KULINARISK
GB

Advertisement

Table of Contents
loading

Related Manuals for IKEA KULINARISK

Summary of Contents for IKEA KULINARISK

  • Page 1 KULINARISK...
  • Page 2 ENGLISH Please refer to the last page of this manual for the full list of IKEA appointed After Sales Service Provider and relative national phone numbers.
  • Page 3 ENGLISH...

  • Page 4: Table Of Contents

    Technical data Before first use Energy efficiency Daily use Environmental concerns Clock functions IKEA guarantee Automatic programmes Using the accessories Subject to change without notice. Safety information Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damage.
  • Page 5 ENGLISH WARNING: The appliance and its accessible parts become • hot during use. Keep children and pets away from the appliance when in use and when cooling down. If the appliance has a child safety device, it should be • activated.

  • Page 6: Safety Instructions

    ENGLISH Use only the food sensor (core temperature sensor) • recommended for this appliance. Safety instructions Installation Built in depth of the 548 mm Warning! Only a qualified person appliance must install this appliance. Depth with open door 1022 mm •...
  • Page 7 ENGLISH • The shock protection of live and insulated • Do not put flammable products or items parts must be fastened in such a way that that are wet with flammable products in, it cannot be removed without tools. near or on the appliance. •...
  • Page 8 ENGLISH • Replace immediately the door glass hot and hot air is released from the front panels when they are damaged. Contact cooling vents. the Authorised Service Centre. • Pyrolytic cleaning and first maximum • Be careful when you remove the door temperature use are high temperature from the appliance.

  • Page 9: Installation

    ENGLISH • Use original spare parts only. • Remove the door to prevent children and pets to get closed in the appliance. Disposal • Packaging material: The packaging material is recyclable. Warning! Risk of injury or Plastic parts are marked with suffocation.

  • Page 10: Control Panel

    ENGLISH Accessories To bake and roast or as pan to collect fat. • Core temperature sensor x 1 • Wire shelf x 2 To measure how far the food is cooked. For cookware, cake tins, roasts. • Telescopic runners x 2 sets •...
  • Page 11 ENGLISH Symbol Function Comment Time and addition‐ To set different functions. When a heating function al functions operates, press the symbol to set the timer or the functions: Function Lock, Favourites, Heat + Hold, Set + Go. You can also change the settings of the core temperature sensor.

  • Page 12: Before First Use

    ENGLISH Symbol Function Fast Heat Up The function works. It decreases the heat up time. Weight Automatic The display shows that the automatic weight system works or that weight can be changed. Heat + Hold The function works. Before first use Accessories can become hotter than usual.

  • Page 13: Daily Use

    ENGLISH Screw back the screw into the hole after removing the child lock. Warning! Be careful not to scratch the control panel. Daily use Warning! Refer to Safety Symbol / Menu Application chapters. item Navigating the menus Used to set the appli‐ ance configuration.
  • Page 14 ENGLISH Symbol / Menu Description Symbol / Menu Description item item When ON, the function Shows the software decreases the heat-up version and configura‐ Fast Heat Up Service time. tion. To set a function and Resets all settings to activate it later with a factory settings.
  • Page 15 ENGLISH Specials Heating Application function Heating function Application This function is designed to To bake bread. save energy during cooking. For the cooking instructions Moist Fan Bread Baking refer to "Hints and tips" chap‐ Baking ter, Moist Fan Baking. The For dishes such as lasa‐...

  • Page 16: Clock Functions

    ENGLISH 4. Select a heating function. Do not put food in the oven when the Fast heat up function works. 5. Press to confirm. 6. Set the temperature. To turn on the function, hold for 3 7. Press to confirm. seconds.

  • Page 17: Automatic Programmes

    2. Select the menu: Recipes. Press for this oven on the website confirm. www.ikea.com. To find the proper 3. Select the category and dish. Press Recipe Book check the article confirm. number on the rating plate on the 4.
  • Page 18 ENGLISH Push the shelf between the guide bars of the Small indentation at the top shelf support and make sure that the feet increase safety. The indentations point down. are also anti-tip devices. The high rim around the shelf prevents cookware from slipping of the shelf.

  • Page 19: Additional Functions

    ENGLISH The oven calculates an approximate end With telescopic runners you can put in and time. The end time is different for the remove wire shelves and trays easily. different quantities of the food, the set oven Caution! Do not clean the temperatures (minimum 120 °C) and the telescopic runners in the operating modes.
  • Page 20 ENGLISH 2. Select the menu: Favourites. Set + Go 3. Press to confirm. The function lets you set a heating function 4. Select your favourite programme name. (or a programme) and use it later with one 5. Press to confirm. press of any symbol.

