3 Preparations

3.1 Charging MaxLiteA

Notes:
• Only use the included power adapter to recharge the
tablet. Use of any other adapter will damage the tool. We
assume no responsibility for damage or loss resulting
from using other similar adapters other than the specified
one.
• Always charge on a non-flammable surface in a well-
ventilated area.
1. To check the battery
power level, press and
hold the Power button
about 3 seconds to turn
on the tablet.
Charging with the Included 5V Power Adapter
6
2. Power level is indicated as
a percentage in the upper
right corner of the screen.
If the power level drops
below 10% while the
tablet is on, a "Connect
Charger" notification will
appear on the screen.
1. Insert one end of the included
charging cable into the power
adapter.
2. Connect the other end to the
charging port of the tablet.
3. Plug the power adapter into
the AC outlet.
Charging via vehicle DLC port
1. Plug one end of the
diagnostic cable into the DB-
15 diagnostic connector of
the tablet.
2. Connect the other end to
the vehicle's DLC (Data Link
Connector) port.

3.2 Power ON/OFF

Note: If it is the first time you use the tablet or the tablet
keeps idle for a long time, it could fail to be turned on. It
results from low battery. In this case, please recharge it for a
while and try to turn it on.
MDMAXLITEA
4. After the batter y is
fully charged and the
ch a r g i n g c o m p l e t e
symbol replaces
the charging symbol.
Disconnect the power
adapter from the AC
outlet.
3. After the battery is
fully charged and the
charging complete
symbol replaces
the charging symbol.
