HARDWARE FUNCTIONS

Hardware Interface
1. Doorbell: Sends notification to YoLink App.
2. 0~9 Keypad: Enter passcode.
3. Unlock Button: Press after entring passcode.
4. Lock Button: Locks door.
5. 1~2 Switch: Set for left/right handed installation.
6. Set Button: Use to set local passcode.
7. Factory Reset: Press and hold for 20 sec to
factory reset lock.
1
2
3
4
C S 1 2
4
5
6
7
