  • Page 2: Table Of Contents

    CONTENTS BEFORE YOU BEGIN System Requirements PRODUCT ACTIVATION Configuring for Windows 10 Configuring for macOS (10.14 and later) ANTELOPE LAUNCHER ‘Devices’ Tab 'System’ Tab FRONT PANEL EXPLAINED REAR PANEL EXPLAINED CONTROL PANEL APPLICATION Introduction Mouse & Keyboard Shortcuts Main View 1...
  • Page 3 GETTING STARTED WITH HDX GETTING STARTED WITH DANTE® THUNDERBOLT™ 3 FUNCTIONALITY Daisy Chaining Device Charging Backwards Compatibility CUSTOMER SUPPORT INFORMATION MY ANTELOPE AUDIO PRODUCT ISN’T WORKING. TECHNICAL SPECIFICATIONS...

  • Page 4: Before You Begin

    BEFORE YOU BEGIN Congratulations on your purchase! We would like to turn your attention to the following: Galaxy 32 Synergy Core is a multi-channel audio interface and high-end AD/DA converter for professional recording studios and high-profile production facilities. The interface builds upon Antelope Audio’s award-winning Orion 32 line - bringing 32 channels of analog...
  • Page 5 Thus, we encourage you to familiarize yourself with the 'Control Panel Application' chapter before you begin working with the Galaxy 32 Synergy Core. Likewise, a 'Getting started with Dante®' chapter provides the foundation for a quick start with audio networking.

  • Page 6: System Requirements

    Memory (RAM): 4 GB minimum (8 GB or more recommended) • CPU: Intel Core i3™ or AMD FX (Higher recommended) Additional Information: • Stable Internet connection is required to download and update your Antelope Audio software • The device does not come with a Thunderbolt cable included...

  • Page 7: Product Activation

    Note: Legacy Thunderbolt™ connections are possible using third-party adapters and corresponding cables. 3. For Pro Tools Ultimate, connect the Galaxy 32 Synergy Core to your HDX system with DigiLink Mini cables (not included). 4. For Dante® audio-over-IP functionality, connect the Galaxy 32 Synergy Core to your computer or network switch with a standard Cat5 or Cat6 ethernet cable.
  • Page 8 Antelope Audio user area and click 'Login'. 11. Click on 'Activate device' to open the Antelope Management Wizard. Note: If the Galaxy 32 Synergy Core does not appear in the 'Devices' tab, click on 'Not seeing your device?' and follow the on-screen instructions.

  • Page 9: Configuring For Windows 10

    Please proceed with the 'Setting up' chapter below to configure the Galaxy 32 Synergy Core for use with your Windows or macOS computer. Note: The Galaxy 32 Synergy Core will be listed in the 'My Hardware' page of the Antelope Audio user area with its serial number and activation date.

  • Page 10: Configuring For Macos (10.14 And Later)

    The security settings in macOS (10.14 and later) may result in no input signal reaching your DAW, despite having everything set up correctly. These steps apply when you are using the Galaxy 32 Synergy Core in a DAW for the first time: 1.
  • Page 11 2.Click 'OK' and your DAW should function normally. However, if the events above did not occur for some reason, or you are using multiple DAWs, you must do a manual tweak for each in 'Security & Privacy' settings: 1. Click the 'Apple' symbol and choose 'System Preferences'. Head to the 'Security & Privacy' settings menu.

  • Page 12: Antelope Launcher

    The Antelope Launcher is a streamlined hub for managing and troubleshooting your Antelope Audio products. The application is organized into the following tabs: ‘Devices’ Tab All Antelope Audio devices currently connected to your computer are listed in this section. The following functionality is available in the 'Devices' tab: Device Name Click the black box to enter a name for your device.
  • Page 13 Click to launch the Antelope Registration Wizard. Use it to register or de-register devices and features (such as AFX2DAW, FPGA FX, HDX Activation and so on). Device Info Click to display the following information (useful for troubleshooting): Serial number ●...
  • Page 14 Choose your device and connection type from the drop-down menus, disconnect the device from your computer, and click ‘Next’ to perform a driver re-install. Note: If the issue persists, please contact Antelope Audio Customer Support. 'Plug-ins’ Tab...

