- Page 4 1. Insert 2 dowels (#F) into each end of the leg support (#3), and the other ends of the dowels into the right and left H/board legs (#2). 2. Prepare 2 bolt assemblies by applying a lock washer (#C) onto the bolt (#B) then a flat washer (#D) onto that same bolt (#B).
- Page 5 1. Carefully place the headboard (#1) onto the top of the H/board legs (#2). 2. Prepare 6 bolt assemblies by applying a lock washer (#C) onto the bolt (#A) then a flat washer (#D) onto that same bolt (#A). Insert 3 bolt assemblies into each end of the headboard (#1) and secure using the Allen wrench (#E).
- Page 6 Insert the threaded ends of the slat supports (#8) into the holes along the slat center (#7). Turn right to tighten. 3. Insert a screw (#K) into the 1. Apply the slats (#6) onto ends of the slats (#6). Secure the side rails (#5).
- Page 10 1. Insert 2 dowels (#F) into each end of the leg support (#3), and the other ends of the dowels into the right and left H/board legs (#2). 2. Prepare 2 bolt assemblies by applying a lock washer (#C) onto the bolt (#B) then a flat washer (#D) onto that same bolt (#B).
- Page 11 1. Carefully place the headboard (#1) onto the top of the H/board legs (#2). 2. Prepare 6 bolt assemblies by applying a lock washer (#C) onto the bolt (#A) then a flat washer (#D) onto that same bolt (#A). Insert 3 bolt assemblies into each end of the headboard (#1) and secure using the Allen wrench (#E).
- Page 12 Insert the threaded ends of the slat supports (#8) into the holes along the slat center (#7). Turn right to tighten. 3. Insert a screw (#K) into the 1. Apply the slats (#6) onto ends of the slats (#6). Secure the side rails (#5).
