Monitor Out Trim
Panning Law
TBK Input
TBK HP1
TBK HP2
TBK Mon
Mute
Oscillator 1
Level
Oscillator 2
Mute
Line Out Volume
Brightness
TB Latency Mode
Discrete 8 Pro Synergy Core User Manual
Page 42
Click to choose the signal trim amount (in
dBu) for the Monitor Outputs from the
drop-down menu.
Click to specify Panning Law
compensation between 0dB (none) to -
4.5dB from the drop-down menu.
Click to change Talkback input from the
internal mic to any microphone connected
to mic/line inputs A1 - A8.
Click to send Talkback input to
Headphone output 1 (HP1).
Click to send Talkback input to
Headphone output 2 (HP2)
Click to send Talkback input to the
monitor outputs.
Mutes Oscillator 1 output.
Choose a frequency for the Oscillator 1
test signal from the drop-down menu.
Choose the output level (in dBFS) for the
oscillator 1 & 2 test signals.
Choose a frequency for the Oscillator 2
test signal from the drop-down menu.
Mute Oscillator 2 output.
Use the fader to adjust line outputs
volume (in dB). Click the adjacent 'Mute'
button to mute and unmute the line
outputs.
Use the fader to adjust the hardware
unit's display brightness.
Choose the Thunderbolt Latency mode
from the drop-down menu. Experiment
with the different modes if you