  • Page 15: System' Tab

    This section lets you install, update, and uninstall Antelope Audio software such as native mic emulations and AFX2DAW. By default, the Bundle Version drop-down menus show the most recent software bundle available for each product. Clicking the menu shows the currently installed software bundle version and lets you roll-back to an older build.
  • Page 16 Uninstall the Antelope Audio Thunderbolt™ and/or USB driver(s) present on your ● system. Login button Click and enter your Antelope Audio username and password, then click ‘Login’. If you don't have an Antelope Audio account, click ‘Register’ and follow the on-screen instructions. Settings button Click to open the Settings window.
  • Page 17 Here, you can do the following: Click ‘View Logs’ to view, save, and send activity logs to Antelope Audio Customer ● Support. Click 'Advanced' to enable or disable automatic updates for each of the following: ● Device firmware USB Driver...

  • Page 18: Front Panel Explained

    The Galaxy 32 Synergy Core front panel features the following items (left to right): Internal clock indicator Lights up when the Galaxy 32 Synergy Core is locked to its internal clock signal generator. Atomic clock indicator Lights up when the Galaxy 32 Synergy Core is locked to an external Antelope Audio 10M/10MX Atomic Clock.
  • Page 19 • Current device sample rate – 32kHz to 192kHz. • Thunderbolt indicator – shown when the Galaxy 32 Synergy Core is connected to a computer via Thunderbolt. • Peak meters for up to 32 audio channels from an audio source of your choice.
  • Page 20 Line In Trim - choose an audio signal trim value for the line inputs (17dBu - 22dBu). By default, this option is set to 22dBu. • S/PDIF Gain – the Galaxy 32 Synergy Core lets you adjust input gain for the Left and Right S/PDIF digital audio input channels independently. Turn the jog control to...
  • Page 21 Press the jog wheel to confirm. • ADAT Gain - the Galaxy 32 Synergy Core lets you adjust input gain for up to 8 ADAT digital audio input channels independently. Turn the jog control to select between channels 1 - 8.

  • Page 22: Rear Panel Explained

    REAR PANEL EXPLAINED Power Connector For use with the provided power supply only. Thunderbolt™ 3 Computer Connection Thunderbolt™ 3 Type-C port providing PC/Mac connection. Thunderbolt™ Specs: Interface Connection: Thunderbolt™ 3 (Type-C) Port, I/O I/O Channel Count 64 Channels Daisy-chain Supported Supported sample rates 44.1 kHz—192 kHz, 24-bit PCM...
  • Page 23 1 x Input @ 75 Ohms 1Vpp on 10M Atomic Reference Input Supported sample rates 44.1 kHz—192 kHz, 24-bit PCM Word Clock Outputs 2x Word Clock outputs on BNC connectors for synchronizing external equipment to the Galaxy 32 Synergy Core.
  • Page 24 Word Clock Output Specs 2x Output @ 75 Ohms 3Vpp on Word Clock Output Dante® Connections Primary and Secondary Dante® connections on RJ 45 (Ethernet) ports. Please note that the number of input and output audio channels is sample rate-dependent. The Secondary Dante®...
  • Page 25 S/PDIF Connections S/PDIF I/O on RCA connectors. S/PDIF Specs: Interface Connection: 2 x RCA Connectors SPDIF SRC Supported I/O Channel Count 2 Channels Supported sample rates 44.1 kHz—192 kHz, 24-bit PCM MADI Connections MADI I/O carrying digital audio over fiber optic cables with SC-Plugs on both ends. Standard MADI audio limits apply per connector: MADI Specs: Interface Connection:...
  • Page 26 44.1 kHz—192 kHz, 24-bit PCM HDX Ports Two primary HDX ports carrying 32 audio channels each (64 in total). DigiLink Mini cables are not included with the Galaxy 32 Synergy Core. Interface Connection: 2 x HDX Ports, I/O I/O Channel Count...
  • Page 27 Supported sample rates 44.1 kHz—192 kHz, 24-bit PCM Monitor Speaker Outputs L/R studio speaker outputs on 1/4-inch TRS connectors. Note that these mastering-grade monitor outputs boast the greatest dynamic range in the system. Monitor Output Specs: Output Connection: 2 x 1/4” 6.35 mm Jack (3 pin) Chanel Count 2 Mono Channels Output level...
  • Page 28 Line Output Specs: Output Connection: 4 x D-sub 25-pin (Tascam Standard) I/O Channel Count 32 Channels -inf to 24dBu // 1 dB Output level step Dynamic Range 128 dB 44.1 kHz—192 kHz, Supported sample rates 24-bit PCM THD+N (A) -115 dB Impedance Load 11.2 kOhms TASCAM’s DB-25 Pinout Standard:...
  • Page 29 Input Connection: 4 x D-sub 25-pin (Tascam Standard) I/O Channel Count 32 Mono Channels Input level trim 14 dBu to 24 dBu in steps of 1 dB Dynamic Range 122 dB Supported sample rates 44.1 kHz—192 kHz, 24-bit PCM THD+N (A) -112 dB Impedance Load 11.2 kOhms...

