- Page 1 OGAL-666A GREENHOUSE ASSEMBLY INS TRU CTION S 1.888.965.3331...
- Page 2 TO PREVENT INJURY, PLEASE READ AND UNDERSTAND THE TO PREVENT INJURY, READ AND UNDERSTAND THE GREENHOUSE ASSEMBLY INSTRUCTIONS MANUAL BEFORE GREENHOUSE ASSEMBLY INSTRUCTIONS BEFORE USE. USE. Notes: Notes: 1. Around 2-3 hours is needed to assemble the greenhouse by 2-3 1.
- Page 3 6X6FT OGAL-666A 79 inches x 76 inches x 75 inches www.kshbrands.com support@kshbrands.com 1.888.965.3331...
- Page 4 Rear Front Notes: 1. Remove approximately 2 inches of film from all the sheet edges prior to installation. Upon completion, immediately remove all the remaining film. 2. The UV-protected side of the sheet, which is covered with opal white film, must face the sun.
- Page 5 www.kshbrands.com support@kshbrands.com 1.888.965.3331...
- Page 6 | OGAL-666A ASSEMBLY INSTRUCTIONS 1.2 Form a right angle using two F-04 1.1 Create a right angle by positioning parts, but ensure that the edges of the parts of F-03b and F-04. However, these pieces are located on the make sure that the grooves of F-03b and outside.
- Page 8 3 . 1 . 2 C o n n e c t F - 0 5 , F - 1 9 b , F - 1 8 b y t h e u p p e r b o l t . O n c e t h e n o t c h o n F - 1 9 b i s a l i g n e d w i t h t h e t o p o f F - 0 5 , y o u c a n s c r e w t h e n u t t i g h t o n t h e b o l t .
- Page 9 OGAL-666A ASSEMBLY INSTRUCTIONS | 4.1 Connect F-18 and F-29 to F-05 using 4.2 Using bolts and nuts, connect F-29 to bolts and nuts. When connecting these F-04. pieces, maintain a 3/4 of an inch distance NOTE: Do not tighten the nuts yet.
- Page 10 | OGAL-666A ASSEMBLY INSTRUCTIONS 5.1 Connect F-30 and F-05 to the lowest notch of F-19b using bolts and nuts. NOTE: Align the top of F-05 5.2 Using bolts and nuts, connect F-30 to F-04. with the notch of F-19b. NOTE: Do not tighten the nuts yet.
- Page 11 OGAL-666A ASSEMBLY INSTRUCTIONS | 6.2 Individually insert one bolt into F-08 6.1 Insert F-08, F-09, F-10 and F-11 into the and F-09. Then, connect F-18 to F-08 and bolt and secure it with nuts. F-09 and tighten using bolts and nuts.
- Page 12 | OGAL-666A ASSEMBLY INSTRUCTIONS 7.1 Connect F-23 to F-04 with a tightened 7.2 Slide a bolt into the slit in F-23, and nut and bolt. perpendicularly attach F-18 through the designated hole. Tighten the nut. These are the parts used in this section.
- Page 13 OGAL-666A ASSEMBLY INSTRUCTIONS | Slide the poly-carbonate panels into the designated area. These are the parts used in this section. Image Item No. www.kshbrands.com support@kshbrands.com 1.888.965.3331...
- Page 14 | OGAL-666A ASSEMBLY INSTRUCTIONS 9.2 Insert the bolts into the grooves of F-23. 9.1 Insert the bolts and nuts in each hole of F-B06, but do not tighten the nuts yet. Then, insert the bolts into the grooves of F-05.
- Page 15 OGAL-666A ASSEMBLY INSTRUCTIONS | 10.1 Place the bolt and nut into the hole 10.2 Insert two bolts each into F-08, F-09, of F-B06, but do not tighten the nut yet. F-10 and F-11. 10.3 Place the bolts and nuts in the hole...
- Page 16 | OGAL-666A ASSEMBLY INSTRUCTIONS 11.1 Insert F-06 and F-07 through the bolts inserted in F-19b and F-B06. then, tighten the nuts. 11.2 Slide the bolts which were inserted through F-08 and F-09 through the holes in F-19 as shown. These are the parts used in this section.
- Page 17 OGAL-666A ASSEMBLY INSTRUCTIONS | 12.1 Insert one bolt into F-06 and F-07, then insert into the hole of F-B07. These are the parts used in this section. Image Item No. www.kshbrands.com support@kshbrands.com 1.888.965.3331...
- Page 18 | OGAL-666A ASSEMBLY INSTRUCTIONS 13.1 Insert F-40 to F-06 and F-07. Afterwards, connect F-12 to F-19 using a bolt and nut. These are the parts used in this section. Item No. Image www.kshbrands.com support@kshbrands.com 1.888.965.3331...
- Page 19 1 4 . 2 S l i d e o n e b o l t i n t o e a c h F - 2 4 i n t h e r i g h t s i d e o f r o o f . 1 4 .
- Page 20 | OGAL-666A ASSEMBLY INSTRUCTIONS Place the poly-carbonate panels into each designated area. These are the parts used in this section. Image Item No. www.kshbrands.com support@kshbrands.com 1.888.965.3331...
- Page 21 OGAL-666A ASSEMBLY INSTRUCTIONS | 16.1 Connect F-28 to F-24 using the bolts left in F-24 and tighten with nuts. 16.2 Slide F-B05 into F-B06 as shown. These are the parts used in this section. Image Item No. www.kshbrands.com support@kshbrands.com 1.888.965.3331...
- Page 22 t h r e e...
- Page 23 OGAL-666A ASSEMBLY INSTRUCTIONS | 18.1 Slide two units of F-26 over the 18.3 Slide F-25 over the top edge of the sides of the F-37 window panel. window panel. 18.2 Slide F-27 over the bottom of the 18.4 Secure with F-B14 nuts and bolts F-37 window panel.
- Page 24 | OGAL-666A ASSEMBLY INSTRUCTIONS 19.1 Slide the window into F-B07. You should be able to pivot it up and down. www.kshbrands.com support@kshbrands.com 1.888.965.3331...
- Page 25 OGAL-666A ASSEMBLY INSTRUCTIONS | Connect each part as shown in the pictures. These are the parts used in this section. Item No. Image 20.2 Secure F-15 and F-16b with screws. 20.1 and 20.3 Insert F-22b into F-16b and secure it with screws.
- Page 26 | OGAL-666A ASSEMBLY INSTRUCTIONS 21.1 and 21.2 Slide the door into the structure. Use the diagrams below as references. These are the parts used in This is the part used in this section. Image Item No. 21.3 Screw the bolts and nuts into holes of F-03b.
- Page 27 OGAL-666A ASSEMBLY INSTRUCTIONS | 22.1 and 22.2 Insert G-P1 to each corner. 22.3 and 22.4 Fix G-P3L and G-P3R in F-13 using bolts and nuts. These are the parts used in this section. Image Item No. 22.5 Insert G-P2 to F-B07.
- Page 28 | OGAL-666A ASSEMBLY INSTRUCTIONS When the window is closed, the handle of F-20 could be rotated to the right and fixed in place. www.kshbrands.com support@kshbrands.com 1.888.965.3331...
- Page 29 OGAL-666A ASSEMBLY INSTRUCTIONS | RECOMMENDATION It is recommended to place glue or tape between the poly-carbonate panel and the aluminum frame to provide better stability. NOTE: 뺭 1. The silicone sealant and glue gun are not included in the tool kit. You may purchase these items locally.