  • Page 21: Hints And Tips

    ENGLISH • Night brightness - when the oven is of the oven cool. If you turn off the oven, the turned off, the brightness of the display is cooling fan can continues to operate until lower between 10 PM and 6 AM. the oven cools down.
  • Page 22 ENGLISH Food Accessories Temperature Shelf posi‐ Time (min) (°C) tion Rolls, 9 pieces baking tray or dripping 30 - 40 Pizza, frozen, wire shelf 10 - 15 0.35 kg Swiss roll baking tray or dripping 25 - 35 Brownie baking tray or dripping 25 - 30 Soufflè, 6 pieces ceramic ramekins on wire...
  • Page 23 ENGLISH Food Accessories Temperature Shelf posi‐ Time (min) (°C) tion Tartlets, 8 pieces baking tray or dripping 20 - 30 Poached vegeta‐ baking tray or dripping 35 - 45 bles, 0.4 kg Vegetarian ome‐ pizza pan on wire shelf 25 - 30 lette Vegetables, baking tray or dripping...
  • Page 24 ENGLISH Food Function Accesso‐ Shelf Temper‐ Time (min) Comments ries posi‐ ature tion (°C) Small Convention‐ Baking 20 - 30 Put 20 small cakes cake al Cooking tray per one baking tray. Small True Fan Baking 150 - 20 - 35 Put 20 small cakes cake Cooking...

  • Page 25: Care And Cleaning

    For additional cooking tables please refer to cavity. the Recipe Book which you can find on the website www.ikea.com. To find the proper Care and cleaning Warning! Refer to Safety chapters.
  • Page 26 ENGLISH Clean all accessories after each use and let them dry. Use a soft cloth with warm water and a mild detergent. Do not clean the accessories in a dish‐ washer. Do not clean the non-stick accessories using abrasive cleaner or sharp- Accessories edged objects.
  • Page 27 ENGLISH Removing and installing door Caution! If there are other appliances installed in the same The oven door has four glass panels. You can cabinet, do not use them at the remove the oven door and the internal glass same time as the function: panels to clean them.
  • Page 28 ENGLISH 5. Hold the door trim (B) on the top edge of the door at the two sides and push inwards to release the clip seal. 6. Pull the door trim to the front to remove 7. Hold the door glass panels by their top edge and carefully pull them out one by one.

  • Page 29: Troubleshooting

    ENGLISH 5. Replace the oven light bulb with a 40 W, 6. Install the glass cover. 230 V (50 Hz), 350 °C heat resistant oven light bulb (connection type: G9). Troubleshooting Warning! Refer to Safety chapters. What to do if... Problem Possible cause Remedy...

  • Page 30: Technical Data

    ENGLISH Problem Possible cause Remedy Steam and condensation set‐ You left the dish in the oven Do not leave the dishes in tle on the food and in the for too long. the oven for longer than 15 - cavity of the oven. 20 minutes after the cooking process ends.

  • Page 31: Energy Efficiency

    ENGLISH Number of functions Energy efficiency Product Information and Product Information Sheet* Supplier's name IKEA Model identification KULINARISK 104.210.62 Energy Efficiency Index 81.2 Energy efficiency class Energy consumption with a standard load, convention‐ 0.93 kWh/cycle al mode Energy consumption with a standard load, fan-forced 0.69 kWh/cycle...

  • Page 32: Environmental Concerns

    IKEA. This guarantee at IKEA. The original sales receipt is required applies to domestic use only. The exceptions as proof of purchase. If service work is are specified under the headline “What is not...
  • Page 33 IKEA is not liable for any discretion, either repair the defective damage that may occur during transport.
  • Page 34 ENGLISH Please do not hesitate to contact IKEA After SAVE THE SALES RECEIPT! It is Sales Service to: your proof of purchase and required for the guarantee to 1. make a service request under this apply. Note that the receipt guarantee;...
  • Page 35 Magyarország 06-1-252-1773 Belföldi díjszabás Hétköznap 8.00 és 17.00 óra között 050-7111267 ma-vr: 8.00 - 21.00 Nederland Geen extra kosten. (0900-BEL IKEA) zat: 9.00 - 21.00 Luxembourg +31 507111267 Alleen lokaal tarief. zon / pub. vakantie: 10.00 - 18.00 (internationaal) Norge l i t Österreich...
  • Page 36 21552 © Inter IKEA Systems B.V. 2022 AA-2063531-5...