  • Page 30: Control Panel Application

    CONTROL PANEL APPLICATION Introduction Welcome to the Galaxy 32 Synergy Core Control Panel application! It provides intuitive and comprehensive access to each aspect of the unit's functionality. This includes settings, signal routing, audio mixing, Synergy Core effects, metering, and presets.

  • Page 31: Mouse & Keyboard Shortcuts

    Main View 1 is always visible in the Control Panel's top section. It features the following areas: Function Strip From left to right, the Function Strip features the following items: On/Standby button Click to power on the Galaxy 32 Synergy Core or enter standby. Clock Source...
  • Page 32 Internal clock, External clock, ADAT (2x, 4x), MADI (2x, 4x), S/PDIF, HDX (Internal clock), HDX (Loop Sync), Dante. External Sync Indicator Lights up when the Galaxy 32 Synergy Core is locked to an external clock source. Sample Rate Drop-down menu to choose the device sample rate. The following choices are available: 32kHz, 44.1kHz, 48.0kHz, 88.2kHz, 96.0kHz, 176.4kHz, 192kHz.
  • Page 33 Back to Function strip 1… Blink button Click to make the LEDs on the Galaxy 32 Synergy Core front panel blink. This way, you can easily identify the unit that's currently connected to your computer. This is useful in situations where several units are racked.

  • Page 34: S/Pdif' View

    Control Panel Window Controls From left to right: Minimize, Maximize, Return to default size, Close window View Selector Switch the Main View between S/PDIF | ADAT | MONITORS | SESSION | INFO views. 'S/PDIF' View This view contains controls for the S/PDIF digital audio channels. The controls are identical and feature the following functionality (top to bottom): ●...

  • Page 35: Monitors' View

    The field to the left of the 'Save' and 'Load' buttons shows the currently loaded Session file. Click the 'Save' and 'Load' buttons to save and load Antelope Session files (*.as). In the Save Session window, you can choose the exact components you want stored and export Session files (*.as) from the ‘Save As’...
  • Page 36 In the Load Session window, you can browse your computer for Antelope Session files (*.as) and choose which components to load. You can also choose from a drop-down list of recently loaded Sessions or load the last used Session. Clicking the 'Set Defaults' button restores the component selection to its default setting.

  • Page 37: Info' View

    ● The 'Registration Wizard' button which opens the Antelope Registration Wizard, used for registering devices and assigning purchased Synergy Core FX or add-ons. ● Shortcuts to Antelope Audio Tech Support, the Galaxy 32 Synergy Core user manual, and contact information.

  • Page 38: Routing' View

    'ROUTING' view This view contains the Routing Matrix for analog and digital audio routing. The Routing Matrix is row-based. Each row has its own unique color and represents a specific audio input or output with its maximum number of channels. The Routing Matrix is split in two main sections: Input (Source) and Output (Destination).
  • Page 39 This is where you receive audio from your DAW. Create a new track in your DAW and assign the output with matching number - e.g. DAW 'Output 1' = 'DAW OUT' 1. These rows also represent all computer audio, such as media playback, YouTube, etc. By default, computer audio is routed to outputs 1 and 2.

  • Page 40: Mixer' View

    DANTE OUT 1-32, 33-64 These rows represent 64 channels of outgoing Dante® network audio. MADI OUT 1-32, 33-64 These rows represent 64 channels of outgoing MADI digital audio. HDX OUT 1-32, 33-64 These rows represent 64 channels of outgoing HDX digital audio. MIC IN 1-8 This row represents the available input channels for microphone emulation processing.

  • Page 41: Auraverb

    ● Due to technical reasons, we cannot offer volume automation inside the mixers at this time. Synergy Core FX automation is possible in your DAW with AFX2DAW. ● MIDI control is not supported. Mixer 1 is home to the AuraVerb send effect, explained below. AuraVerb AuraVerb provides richness and color using a special new approach and a unique algorithm.
  • Page 42 Common for most reverbs, the pre-delay lets you create a bit of space between the source and the onset of reverb. This happens by controlling the amount of delay time that precedes the initial sound from the reverb. This parameter is used to place the reverberated signal later in time with respect to the unprocessed signal.
  • Page 43 Richness Richness controls the complexity of the reverb envelopment and dampening nuances. At 0, there is less dampening and a brighter decay. This sound is light or airy, but by increasing the Richness, you can add a sense of spaciousness to the sound and smoothly increase reverb time for lower frequencies.

