diagnosis 7.3 Troubleshooting Procedure 7.3.1 Troubleshooting procedure This section describes the troubleshooting procedures for a disk drive failure at field maintenance level described in Subsection 7.1.3. In this section, troubleshooting is made to isolate the reported failure to the disk drive or a host system.
Page 297: Table 7.3 System Level And Field Troubleshooting
Table 7.3 System level and field troubleshooting Check to be made Confirm that the DC power voltage is within ±5% of the standard value. DC power voltage When measured at +5 V power pins P8 or P9 and GND pins P4-P6, P10, level or P12 of the power supply connector, the +5 DVC must be 4.75 to 5.25 VDC.
Page 298: Troubleshooting At Factory
Maintenance and Diagnosis 7.3.3 Troubleshooting at factory When the trouble is recovered by replacing the drive at field (Subsection 7.3.2), troubleshoot the replaced drive to isolate the trouble to the subassembly parts. To shorten the troubleshooting time and repairing time, gather the data, such as environmental data and other information, from the user and then return the failed drive to the factory to repair.
Page 299: Disk Drive Removal Procedure
7.4 Disk Drive Removal Procedure The method and procedures to demount the disk drive to check the jumper terminal, change the jumper position, or replace the device differ depend on the system cabinet structure. Therefore, for actual working procedures, the specific conditions necessary for each system must be determined.
Page 300 This page is intentionally left blank.
Page 301: Glossary
Actuator Head positioning assembly. The actuator consists of a voice coil motor and head arm. If positions the read-write (R-W) head. AT bus A bus between the host CPU and adapter board ATA (AT Attachment) standard The ATA standard is for a PC AT interface regulated to establish compatibility between products manufactured by different vendors.
Page 302 Glossary Master (Device 0) The master is the first drive that can operate on the AT bus. The master is daisy- chained with the second drive which can operate in conformity with the ATA standard. MTBF Mean time between failures. The MTBF is calculated by dividing the total operation time (total power-on time) by the number of failures in the disk drive during operation.
Page 303 Serial-ATA Serial ATA is an extension specification from the current Parallel ATA physical storage interface. The parallel data transfer of Parallel ATA is changed to the serial data transfer in Serial-ATA for obtaining greater data transfer speed. Slave (Device 1) The slave is a second drive that can operate on the AT bus.
Page 304 This page is intentionally left blank.
Page 305: Acronyms And Abbreviations
Acronyms and Abbreviations ABRT Aborted command Automatic idle control AMNF Address mark not found AT attachment American wire gage Bad block detected BIOS Basic input-output system CORR Corrected data Cylinder high field Cylinder low field Command field Current sense resistor Current start/stop Cylinder field dB A-scale weighting...
Page 306 This page is intentionally left blank.
Page 307: Index
A/D converter circuit ... 4-11 AAM ... 5-125 acceleration mode ... 4-18 acoustic noise ... 1-12 active field... 5-26 active idle mode ... 6-8 active mode ... 6-8, 6-11 actuator... 2-2, 4-2 actuator motor control ... 4-17 adaptability... 1-2 advanced power management...1-15, 1-16, 5-123 AGC circuit ...
Page 308 Index drive system ... 2-3 system ... 2-3 connection drive ... 2-3 connection to SATA interface ... 1-3 connection with host system... 3-9 connector location ... 3-9 connector pinout... 5-7 connector specification host system ... 3-10 connector, device... 3-9 controller circuit ... 2-3, 4-4 counter identifier information ...
Page 309 E_status field... 5-26 effect, blower ... 2-3 electrical specification... 5-6 enabling and disabling ... 6-21 environmental protection ... 1-2 environmental specification ... 1-11 error (ERR) bit ... 5-25 error correction and retry by ECC... 1-3 error data structure ... 5-66 error field...
Page 310 Index interface... 5-1 logical ... 5-11 physical... 5-2 SATA... 2-3 interface... 1-3 interface power management... 1-17, 1-18 interface signal ... 5-2 invalidating caching-target data ... 6-15 invalidation of cached data... 6-20 IPM... 1-17 large capacity... 1-2 layer, communication ... 5-12 limitation of mounting...
Page 311 power amplifier ... 4-13 power command ... 6-10 power management interface ... 1-17, 1-18 power requirement ... 1-8 power save... 6-8 power save controlled by interface power management (IPM)... 6-11 power save mode... 1-2, 6-8 power save mode of interface ... 6-11 power supply configuration...
Page 312 Index sensing and compensating for external force ... 4-8 sequential hit ... 6-17 serial ATA function... 5-124 service area ... 3-7 service life ... 1-13 servo burst capture circuit ... 4-13 servo circuit ... 4-3 servo control... 4-12 servo control circuit... 4-12 servo frame format ...
Page 313 viterbi detection circuit ... 4-11 wide temperature range ... 1-3 worst case attribute value ... 5-61 WRITE BUFFER... 5-102 write cache ... 1-4, 6-20 write circuit ... 4-10 WRITE DMA... 5-98 WRITE DMA EXT ... 5-155 WRITE DMA FUA EXT ... 5-159 WRITE FP DMA QUEUED...
Page 314 This page is intentionally blank. left...
Page 315 Comments & Suggestions List any errors or suggestions for improvement. Page Line Please send this form to the address below. We will use your comments in planning future editions. Address: Fujitsu Learning Media Limited 37-10 Nishikamata 7-chome Oota-ku Tokyo 144-0051 JAPAN...
Page 316 This page is intentionally left blank.