  • Page 44: Hdx' View

    Reverb Level This is the output level control of the reverb. Since inputs for AuraVerb are assigned to Send knobs on Mixer 1’s channels, we recommend balancing the channel volume levels from the Send controls and using Reverb Level to adjust the amount of reverb in the Master bus.
  • Page 45 HDX 1-2 Device - Port 1 & Port 2 The 64 HDX audio channels handled by the Galaxy 32 Synergy Core are spread across two virtual HDX devices with one sub-device each for a total of four virtual devices. Each virtual device handles 16 audio channels.

  • Page 46: Afx' View

    0 (default). Loop sync master indicator Lights up when the Galaxy 32 Synergy Core is the master loop sync source. Loop sync out Drop-down menu to choose the word clock output that the loop sync signal will be routed 'AFX' view The 'AFX' view is contained in a floating window.
  • Page 47 ● Hold Shift and use the mouse scroll wheel to scroll up and down through the FX rack. Notes: ● A user manual for the Antelope Audio Synergy Core FX library is available here. ● Additional effects can be purchased from the Antelope Audio online software store.

  • Page 48: Trims' View

    The views are identical and let you monitor signal levels for all audio inputs and outputs of the Galaxy 32 Synergy Core. 'Meters L' is mirrored on Display L on the Galaxy 32 Synergy Core. 'Meters R' is mirrored on Display R.

  • Page 49: Getting Started With Hdx

    Galaxy 32 Synergy Core as the Master HDX device In this scenario, the Galaxy 32 Synergy Core is your sole HDX audio interface. The unit is connected to an HDX card and is optionally connected to a computer over Thunderbolt™...
  • Page 50 Galaxy 32 Synergy Core as the Master HDX device with secondary Galaxy 32 Synergy Core slaved to it In this scenario, the Galaxy 32 Synergy Core is your master HDX audio interface and a secondary Galaxy 32 Synergy Core is slaved to its Loop Sync signal.
  • Page 51 (labeled WC IN) on the Slave Galaxy 32 Synergy Core's rear panel using a standard BNC cable. 4. Open the Control Panel application for the Master Galaxy 32 Synergy Core and select 'HDX/INT' from the Clock Source drop-down menu: 5. Open the Control Panel application for the Slave Galaxy 32 Synergy Core and select 'HDX/LS' from the Clock Source drop-down menu: 6.
  • Page 52 'HDX' view of the Control Panel application for the Master Galaxy 32 Synergy Core unit lights up. 8. The Loop Sync Master indicator in 'HDX' view of the Control Panel application for the Slave Galaxy 32 Synergy Core is not lit. 9. The sample rates of both units match.

  • Page 53: Getting Started With Dante

    Dante Controller Windows/Mac application from Audinate. 2. Connect the Galaxy 32 Synergy Core to your computer and/or network hub with a standard Cat5 or Cat6 ethernet cable. 3. Launch Dante Controller. The Galaxy 32 Synergy Core will appear as 'GALAXY32- SERIALNUMBER'.
  • Page 54 However, this will change the number of audio channels available between networked devices. 6. To use the Galaxy 32 Synergy Core as the clock source for your network, head back to the Dante® Controller application and open the 'Clock Status' tab. Place checkmarks on...
  • Page 55 To slave the Galaxy 32 Synergy Core to the network clock, remove the checkmarks in the 'Clock Status' tab. Open the Galaxy 32 Synergy Core Control Panel application and choose 'Dante' from the Clock Source drop-down menu. 6. Use the Dante® Controller application's routing matrix in combination with the Galaxy 32 Synergy Core Control Panel application to route audio between the devices in your network.

  • Page 56: Thunderbolt™ 3 Functionality

    A basic example would be connecting the Galaxy 32 Synergy Core to an external hard drive with two Thunderbolt™ 3 ports. One port is occupied by the unit while the other connects to a computer or another Thunderbolt™...

  • Page 57: Backwards Compatibility

    Backwards Compatibility Thunderbolt™ 3 is backwards-compatible with legacy Thunderbolt™ 2 and Thunderbolt™ 1 connections using third-party adapters and corresponding cables. Given all the technical variables involved, we cannot provide singular instructions for legacy compatibility in this manual. Please get in touch with Customer Support if you need help setting up.

  • Page 58: Customer Support Information

    CUSTOMER SUPPORT INFORMATION Antelope Audio Customer Support can be reached by the following means: Online Visit support.antelopeaudio.com Phone We are there for you around the clock, 21 hours/day, Monday to Friday. North America +1-916-238-1643 01:00 a.m. – 10:00 p.m. (EST) International +44 19 2593 3423 06:00 a.m.
  • Page 59 • Knowledge Base in our Customer Support section is an often-overlooked source of troubleshooting information, answers to commonly asked questions and Antelope know-how.

  • Page 60: My Antelope Audio Product Isn'tworking

    Please, don't attempt to send us your device without receiving a RMA number first, as the device will be returned and not serviced. How do I get an RMA number? The Antelope Audio Customer Support team is in charge of issuing RMA numbers. Visit support.antelopeaudio.com and get in touch.
  • Page 61 The shipping costs are covered by the owner of the product. Antelope Audio will not cover any local customs charges. We recommend using a courier service of your choice (e.g. DHL, UPS, FedEx). The package...
  • Page 62 Consumers have the right to choose whether to claim service under the Antelope Audio Limited Warranty or under their consumer law rights.
  • Page 63 3) to refund the price paid. Should Antelope Audio decide to refund the price paid, it may deduct from the paid Product’s price any damages caused to the Product; where, within fourteen (14) days of the expiration of the warranty period,(i) Antelope Audio has received written notice of any nonconformity;(ii) after Antelope Audio’s written authorization,...
  • Page 64 These warranty obligations are conditioned upon the hardware being returned to the original place of purchase, or another place as directed by Antelope Audio, with the original sales receipt attached. You will be required to pay shipping and handling charges for returning the product.
  • Page 65 (ii) Products purchased from a person or entity which is not an authorized dealer or re-seller of Antelope Audio; (iii)Product sold “as is” or “with all faults”, to the extend permitted by local law. This warranty is not valid in case any manufacturer label(s), serial numbers, date stamp(s) or warranty sticker(s) has been altered or removed from the Product.
  • Page 66 (B2B) / Direct customers of Antelope Audio please email us at techsupport@antelopeaudio.com (ii) A valid proof of purchase is required for RMA processing (i.e. receipt, invoice, etc). Antelope Audio will provide you with the RMA number within 2 working days as of the claim submission date. RMA Return Addresses We have multiple RMA receiving locations worldwide.
  • Page 67 Republic of Bulgaria with UIN: 131052590, is doing business and is worldwide known. Elsewhere in this document where the trade name Antelope Audio is used shall refer to Elektrosfera ltd., with address of management: Tsarigradsko Shose Blvd., 7th km, Building of BIC IZOT, floor 6, Mladost region, Sofia, Bulgaria.
  • Page 68 SAFETY NOTES To reduce the risk of electrical shocks, fire, and related hazards: ● Do not remove screws, cover, or cabinet. There are no user serviceable parts inside. Refer servicing to qualified service personnel. ● Do not expose this device to rain, moisture or spillover of liquid of any kind. ●...
  • Page 69 ● The device is designed to operate in a temperate environment, with a correct Operating Temperature of 0-50° C, 32-122° F.

  • Page 70: Technical Specifications

    TECHNICAL SPECIFICATIONS AD Line Input  4 x D-sub 25-pin (Tascam Input Connection:  Standard)   32 Channels  I/O Channel Count   12 dBu to 22 dBu in steps of 1 dB  Input level trim  Dynamic Range  122 dB Supported sample rates  44.1 kHz—192 kHz, 24-bit THD+N (A) ...
  • Page 71 Supported sample rates  44.1 kHz—192 kHz, 24-bit THD+N (A)  -115 dB  56 Ohms  Impedance Load  Digital Interface – Thunderbolt™  1 x Thunderbolt 3 Port, I/O  Interface Connection:   64 Channels I/O Channel Count  Supported sample rates  44.1 kHz—192 kHz, 24-bit  Supported  Control Panel Support ...
  • Page 72  Yes (16x16)  Session I/O Support  Digital Interface - MADI  2 x Optical SC Connectors  Interface Connection:   Dual Wire, Optical  MADI Mode   Supported  SMUX   AES10-2003  Madi Protocol  I/O Channel Count  64 Channels (@44.1/48.0 kHz) Supported sample rates  44.1 kHz—192 kHz, 24-bit Digital Interface - S/PDIF  2 x RCA Connectors ...
  • Page 73  4th Generation Acoustically Clocking Technology  Focused Clocking  64-Bit Jitter Management DDS  1 x Input @ 75 Ohms 3Vpp on BNC  Word Clock/Loop-Sync Input   2 x Output @ 75 Ohms 3Vpp on Word Clock/Loop-Sync Output  BNC   1 x Input @ 75 Ohms 1Vpp on BNC  10M Atomic Reference Input ...
